Large Workpiece CNC Gantry Milling Service With Mill Test Report
Product Spotlights
Precision CNC gantry milling for oversized parts up to 8m, certified with Mill Test Report for full traceability. ISO9001 factory, 51-100 skilled staff, 30-ton capacity, multi-axis flexibility. Cost-effective single-setup machining, fast lead times, global shipping from major Chinese ports. Customized solutions for aerospace, automotive, heavy machinery.
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Service Type:
CNC Gantry Milling
Max Workpiece Size (L×W×H):
Up to 8000×4000×2000 mm
Material Capability:
Steel, Stainless Steel, Aluminum, Cast Iron, Alloy
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Custom Metal Gantry Milling Service 42CrMo 20CrMnTi Steel Parts MachiningNegotiableMOQ: 1 Piece -
5 Axis Gantry CNC Machining for Large Gear & Gear Housing PartsNegotiableMOQ: 1 Piece
-
Factory Supply Gantry CNC Machining for Large Bearing Seat ComponentsNegotiableMOQ: 1 Piece
-
OEM Large Size Gantry CNC Machining Service Per Customer DrawingsNegotiableMOQ: 1 Piece
-
High Precision 8‑meter Gear Hobbing Service DIN6‑DIN9 Large Gear Blank MachiningNegotiableMOQ: 1 Piece
Service Type
CNC Gantry Milling
Max Workpiece Size (L×W×H)
Up to 8000×4000×2000 mm
Material Capability
Steel, Stainless Steel, Aluminum, Cast Iron, Alloy
Tolerance
±0.05 mm (customizable)
Surface Finish
Ra 0.8 – 3.2 μm
Testing Report
Mill Test Report (MTR) provided
Industry Application
Aerospace, Automotive, Mold & Die, Heavy Machinery
Lead Time
10–30 working days (depending on complexity)
Welcome to Henan San Kuang Machinery Technology Co., Ltd. – your trusted partner for precision Large Workpiece CNC Gantry Milling Service. Since 2014, we have been delivering high-quality machining solutions from our 10,000–30,000 m² factory in Luoyang, Henan, China. Our service includes a comprehensive Mill Test Report (MTR) for every workpiece, ensuring full traceability and material compliance. With annual export value exceeding US$2.5 million, we serve clients across North America, Europe, Asia, and beyond.
Our CNC gantry milling machines are purpose-built for oversized and heavy components, offering exceptional rigidity and accuracy. Whether you need prototypes, single parts, or batch production, we combine advanced technology with skilled engineering to meet your most demanding specifications.
Key Features & Technical Specifications
- Ultra-Large Capacity: Handles workpieces up to 8m long, 4m wide, and 2m high – ideal for aerospace frames, wind turbine components, and large mold bases.
- High-Precision Machining: Achieves tolerances of ±0.05 mm with repeatability of ±0.02 mm, thanks to our HEIDENHAIN & SIEMENS control systems.
- Multi-Axis Flexibility: 3-axis, 4-axis, and 5-axis configurations available for complex contouring and undercut features.
- Full Material Compatibility: Works with carbon steel, alloy steel, stainless steel, aluminum, titanium, cast iron, and engineering plastics.
- Integrated Quality Control: Every part is inspected with CMM and hardness testers; the Mill Test Report includes chemical composition, mechanical properties, and dimensional data.
| Parameter | Value |
|---|---|
| Table Load Capacity | Up to 30 tons |
| Spindle Speed | 20–6000 rpm (optional high-speed 12,000 rpm) |
| Spindle Power | 30–60 kW |
| Rapid Traverse | X: 20 m/min, Y: 15 m/min, Z: 10 m/min |
| Tool Changer | Automatic, 40–60 tools |
Benefits for Your Business
- Reduced Lead Times: Our efficient production planning and 24/7 shift capability ensure on-time delivery for critical projects.
- Cost-Effective Solutions: Eliminate multiple setups and fixturing costs – one machine can complete complex large parts in a single operation.
- Full Documentation: Mill Test Reports are issued per ASTM, EN, or customer-specific standards, supporting your quality assurance and regulatory needs.
- Flexible Order Quantities: From one-off prototypes to high-volume runs, we adapt to your inventory strategy.
Trust & Reliability
With certifications including ISO9001, ISO14000, and OHSAS18001 (among others), our quality management system is independently audited and continuously improved. Our factory employs 51–100 skilled professionals and operates under strict environmental and safety standards. We ship globally via Shanghai, Lianyungang, Qingdao, or Tianjin ports, ensuring secure packaging and fast logistics. Over 80% of our revenue comes from repeat customers who value our consistent quality and responsive service.
We invite you to experience the San Kuang advantage. Contact us today with your drawings or specifications – we will provide a detailed quotation, process plan, and sample Mill Test Report within 48 hours. Let our expertise turn your large workpiece challenges into precision solutions.
Frequently Asked Questions
- What is a Mill Test Report and why do you provide it? A Mill Test Report (MTR) is a quality document that certifies the chemical composition, mechanical properties, and dimensional accuracy of the machined part. We provide it as standard to guarantee material traceability and compliance with your specifications.
- What is the maximum workpiece size you can handle? Our standard gantry mill can accommodate parts up to 8000×4000×2000 mm (length × width × height). For oversized items, we can discuss custom fixturing or alternative machine access.
- Do you offer secondary services like heat treatment or surface coating? Yes, we can coordinate with our trusted partners for heat treatment, anodizing, painting, and other finishing – all under our quality control.
- How do you ensure the accuracy of large parts? We use a combination of laser calibration, temperature-controlled shop floor, and in-process probing. Final inspection is performed with a coordinate measuring machine (CMM) and documented in the MTR.
- What materials can you machine? We regularly machine carbon steel, alloy steel, stainless steel, aluminum, cast iron, bronze, and engineering plastics. For exotic alloys like Inconel or titanium, we have specialized tooling and cutting parameters.
- What is your typical lead time? Lead time depends on complexity and current workload. Generally, simple parts take 10–15 working days, while complex multi-axis parts require 20–30 working days. Rush orders are available upon request.
- Do you provide samples before mass production? Absolutely. We recommend a first-article inspection (FAI) with a sample part to validate the process. The sample and report are shipped at cost.
- Can you work with proprietary designs or NDAs? Yes, we respect your IP. We gladly sign Non-Disclosure Agreements and securely store your designs. Your data is never shared with third parties.
