Rectangular Steel Grating, 40x100mm, 3mm Thick, Standard Compliant, Load Bearing 3kN/m²
Product Spotlights
Rectangular steel grating 40x100mm, 3mm thick, load bearing 3kN/m². Standard compliant, customizable dimensions and surface treatments. Ideal for walkways, platforms, and drainage covers. Factory direct from Anping Xinye, ensuring quality and competitive pricing.
Negotiable
MOQ: 50 Cubic Centimeters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Steel (Q235 or equivalent)
Bar Spacing:
40mm × 100mm
Thickness:
3mm
Payment & Shipping
Payment Methods:
Port of Shipment:
china
Delivery Detail:
7 days
Related Products
-
Welded Steel Grating, 100x50mm Flat Bar, 5mm Thick, Hot Dip Galvanized, Mill Test ReportNegotiableMOQ: 50 Cubic Centimeters -
Steel Grating for Industrial Catwalk and Platform, Anti-Slip Design, Heavy Load SupportNegotiableMOQ: 50 Cubic Centimeters
-
Durable Steel Grating for Drainage Cover and Trench Gate, 40x40mm Mesh, 5mm ThickNegotiableMOQ: 50 Cubic Centimeters
-
Factory Direct Steel Grating, Technical Support, Quick Delivery, 100% Mill Test ReportNegotiableMOQ: 50 Cubic Centimeters
-
304 Stainless Steel Steel Grating 25x3mm Welded Platform for Load Capacity 4kN/m2NegotiableMOQ: 50 Cubic Centimeters
Material
Steel (Q235 or equivalent)
Bar Spacing
40mm × 100mm
Thickness
3mm
Load Capacity
3kN/m²
Surface Treatment
Galvanized, Painted, or Plain (customizable)
Shape
Rectangular
Application
Industrial platforms, walkways, drainage covers
Standard Compliance
Industry standard compliant (details available upon request)
From the factory of Anping Xinye Metal Wire Mesh Products Co., Ltd, we present our Rectangular Steel Grating with dimensions of 40x100mm and a thickness of 3mm. Designed to meet industry standards for load bearing, this grating supports a rated load of 3kN/m², making it a reliable choice for various industrial and commercial applications. Our manufacturing expertise ensures consistent quality, precise dimensions, and durable performance.
Key Features & Technical Specifications
- Rectangular Pattern: The 40x100mm grid spacing provides optimal balance between strength and visibility, ideal for walkways, platforms, and drainage covers.
- 3mm Thickness: Each bearing bar is 3mm thick, offering a robust structure that can withstand heavy foot traffic and light industrial loads.
- Load Capacity 3kN/m²: Tested to support a uniform load of 3 kilonewtons per square meter, suitable for pedestrian walkways, maintenance platforms, and mezzanines.
- Standard Compliant: Manufactured according to industry standards (e.g., equivalent to EN 1161 or similar), ensuring safety and reliability.
- Customizable Surface Treatment: Available in hot-dip galvanized, painted, or plain steel finish to match your environmental requirements.
- Durable Material: Made from high-quality steel (typically Q235 or equivalent), with optional stainless steel upon request.
Technical Parameters Table
| Parameter | Value |
|---|---|
| Bar Spacing (center to center) | 40mm × 100mm |
| Bearing Bar Thickness | 3mm |
| Load Rating | 3 kN/m² |
| Standard Panel Size | Customizable (e.g., 1000mm x 6000mm) |
| Material | Steel (Q235, SS304, etc.) |
| Surface Finish | Galvanized, Painted, or Plain |
Benefits for Your Application
- Safety: The anti-slip surface and open grid design reduce the risk of slipping and allow water, debris, and light to pass through.
- Cost-Effective: Lightweight yet strong structure reduces transportation and installation costs without compromising performance.
- Easy Installation: Panels can be cut, welded, or fixed with clips, saving time on site.
- Long Service Life: Hot-dip galvanized finish provides excellent corrosion resistance, extending product lifespan in harsh environments.
- Versatile: Suitable for indoor and outdoor use, including chemical plants, power stations, sewage treatment plants, and commercial buildings.
Trusted Manufacturing Partner
Based in Hengshui, Hebei, China, Anping Xinye Metal Wire Mesh Products Co., Ltd has been a reliable manufacturer and exporter of wire mesh and grating products for years. Our factory is equipped with advanced production lines, skilled workers, and strict quality control procedures. We have supplied steel gratings to clients in over 30 countries, with a monthly production capacity of 500+ tons. Our commitment to on-time delivery, competitive pricing, and customer satisfaction has built long-term partnerships with global buyers. We invite you to contact us for a quote or sample request. Experience the quality and service that sets us apart.
Frequently Asked Questions
-
Q: What is the standard panel size of the 40x100mm steel grating?
A: Standard panel sizes are customizable; common dimensions are 1000mm x 6000mm, but we can produce any size according to your requirements. -
Q: Can this grating be used for heavy-duty vehicle traffic?
A: This grating is rated for 3kN/m², which is suitable for pedestrian walkways and light industrial platforms. For heavy vehicle loads, we recommend consulting our team for a higher load capacity option. -
Q: What surface treatment options are available?
A: We offer hot-dip galvanized, painted (various colors), and plain (mill finish). For outdoor or corrosive environments, hot-dip galvanized is recommended. -
Q: Is the grating available in stainless steel?
A: Yes, stainless steel (SS304 or SS316) is available upon request, ideal for food processing, pharmaceutical, or marine applications. -
Q: Do you provide custom cutting or fabrication?
A: Absolutely. We can cut panels to your exact dimensions, add notches, or provide serrated bars for extra anti-slip performance. -
Q: What is the lead time for a typical order?
A: For standard sizes, lead time is 10-15 days after order confirmation. Custom orders may take 15-25 days depending on complexity. -
Q: How do you ensure the grating meets the load rating of 3kN/m²?
A: Our production follows strict quality control, including material testing and load testing samples. We can provide test reports upon request. -
Q: Can I get a sample before placing a bulk order?
A: Yes, samples are available. Please contact our sales team to arrange sample shipment (sample cost and freight apply).
