Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. — a trusted manufacturer since 2015, with a 10,000–30,000 m² factory and annual export value exceeding US$10 million. Our Compact ZLD Water Treatment System is engineered to help industries achieve zero liquid discharge while minimizing footprint and operational costs. This system comes with a 1-year warranty and free installation support, ensuring you receive a reliable, turnkey solution for your wastewater challenges.
Designed for industrial wastewater recycling, this compact ZLD system combines advanced membrane technology and thermal evaporation to recover up to 99% of water, leaving only dry solids. It is ideal for sectors such as chemicals, pharmaceuticals, textiles, food processing, and power generation. Below, we detail its key features, technical specifications, and the tangible benefits it brings to your operations.
Key Features
- Compact Design: Space-saving modular structure allows easy integration into existing facilities, reducing installation footprint by up to 40% compared to traditional ZLD systems.
- Zero Liquid Discharge: Achieves complete water recovery, eliminating wastewater discharge and helping you comply with strict environmental regulations.
- Energy Efficient: Incorporates intelligent heat recovery and low-energy membrane processes, lowering operational costs by 15–30%.
- 1-Year Warranty: Full coverage on parts and labor, giving you peace of mind.
- Free Installation Support: Our team provides on-site guidance and remote assistance to ensure smooth commissioning.
- Automated Operation: PLC-based control system with touchscreen interface, enabling real-time monitoring and minimal manual intervention.
- Robust Construction: Made from corrosion-resistant materials (stainless steel 316L or duplex), suitable for harsh industrial environments.
- Customizable Capacity: Available in standard models from 1 m³/day to 100 m³/day; larger capacities on request.
Technical Specifications
| Parameter | Value |
|---|---|
| Feed Water TDS | Up to 50,000 mg/L |
| Recovery Rate | ≥ 98% |
| Power Consumption | 3.5–7.5 kWh/m³ (depending on TDS) |
| Operating Temperature | 10–45°C |
| Dimensions (L×W×H) | 2.5m × 1.8m × 2.2m (for 10 m³/day model) |
| Weight | Approx. 2,800 kg |
| Warranty | 1 Year (parts & labor) |
Client Benefits: By choosing our Compact ZLD System, you gain regulatory compliance, reduced water purchase costs, and lower waste disposal fees. The free installation support ensures your team quickly learns to operate the system, while the 1-year warranty protects your investment.
Why Choose Qingdao Conqinphi?
We are a certified manufacturer with ISO9001, ISO14000, OHSAS18001, HACCP, and many other international standards. Our factory spans 10,000–30,000 m² and employs 201–300 skilled workers. With an annual export value of US$10–50 million, we have supplied ZLD systems to clients across North America, Europe, Southeast Asia, the Middle East, and more. Our products are shipped from Qingdao Port, ensuring efficient logistics worldwide.
Don't let wastewater challenges slow your production. Our Compact ZLD Water Treatment System with 1-year warranty and free installation support is the cost-effective, reliable solution you need. Contact us today for a customized quote and technical proposal.
Frequently Asked Questions
-
What is the typical payback period for this ZLD system?
Depending on water cost and disposal fees, most clients see ROI within 2–3 years due to water reuse and reduced waste volume. -
Can the system handle high-salinity wastewater?
Yes, it can treat feed water with TDS up to 50,000 mg/L. For higher TDS, we offer customized pre-treatment options. -
What does the free installation support include?
Our engineers provide remote guidance, on-site supervision (if required), and training for your operators. Travel expenses may apply for on-site visits outside China. -
Is the system easy to maintain?
Yes, the modular design allows easy access to membranes and pumps. We also provide a comprehensive maintenance manual and spare parts list. -
Does the warranty cover consumables like membranes?
The 1-year warranty covers defects in materials and workmanship for non-consumable parts. Membranes are covered for 6 months under normal usage. -
What certifications does your company hold?
We are certified to ISO9001, ISO14000, OHSAS18001, HACCP, and more. Full details are available upon request. -
Can you customize the system for my specific industry?
Absolutely. We have experience in chemical, pharmaceutical, textile, food & beverage, and oil & gas sectors. Just provide your water analysis and capacity requirements. -
How long does delivery take?
Standard models are shipped within 30–45 days after order confirmation. Customized systems may require 60–90 days.
