CNC ELECTRIC SPARK WIRE CUT MACHING
Comprehensive characteristics
2、Main features of machine tools
1, support graphics-driven automatic programming, do not need to contact the code, only need to set the processing process of processing graphics, can be processed; Support a variety of wire-cutting software generated 3B code, G code and other processing code;
2, multiple processing methods can be flexibly combined processing (continuous, single-section, forward, reverse, backward and other processing methods)
3, XYUV 4 axis can be set to reverse, the driving motor can be set to five-phase ten-beat, three-phase six-beat, pulse-driven and other modes;
4, real-time monitoring of wire-cutting machine tool X, y, u, v Four-axis processing state;
5, processing preview, real-time display of machining process, 3-d tracking display during taper machining, magnify and reduce viewing graphics, observe machining situation from main view, left view, top view, etc
6, may carry on many times cuts, enhances the smooth degree.
7, with the user can maintain the process library function, so that multiple processing become simple and reliable.
8, taper workpiece processing, using four-axis linkage control technology, can be convenient for up and down the special-shaped surface processing, it can drive 4-axis motion control card and work stably and reliably.
9, it can support multi-card parallel work, one computer can control many wire cutting machines at the same time
10, with automatic alarm function, in the processing or failure automatically alarm, alarm time can be set;
11, support corner delay processing, in the processing track corner delay,
12, to support three processing modes: normal fast wire-walking mode, 3-bit code in wire-walking, in wire-walking oscillation output mode;
13, automatically save the processing state when power-off, power-on to resume processing, short-circuit automatic backoff and other fault treatment;
