Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with a 1,000–3,000 m² factory and ISO9001/ISO9000 certified quality management, proudly presents our Durable FRP Grating Panels. These panels are engineered to deliver exceptional strength, corrosion resistance, and long service life in demanding industrial environments. With a 2-year warranty against defects and free samples available upon request, we invite you to experience the reliability of our fiberglass reinforced plastic grating firsthand.
Our FRP grating panels are manufactured using high-quality fiberglass and premium thermosetting resin, pultruded into a robust mesh structure. They offer a lightweight yet strong alternative to steel or aluminum gratings, making them ideal for chemical plants, offshore platforms, water treatment facilities, and food processing areas. The panels are UV-resistant, non-conductive, and slip-resistant, ensuring safety and durability in harsh conditions.
Key Features & Technical Specifications:
- High Load Capacity: Designed to withstand heavy loads up to 5000 kg/m² depending on the profile and thickness.
- Corrosion Resistance: Impervious to a wide range of chemicals, saltwater, and UV radiation – ideal for outdoor and marine applications.
- Lightweight: Only 30–40% of the weight of steel grating, reducing transportation and installation costs.
- Slip-Resistant Surface: Available with a gritted top surface (silica sand) for enhanced foot traction, meeting safety standards.
- Non-Conductive & Non-Magnetic: Safe for electrical environments and sensitive electronics.
- Low Maintenance: Does not rust, rot, or require painting – simply wash with water.
- Customizable: Panel sizes, thicknesses, colors, and resin types (polyester, vinyl ester, phenolic) can be tailored to your project.
- Easy Installation: Can be cut and drilled on-site using standard power tools; compatible with various support structures.
| Property | Value | Notes |
| Panel Thickness | 25 mm / 38 mm / 50 mm | Other thicknesses available upon request |
| Standard Panel Size | 1220 mm × 3660 mm | Custom sizes up to 3 m × 6 m |
| Load Capacity (Max) | 5000 kg/m² | Depends on span and profile |
| Weight per m² | ~18 – 35 kg | Based on thickness and resin |
| Resin Type | Polyester / Vinyl Ester / Phenolic | Select according to chemical exposure |
| Surface Finish | Gritted or Smooth | Gritted for anti-slip |
| Color Options | Yellow, Gray, Green, Red, Blue, Custom | Integral color – no fading |
| Operating Temperature | -40°C to +80°C (standard) | Higher temperature resins available |
Benefits to Your Business:
- Reduce total cost of ownership: no painting, no corrosion, minimal replacement.
- Enhance worker safety: slip-resistant, non-conductive, and fire-retardant options.
- Quick project turnaround: our factory runs 2 shifts with 101-200 experienced employees, ensuring timely delivery.
- Global logistics: shipped from Port of Tianjin or Port of Qingdao to North America, South America, Europe, Africa, and more.
- Risk-free trial: request a sample to test the quality before bulk order.
We at Hengshui Ruibin New Materials LLC have been serving international markets since 2019, with an annual export value of US$2.5–5 Million. Our products are ISO9001/ISO9000 certified, and we have a dedicated quality control team that inspects every batch. Our factory spans 1,000–3,000 square meters with modern pultrusion lines, allowing us to produce over 200,000 m² of FRP grating annually. We have successfully supplied projects in Eastern Europe, Southeast Asia, the Middle East, and the Americas. With a 2-year warranty against defects and a responsive after-sales service, you can confidently choose our FRP grating panels for your next project. Contact us today for a free sample and a competitive quotation.
Frequently Asked Questions (FAQ):
-
Q: What is the typical lifespan of FRP grating panels?
A: Under normal industrial conditions, our FRP grating panels can last 15–25 years, depending on the resin type and exposure environment. The 2-year warranty covers material and workmanship defects. -
Q: Can the grating be used in chemical environments?
A: Yes. We offer different resin systems: standard polyester for general use, vinyl ester for strong acids/alkalis, and phenolic for fire resistance. Please specify your chemical exposure when ordering. -
Q: How do I install FRP grating panels?
A: The panels can be cut to size using a circular saw with a carbide blade. They are typically fastened with stainless steel clips, bolts, or adhesive. Installation is similar to metal grating but much lighter. -
Q: What is the maximum load capacity?
A: Load capacity depends on panel thickness, span distance, and grid design. For example, a 38 mm thick panel with a 600 mm span can support over 3000 kg/m². We provide load tables for your specific configuration. -
Q: Are samples really free?
A: Yes, we provide free samples (typically 200×200 mm) for evaluation. You only need to cover the shipping cost, which can be arranged via your preferred courier or we can quote DDP. -
Q: What colors are available?
A: Standard colors are yellow, gray, green, and red. Custom colors (RAL codes) are available with a minimum order quantity. The color is integral to the resin, so it won't peel or fade. -
Q: Do you have certifications?
A: Our factory is ISO9001 and ISO9000 certified. We can provide a certificate of conformity with each shipment. For specific industry certifications, please inquire. -
Q: What is the minimum order quantity?
A: For standard sizes, MOQ is 50 m². For custom colors or special resins, MOQ is 100 m². Sample orders are always welcome.
