Hebei Speed Torque Transmission Technology Co., Ltd. proudly presents our Oil Resistant Flat End Wear Resistant Rubber Hose designed for demanding industrial applications where durability and reliability are paramount. With a robust working pressure of 1.0 MPa, this hose is engineered to withstand harsh environments, resist oil degradation, and provide long service life. Our factory, spanning 3,000–5,000 square meters and staffed by over 100 experienced professionals, ensures every meter of hose meets stringent quality standards. Backed by ISO 9001 certification, we deliver products that perform consistently in oil transfer, hydraulic systems, and general industrial use.
Product Overview: This hose features a flat end design that allows for easy coupling and leak-free connections. The wear-resistant outer layer protects against abrasion, while the oil-resistant inner tube prevents swelling or cracking when exposed to petroleum-based fluids. Ideal for use in machinery, automotive, manufacturing, and mining sectors, this hose offers a perfect balance of flexibility and strength.
Key Features & Technical Specifications
Oil Resistance: Inner tube made of NBR (Nitrile Butadiene Rubber) to resist oils, fuels, and hydraulic fluids.
Wear Resistance: Outer cover reinforced with abrasion-resistant rubber compound to withstand rough handling and contact with sharp surfaces.
Flat End Design: Smooth bore ends ensure easy installation and compatibility with standard fittings.
High Working Pressure: Rated for 1.0 MPa continuous operation, with burst pressure up to 4.0 MPa for safety margin.
Temperature Tolerance: Operates effectively in a wide temperature range from -20°C to +80°C.
Flexibility: Excellent bend radius allows for tight routing without kinking.
Customizable Dimensions: Available in various inner diameters (e.g., 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2") and lengths up to 100 meters per roll.
| Parameter | Value |
|---|---|
| Working Pressure | 1.0 MPa (145 psi) |
| Burst Pressure | ≥4.0 MPa (580 psi) |
| Inner Tube Material | NBR (Nitrile Rubber) |
| Outer Cover Material | Wear-resistant SBR/NR blend |
| Reinforcement | High-tensile textile cord or steel wire (optional) |
| Temperature Range | -20°C to +80°C |
| Minimum Bend Radius | 6x ID (typical) |
Advantages for Your Business
Reduced Downtime: The durable construction minimizes the need for frequent replacements, keeping your operations running smoothly.
Cost-Effective: Competitive pricing without compromising on quality – our annual export value of US$5–10 million reflects our ability to serve global clients efficiently.
Versatile Applications: Suitable for oil transfer lines, hydraulic return lines, fuel systems, pneumatic systems, and general industrial fluid handling.
Global Logistics: Shipped from major ports (Shanghai, Tianjin, Qingdao) with fast delivery to North America, Europe, Asia, and beyond.
Customization Options: We can tailor length, diameter, color, and end fittings to meet your specific requirements.
Our factory, established in 2017, has grown to employ 101–200 skilled workers, ensuring consistent quality control and timely production. With ISO 9001 certification, every batch of rubber hose undergoes rigorous testing for pressure resistance, oil resistance, and abrasion performance. We have served markets across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more, demonstrating our commitment to excellence.
Why Choose Hebei Speed Torque? We prioritize customer satisfaction by offering technical support, sample testing, and flexible order quantities. Whether you need a small trial order or a large-volume contract, we are ready to assist. Contact us today to discuss your requirements and experience the reliability of our oil resistant flat end wear resistant rubber hose.
Frequently Asked Questions (FAQ)
Q: What is the maximum working pressure of this hose?
A: The hose is rated for 1.0 MPa (145 psi) continuous working pressure, with a burst pressure of at least 4.0 MPa (580 psi).Q: Can this hose be used for diesel fuel transfer?
A: Yes, the NBR inner tube is resistant to diesel, gasoline, and other petroleum-based oils.Q: Is the hose suitable for outdoor use?
A: The outer cover provides UV resistance and ozone resistance, making it suitable for outdoor applications. However, prolonged extreme UV exposure may require additional protection.Q: What lengths are available?
A: Standard lengths are 20m, 50m, and 100m per roll. Custom lengths can be produced upon request.Q: Do you offer samples for testing?
A: Yes, we can provide sample lengths (usually 1 meter) for customer evaluation. Please contact our sales team for details.Q: What is the minimum order quantity?
A: MOQ is typically 100 meters for standard sizes, but smaller orders may be accommodated for first-time customers.Q: How does the flat end design benefit installation?
A: The smooth flat end allows for easier insertion into fittings and reduces the risk of leaks compared to hoses with rough cut ends.Q: Is the hose certified?
A: Our production facility is ISO 9001 certified, ensuring consistent quality management. The hose itself meets relevant industrial standards for oil resistance and pressure.
