Home > Industrial Equipment & Components > Other Equipment & Components > Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection thumbnail-3

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection thumbnail-4

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection thumbnail-5

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection photo-1

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection photo-2

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection photo-3

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection photo-4

Split Gear Ring Offering Technical Support, 12 Months Warranty, 100% Dimensional Inspection photo-5

Product Spotlights

Split gear ring with 12-month warranty and 100% dimensional inspection. Easy split design reduces installation downtime. Customizable materials, modules, and heat treatment. Technical support from experienced engineers. Suitable for mining, cement, and heavy machinery. Available from Henan San Kuang Machinery with ISO certifications.

US$ 1000 ≥1 Piece

Key Specifications

Get Latest Price

Material:

Alloy Steel / Carbon Steel (customizable)

Module:

1-50 (customizable)

Number of Teeth:

12-200 (customizable)

Contact Supplier Request Quote Chat Now

Henan San Kuang Machinery Technology Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao|tianjin

Delivery Detail:

30 days

Product Details
Company Profile
Contact Us

Material Alloy Steel / Carbon Steel (customizable)

Module 1-50 (customizable)

Number of Teeth 12-200 (customizable)

Outer Diameter 100-5000 mm (customizable)

Heat Treatment Quenching & Tempering / Carburizing / Nitriding

Application Mining / Cement / Power Generation / Heavy Machinery

Surface Treatment Phosphating / Painting / Galvanizing (optional)

Warranty 12 Months

Inspection 100% Dimensional Inspection

Certification ISO 9001 / ISO 14000 / OHSAS 18001 (available)

Henan San Kuang Machinery Technology Co., Ltd., established in 2014 with a factory spanning 10,000-30,000 square meters, is proud to offer our Split Gear Ring designed for heavy-duty industrial applications. Our split gear rings combine precision engineering with robust technical support, backed by a 12-month warranty and 100% dimensional inspection to ensure every component meets exacting standards. Whether you need a replacement part for a crusher, mill, or conveyor system, our split design simplifies installation and maintenance, reducing downtime and operational costs.

Key Features & Technical Specifications

Split Design for Easy Installation: The ring gear is split into two or more segments, allowing for quick assembly around existing shafts without removing adjacent components. This feature significantly reduces installation time and labor costs.
High-Strength Material Options: Manufactured from high-grade alloy steel or carbon steel, with optional heat treatments such as quenching and tempering, carburizing, or nitriding to enhance wear resistance and fatigue life. Custom material grades are available upon request.
Precision Machining: Our CNC gear hobbing and grinding processes ensure AGMA Class 8-10 accuracy, providing smooth operation and minimal noise even under heavy loads.
100% Dimensional Inspection: Every split gear ring undergoes a complete dimensional check using calibrated instruments, including tooth profile, pitch, runout, and bore diameter. A detailed inspection report is provided with each shipment.
12-Month Warranty: We stand behind our product quality with a full 12-month warranty against manufacturing defects. In the unlikely event of a problem, our technical team provides prompt support and replacement.
Customizable Options: Available in a wide range of modules, tooth counts, outer diameters, and bore sizes. Surface treatments like phosphating, painting, or galvanizing are optional for corrosion resistance.

Typical Technical Parameters (Sample)

Parameter	Range / Value
Module	1 – 50 (customizable)
Number of Teeth	12 – 200
Outer Diameter	100 – 5000 mm
Bore Diameter	50 – 2000 mm (custom)
Face Width	50 – 800 mm
Material Hardness	HB 200 – 600 / HRC 40 – 58 (after heat treatment)
Accuracy Grade	AGMA Class 8 – 10

Advantages for Your Business

Reduced Downtime: The split design allows replacement without dismantling whole assemblies, cutting maintenance time by up to 50% compared to solid rings.
Cost-Effective: Lower shipping and handling costs due to segmented construction, and longer service life thanks to premium materials and heat treatment.
Reliable Performance: With 100% dimensional inspection, every gear ring meets your exact specifications, ensuring consistent power transmission and minimal vibration.
Technical Support: Our team of experienced engineers provides free technical support during installation and operation, helping you achieve optimal performance.

Our split gear rings are widely used in mining, cement, power generation, and heavy machinery industries. They are designed to fit equipment from major OEMs such as Metso, Sandvik, FLSmidth, and others, or can be manufactured to your custom drawings.

Why Choose Henan San Kuang Machinery Technology Co., Ltd.?

With 51-100 skilled employees and an annual export value of US$2.5 – 5 million, we have established a strong presence in markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and Asia. Our factory is located in Luoyang, Henan, China – a city renowned for its heavy machinery manufacturing base. We ship through major ports including Shanghai, Lianyungang, Qingdao, and Tianjin, ensuring timely delivery worldwide.

We hold multiple certifications such as ISO 9001, ISO 14000, OHSAS 18001, and others, demonstrating our commitment to quality, environment, and occupational health. Our 100% dimensional inspection and 12-month warranty give you peace of mind. Contact us today for a quote or technical consultation – we are ready to support your split gear ring needs.

Frequently Asked Questions (FAQ)

Q: What is the typical lead time for a split gear ring?
A: Standard lead time is 30-45 days after drawing approval. For urgent orders, express delivery can be arranged within 20-25 days.
Q: Can you manufacture split gear rings according to customer drawings?
A: Yes, we accept custom designs. Please provide the drawing or specifications, and our engineers will review and confirm the feasibility.
Q: How do you ensure the split gear ring aligns correctly after installation?
A: Each segment is precision-machined with aligning dowel holes and bolting flanges. We also provide alignment instructions and technical support.
Q: What materials are available for the split gear ring?
A: Common materials include 42CrMo, 40Cr, 35CrMo, and cast steel. We can also use special alloys upon request. Heat treatment options are customized to your application.
Q: Do you offer a warranty?
A: Yes, we provide a 12-month warranty against manufacturing defects. In case of any issue, we will replace the product or provide a refund.
Q: Is the 100% dimensional inspection report included?
A: Yes, a detailed inspection report with measurements is provided with each shipment for your quality assurance.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 piece for standard sizes. For custom dimensions, please contact our sales team for negotiation.
Q: How do you ship the split gear ring?
A: We pack the segments in plywood cases or steel frames, suitable for sea or air freight. Each segment is individually protected to prevent damage during transit.
