EDM DRILLING MACHINE
Type |
cnc703 |
|
1 |
Worktable Dimension |
700*400 |
2 |
Travels X×Y×Z |
500*400*（380+300） |
3 |
Max Load on Work Table |
250kg |
4 |
Max Pressure of Working Water |
6mpa |
5 |
Flume dimension |
700*480mm |
6 |
Max Work Current |
30A |
7 |
Electrode Diameter |
Φ0.2-Φ3.0mm |
8 |
Max Process Deep |
30-60mm/min（Φ1.0） |
9 |
Max Processing Speed |
300mm |
10 |
Max Diameter to Deep Ratio |
≥300 |
11 |
Workpiece Material |
Steel/Aluminum/Copper/Carbide and Various of Conductors |
12 |
Working Medium |
Tap water/Ion free water |
13 |
Machine Exernal Dimensions |
1000*950*1800mm |
14 |
Machine Weight |
950kg |
Ø Process deep holes of diameter from Ф0.15-Ф3mm rapidly.
Ø Servo control system realizes speedy motion.
Ø High accuracy movement by linear guides of Z，W axis.
Ø X,Y,Z ,W four axes adopt high accuracy ball screws for fast and agile movement.
Ø Guide Travels linear guide
Ø Fast approaching, quickly out of machining
Ø Three axes DRO with linear scales, auto depth control helps blind holes process.
Ø One touch, one hole made. (optional)
