Help CenterDC250-350V 300W Laser Power Supply for Combined Beam Laser Generator on Mobile Laser Equipment
Product Spotlights
Comprehensive Safety Protection: Features short-circuit, open-circuit, and laser tube damage protection to safeguard operators and equipment.
Wide Voltage Compatibility: Supports AC 180-260V and DC 280-350V input ranges for stable performance across diverse power environments.
Related Products
-
High Power 600W Folded CO2 Laser Tube for CO2 Laser Knife CuttingNegotiableMOQ: 20 Units -
1064nm 600W 4PCS Folded CO2 Laser Tube With Metal Case for Laser Die CuttingNegotiableMOQ: 20 Units
-
Reci W1 1110mm 70-90 Watt CO2 Laser TubeNegotiableMOQ: 20 Units
-
Fast Engraving Min 90W Max 100W Reci W2 CO2 Laser Tube/LampNegotiableMOQ: 20 Units
-
Factory Sell 80 Watt CO2 Laser Power Supply/High Voltage CO2 Laser PSU/CO2 Tube Driving Power SupplyNegotiableMOQ: 20 Units
RUBYLASER 150W LASER POWER SUPPLY
1.It can support input voltages of AC180-260V or DC 280-350V.
2. It has light weight and small size characteristics, which is easily used on mobile vehicles.
3. It has CO2 laser tube damage protection. If the laser tube is damaged, power supply will not output current which protects the operator.
4. It has enhanced short-circuit protection and open circuit protection. In short circuit status, the power supply is in a protected condition and stop works. In an open circuit status, the power supply doesn't output high voltage and the laser tube does not work at all.
Product Details
•Wide Input Voltage Compatibility
Supports AC 180–260V and DC 280–350V input ranges, ensuring stable performance across diverse power environments.
•Compact & Lightweight Design
Engineered with a small footprint and low weight, making it ideal for integration into mobile or space-constrained equipment.
•CO2 Laser Tube Protection
Built-in tube-damage protection ensures no output current is delivered when the laser tube fails, safeguarding operators and connected devices.
•Enhanced Short-Circuit & Open-Circuit Protection
Short-circuit conditions trigger automatic shutdown to protect the unit. In open-circuit status, the power supply outputs no high voltage, preventing unintended laser emission.
•High Compatibility with 150W CO2 Laser Tubes
Fully capable of driving standard 150W sealed glass CO2 laser tubes. Dual ZS-L150W-Y units can support 300–350W combined-beam or folded CO2 laser configurations.
•Optional 90–270V Voltage Stabilization
Available voltage-stabilization function maintains output stability under fluctuating input conditions.
•Optional Current Adaptive Function
With one-button operation, the output current automatically adjusts to match the laser tube's optimal working current and remains consistent.
•Silicon-Carbide Technology
Replaces traditional rectifier diodes with SiC components for lower heat generation and reduced failure rates, delivering high durability in high-temperature and humid environments. Standard warranty: one year.
•Stable Output Performance
SiC-based design simplifies circuit architecture and enhances consistency of output parameters, contributing to superior cutting and engraving quality.
•Flexible Power Control Interface
Supports both 0–5V analog control and PWM control for precise output power regulation.
•Robust Grounding Protection
Comprehensive grounding design ensures safe and reliable operation for industrial users.
•Optimized Terminal & Mechanical Design
Utilizes H/L/P/G/IN/5V green terminal blocks for laser control signals. The aluminum housing provides excellent ventilation and heat dissipation.
•Reliable Signal Compatibility
Simple, dependable terminal control supports high- and low-level signals. TTL input enables accurate laser on/off control. An additional protection switch monitors water-through status to prevent abnormal operation.
•Automated SMT Production
Manufactured on fully automated SMT lines with high-definition optical inspection for circuit boards, components, and soldering quality, minimizing human-induced defects.
•Custom 180W Version Available
A 180W CO2 laser power supply can be customized according to the buyer's specific technical requirements.
Specification | ||
Input |
Input voltage |
AC180-260V or DC 280-350V±10% (AC110V specified while order) |
AC frequency |
47~440HZ |
|
Maximum input power |
1000W |
|
Maximum input current |
4.5A |
|
Output |
Maximum output voltage |
50KV |
Maximum output current |
45mA |
|
Efficiency |
More than 90% (Full load) |
|
Response speed |
Less than 1ms |
|
Control interface |
TTL multilevel switching control, effective level can be high and low selection (see control wining diagram) |
|
Insulation |
input-output |
AC 1500V 1 minutes not more than 10mA |
input-shell |
AC 1500V 1 minutes not more than10mA |
|
Output-shell |
Connection |
|
Open Circuit Protection |
Can be short circuit (requires a good grounding shell, while avoiding the positive electrode and the shell between the arc) |
|
Environmental Requested |
Working temperature |
-10ºC~50ºC |
Relative Humidity |
Maximum 85%RH (non-condensing) |
|
Dimensions (LxWxH) |
350mmx123mmx56mm |
|
