Help CenterSplit Gear Ring for Agricultural Machinery Gearboxes, 16 Teeth, 5 Module, 1045 Carbon Steel
Product Spotlights
Related Products
-
Precision Ground Split Gear Ring, 40Cr, 6 Module, 18 Teeth, 0.01mm Runout ToleranceUS$ 1000MOQ: 1 Piece -
Split Gear Ring Used in Packaging Machine Drive Systems, 42CrMo Alloy, 12 Teeth, 6 ModuleUS$ 1000MOQ: 1 Piece
-
Induction Hardened Split Gear Ring, 45 Steel, Surface Hardness HRC 50-55, 30 Teeth, 8 ModuleUS$ 1000MOQ: 1 Piece
-
304 Stainless Steel Split Gear Ring for Corrosive Environments, 0.5mm Tolerance, 100mm ODUS$ 1000MOQ: 1 Piece
-
Split Gear Ring for Speed Reducers, 20MnCr5 Steel, 8 Module, 40 Teeth, 250mm ODUS$ 1000MOQ: 1 Piece
As a leading manufacturer from Henan San Kuang Machinery Technology Co., Ltd., established in 2014, we specialize in producing high-quality split gear rings for agricultural machinery gearboxes. Our 16-tooth, 5-module split gear ring, crafted from premium 1045 carbon steel, delivers exceptional durability and precise torque transmission, ensuring your equipment operates smoothly under heavy loads. Designed for easy installation and maintenance, this split gear ring is a reliable replacement or upgrade part for various agricultural gearboxes, including tractors, harvesters, and tillers.
Our manufacturing expertise spans over 10,000 square meters of factory space, and we have a dedicated team of 51-100 employees. Each split gear ring is produced using advanced CNC machining and heat treatment processes, guaranteeing consistent quality and dimensional accuracy. The 1045 carbon steel material provides excellent wear resistance and strength, making it ideal for demanding agricultural applications.
Key Features & Technical Specifications
- Material: 1045 medium carbon steel – high strength and good wear resistance, suitable for heavy-duty gearbox applications.
- Teeth Count: 16 teeth – designed for specific gear ratios in agricultural machinery.
- Module: 5 – standard metric module, ensuring compatibility with common gearbox systems.
- Split Design: Allows for easy installation and removal without disassembling the entire shaft, reducing downtime.
- Precision Machining: Tolerances within ISO standard, ensuring smooth meshing and low noise operation.
- Heat Treatment Options: Quenching and tempering available to achieve desired hardness (e.g., 45-50 HRC).
- Custom Surface Finish: Black oxide, phosphating, or as per customer request for corrosion resistance.
- Application: Agricultural gearboxes in tractors, combine harvesters, rotary tillers, and other farm machinery.
| Parameter | Value |
|---|---|
| Material Grade | 1045 Carbon Steel |
| Number of Teeth | 16 |
| Module | 5 |
| Outer Diameter (approx.) | 90 mm (based on module & teeth) |
| Inner Diameter (split) | Customizable – typically 30-50 mm |
| Hardness (after heat treatment) | 45-50 HRC (optional) |
| Surface Finish | Black oxide / phosphating / as per request |
| Packaging | Wooden cases, cartons, or pallets |
Advantages & Customer Benefits
- Easy Installation: The split design eliminates the need to remove bearings or shafts, saving up to 50% installation time compared to solid rings.
- Cost-Effective: 1045 carbon steel offers an excellent balance of strength and cost, making it a budget-friendly solution without sacrificing performance.
- Long Service Life: Proper heat treatment and precision machining reduce wear, extending the gear ring's lifespan under harsh agricultural conditions.
- Compatibility: Standard 5 module and 16 teeth fit many common gearbox models; we can also produce custom dimensions.
- Reliable Supply: With annual export value of US$2.5-5 million, we ensure stable production and timely delivery from ports like Shanghai, Qingdao, etc.
Our split gear ring is widely used in agricultural gearboxes across North America, South America, Europe, Southeast Asia, Africa, and Oceania. We have obtained multiple certifications including ISO9001, ISO14000, OHSAS18001, and others, ensuring strict quality control from raw material to finished product.
Trust & Reliability
Since 2014, Henan San Kuang Machinery Technology Co., Ltd. has grown into a trusted partner for global agricultural machinery manufacturers. Our factory spans 10,000-30,000 square meters, housing advanced production lines and a skilled workforce of 51-100 employees. With an annual export value of US$2.5 million to US$5 million, we serve diverse markets including domestic and international regions. Our quality management system is certified to ISO9001, ISO14001, OHSAS18001, and additional standards, reflecting our commitment to excellence. We also offer flexible customization options for heat treatment, surface finish, and dimensions to meet your specific requirements.
Partner with us for reliable split gear rings that keep your agricultural machinery running efficiently. Contact our sales team today for a quote or technical consultation. We look forward to supporting your business with high-quality components and professional service.
Frequently Asked Questions (FAQ)
- What is the material of this split gear ring? It is made of 1045 carbon steel, offering good strength and wear resistance. Heat treatment is optional to achieve higher hardness.
- What are the exact dimensions of the gear ring? The outer diameter is approximately 90 mm (based on module 5 and 16 teeth). Inner diameter and width can be customized; please provide your shaft size.
- Can I get a sample before mass production? Yes, we provide samples for evaluation. Sample lead time is about 7-15 days depending on customization.
- Is the split gear ring easy to install? Absolutely. The split design allows you to clamp it around the shaft without removing other components, significantly reducing downtime.
- What surface treatments are available? We offer black oxide, phosphating, or other finishes upon request. Standard product comes with a clean mill finish.
- Do you have any quality certifications? Yes, we are certified to ISO9001, ISO14001, OHSAS18001, and other standards. Detailed certificates can be provided upon request.
- What is the minimum order quantity (MOQ)? MOQ is typically 50 pieces for standard sizes, but we can negotiate for smaller quantities or custom orders.
- How do you ensure the gear ring fits my gearbox? We recommend sending your gearbox specifications or a drawing. Our engineers can verify compatibility and adjust dimensions if needed.
