Help CenterFiberglass Cable Tray for Wastewater Treatment Plant, UV Resistant, Lightweight, Easy Installation, 2m Length
Product Spotlights
Related Products
-
FRP Fiberglass Cable Tray, UL 94 V-0 Flame Retardant, 100x50mm, 3000mm Length, Lightweight Corrosion ResistantNegotiableMOQ: 300 Pieces -
Fiberglass Cable Tray, 3.0mm Thickness, 6m Long, Working Temperature -40°C to +130°C, High Load Capacity 150kg/mNegotiableMOQ: 300 Pieces
-
Fiberglass Reinforced Plastic Cable Tray, NEMA Type 12, 600mm Wide, 100mm Height, UV Stabilized for Outdoor UseNegotiableMOQ: 300 Pieces
-
Fiberglass Cable Tray for Oil & Gas Industry, Corrosion-Proof, 1000mm Wide, Heavy Duty, 1 Year WarrantyNegotiableMOQ: 300 Pieces
-
Molded Fiberglass Cable Tray, Fire Retardant Class A, 300mm Width, 50mm Depth, With Cover and Splice PlatesNegotiableMOQ: 300 Pieces
Hengshui Ruibin New Materials LLC, a manufacturer established in 2019 with a factory spanning 1,000-3,000 square meters and an annual export value of US$2.5-5 million, proudly presents our Fiberglass Cable Tray for Wastewater Treatment Plants. Designed specifically for harsh environments, this tray offers exceptional UV resistance, lightweight construction, and easy installation. With a standard length of 2 meters, it provides a reliable and cost-effective solution for cable management in water treatment facilities.
Our product is engineered to withstand the corrosive conditions of wastewater plants, eliminating the risk of rust and degradation common in metal trays. The UV-resistant formulation ensures long-term performance even under direct sunlight, while the lightweight nature (approximately 2-5 kg/m depending on size) reduces structural load and simplifies handling. Below we detail the key features and technical specifications.
Key Features & Benefits
- UV Resistant: Special additives protect against UV degradation, ensuring 20+ years of service life in outdoor installations.
- Lightweight: Up to 70% lighter than steel trays, reducing transportation costs and labor requirements.
- Easy Installation: Pre-drilled holes and snap-fit connectors allow quick assembly without specialized tools.
- Corrosion Proof: Fiberglass Reinforced Plastic (FRP) is impervious to acids, alkalis, and moisture common in wastewater treatment.
- Fire Retardant: Optional fire-retardant grade available upon request to meet safety standards.
- Customizable Dimensions: Widths from 100mm to 600mm and heights from 50mm to 150mm can be tailored to your project.
- Low Maintenance: No need for painting, galvanizing, or other protective coatings.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | Fiberglass Reinforced Polyester (FRP) |
| Standard Length | 2 meters |
| Width Range | 100mm – 600mm (customizable) |
| Height Range | 50mm – 150mm (customizable) |
| Weight per Meter | Approx. 2 – 5 kg (depending on size) |
| Load Capacity | Light to medium duty (up to 75 kg/m) Higher loads available upon request |
| UV Resistance | Excellent (with UV stabilizers) |
| Operating Temperature | -40°C to +80°C |
| Color | Gray (standard), Green/Optional available |
| Certification | ISO9001, ISO9000 |
Why Choose Our Fiberglass Cable Tray?
- Superior Corrosion Resistance: Unlike steel or aluminum trays, our FRP tray will not rust or corrode in the aggressive chemical environment of wastewater treatment plants.
- UV Stability: The built-in UV inhibitors prevent yellowing, cracking, and loss of strength, ensuring the tray remains functional for decades.
- Lightweight Design: At only 2-5 kg per meter, it can be easily carried by one worker, reducing installation time by up to 40% compared to metal trays.
- Tool-Free Assembly: The snap-fit joining system and pre-punched slots allow for rapid installation without welding or drilling.
- Non-Conductive & Safe: Fiberglass is an electrical insulator, reducing the risk of short circuits and electrical hazards.
- Environmental Friendly: The production process is low-energy, and the material is 100% recyclable at end of life.
The 2-meter length is optimized for standard shipping and on-site handling, minimizing waste and cutting costs. Each tray is manufactured under strict quality control procedures in our 1,000-3,000 sqm factory in Hengshui, Hebei, China. With a team of 101-200 skilled employees and annual export value exceeding US$2.5 million, we have supplied fiberglass cable trays to projects across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East.
Backed by ISO9001 and ISO9000 certifications, our products meet international quality standards. We offer flexible customization options, including special widths, heights, colors, and fire-retardant grades. Our dedicated sales team provides prompt technical support and samples upon request.
Trust Hengshui Ruibin New Materials LLC for your next wastewater treatment project. Our UV-resistant, lightweight, and easy-to-install fiberglass cable trays are available for immediate shipment from Tianjin or Qingdao ports. Contact us today for a quote or to discuss your specific requirements!
Frequently Asked Questions (FAQ)
-
Q: Is this cable tray suitable for outdoor use in direct sunlight?
A: Yes, it is specifically designed with UV-resistant additives to withstand prolonged exposure to sunlight without degradation. -
Q: Can the tray be cut to custom lengths on site?
A: Absolutely. The fiberglass material can be cut with standard power tools (e.g., reciprocating saw or angle grinder) for non-standard lengths. -
Q: What is the maximum load capacity of a 2-meter tray?
A: For standard light-duty series, the safe load is up to 75 kg/m. Please contact us for heavy-duty options if required. -
Q: Does the tray come with all necessary accessories (covers, brackets, splices)?
A: Yes, we offer a full range of accessories including covers, mounting brackets, splice plates, and fasteners, all sold separately or as a package. -
Q: How does the price compare to steel or aluminum trays?
A: While initial material cost may be slightly higher, the total installed cost is often lower due to reduced labor, lighter weight, and zero maintenance over the long term. -
Q: What is the typical lead time for an order?
A: For standard 2m trays, lead time is 15-20 days after order confirmation. Custom sizes may require 25-30 days. -
Q: Is the tray resistant to chemicals like chlorine or sulfuric acid?
A: Yes, the FRP formulation is highly resistant to a wide range of chemicals commonly found in wastewater treatment, including chlorinated compounds and dilute acids. -
Q: Can you provide samples before bulk order?
A: Yes, we can offer free samples (shipping cost covered) for evaluation. Please contact our sales team.
