As a trusted manufacturer since 1998, Anping County Boli Hardware Wiremesh Products Factory proudly presents our 1 Year Warranty Stainless Steel Thermal Storage Tank. Engineered for durability and thermal efficiency, this tank is crafted from premium stainless steel and comes with a Mill Test Report to guarantee material integrity. Our tank fully complies with international standards, ensuring reliable performance for commercial and industrial thermal storage applications. Whether you need a buffer tank for solar heating, a hot water storage vessel for district heating, or a process tank for manufacturing, our solution offers exceptional value backed by two decades of manufacturing expertise.
The tank is designed with a sturdy stainless steel inner shell and an optional insulation layer (polyurethane foam or rock wool) to minimize heat loss. Every unit undergoes rigorous quality control checks, and we provide a Mill Test Report to verify the chemical composition and mechanical properties of the steel. Our standard compliant design ensures compatibility with local pressure vessel regulations, and we offer customization options to meet your specific capacity, pressure, and connection requirements.
Key Features & Technical Specifications
- Premium Stainless Steel Construction – Made from 304 or 316L stainless steel, providing excellent corrosion resistance and long service life.
- Mill Test Report Included – Each tank is supplied with a material traceability certificate, confirming compliance with relevant standards.
- High Thermal Efficiency – Optional insulation layers (50-100mm polyurethane foam or rock wool) reduce standby heat loss by up to 30%.
- Standard Compliant Design – Manufactured in accordance with ASME, EN, or GB150 standards (depending on customer requirement).
- 1 Year Warranty – Coverage against manufacturing defects, giving you peace of mind.
- Wide Capacity Range – Available from 500L to 10,000L, with custom sizes upon request.
- Multiple Connection Options – Flanged or threaded inlet/outlet ports, with optional heating/cooling coils.
- Pressure Rated – Working pressure from 0.6 MPa to 1.6 MPa, with higher pressure ratings available for special applications.
Technical Parameters (Reference Table)
| Parameter | Standard Value | Customizable |
|---|---|---|
| Material Grade | 304 / 316L | Yes (e.g., 321, 310S) |
| Capacity | 500L – 10,000L | Up to 50,000L |
| Working Pressure | 0.6 MPa – 1.6 MPa | Up to 4.0 MPa |
| Design Temperature | -20°C to 120°C | Higher temperature available |
| Insulation Thickness | 50mm / 80mm / 100mm | Yes |
| Surface Finish | 2B (standard) | BA, Hairline, Mirror |
| Connection Type | Flanged (ANSI/DIN) | Threaded, Tri-clamp |
Benefits for Your Business
- Energy Savings – The high-quality insulation reduces heat loss, lowering your operational energy costs.
- Long Service Life – Stainless steel resists rust and scaling, ensuring decades of reliable service without frequent replacement.
- Regulatory Compliance – Our standard compliant design helps you meet local codes and pass inspections with ease.
- Reduced Maintenance – Smooth internal surfaces minimize scale buildup, and the tank is easy to clean.
- Flexible Integration – Multiple port configurations allow easy connection to existing piping, heat exchangers, or solar collectors.
Trust Our Manufacturing Heritage
Founded in 1998, Anping County Boli Hardware Wiremesh Products Factory has been a reliable manufacturer for over 25 years. Our annual export value exceeds US$5 million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery worldwide. Each thermal storage tank is backed by our 1 Year Warranty and comes with a comprehensive Mill Test Report for full material traceability. Our team of experienced engineers can also customize the tank to your exact specifications, including pressure rating, insulation type, and connection dimensions. We invite you to experience the quality and dedication that has made us a trusted partner for global buyers. Contact us today for a quote or to discuss your project requirements.
Frequently Asked Questions (FAQ)
-
Q: What certifications are included with the tank?
A: Each tank comes with a Mill Test Report (MTR) that certifies the chemical composition and mechanical properties of the stainless steel. The tank is designed to comply with common international standards such as ASME, EN, or GB150, depending on your requirements. If you need specific third-party certification, please let us know and we can arrange it as an optional service. -
Q: Can I get a higher working pressure than 1.6 MPa?
A: Yes, we can customize the tank for working pressures up to 4.0 MPa. Please provide your required pressure and design temperature, and our engineering team will design the tank accordingly. -
Q: What insulation material is used? Is it environmentally friendly?
A: We offer polyurethane foam (PUF) and rock wool as insulation options. Both are effective and safe. PUF has excellent thermal performance, while rock wool is fire-resistant. We can also use eco-friendly materials upon request. -
Q: How long does the warranty cover, and what does it include?
A: The warranty is valid for 1 year from the date of shipment. It covers manufacturing defects in materials and workmanship. Normal wear and tear, misuse, or unauthorized modifications are not covered. We provide full support for any warranty claims. -
Q: What is the typical lead time for a standard tank?
A: For standard capacities (500L – 3000L), lead time is approximately 15–20 working days after order confirmation. For larger or custom tanks, lead time may be 25–40 working days, depending on the complexity. -
Q: Can you provide samples or a small quantity first?
A: Yes, we accept trial orders for small quantities. However, due to the manufacturing process, the minimum order quantity for custom tanks is typically 1 piece. Standard tanks can be ordered in single units. -
Q: What payment terms do you accept?
A: We accept T/T, L/C, and other common payment methods. For new customers, we usually require 30% deposit and 70% balance before shipment. -
Q: How do you ensure the quality before shipment?
A: Every tank undergoes a hydrostatic pressure test, visual inspection, and dimensional check. We also provide photos and videos upon request. The Mill Test Report is included with each shipment for material traceability.
