As a leading manufacturer with over 25 years of experience, Anping County Boli Hardware Wiremesh Products Factory proudly presents our Hook-banded Composite Screen Mesh 20 Mesh 1.5m x 30m Roll 304 Material. Designed specifically for vibrating screens, this product combines high-quality 304 stainless steel with a robust hook-banded structure to ensure superior performance in demanding industrial applications. Our factory, established in 1998, has exported to markets across North America, South America, Europe, and Asia, with annual export values reaching US$5–10 million, reflecting our commitment to excellence and reliability.
This screen mesh is engineered to deliver efficient material separation, enhanced durability, and easy installation. The 20-mesh opening provides an optimal balance between throughput and particle size control, making it ideal for aggregate, mining, recycling, and chemical processing industries. The composite design integrates a high-strength woven wire cloth with a hook strip along the edges, allowing quick tensioning and secure mounting on vibrating screen decks.
Below are the key technical specifications of our Hook-banded Composite Screen Mesh:
| Parameter | Value |
| Mesh Count | 20 Mesh |
| Wire Diameter | 0.4 mm (standard, customizable) |
| Open Area | Approximately 50% (based on wire diameter) |
| Roll Dimensions | 1.5m width x 30m length |
| Material | 304 Stainless Steel |
| Edge Type | Hook-banded (with metal hook strip) |
| Surface Finish | Bright, smooth, corrosion-resistant |
| Application | Vibrating screens, sieving, grading, dewatering |
Key Features and Benefits:
- High-Quality 304 Stainless Steel: Resists rust, corrosion, and wear, ensuring long service life even in wet or abrasive environments.
- Precise 20 Mesh Opening: Provides consistent particle separation with minimal blinding, improving screening efficiency.
- Hook-Banded Edge Design: Allows fast and secure installation on vibrating screens, reducing downtime and labor costs. The hook strip can be easily tensioned to maintain flatness.
- Customizable Wire Diameter & Dimensions: We offer flexibility to adjust wire diameter, mesh count, and roll size to meet your specific requirements.
- Versatile Applications: Suitable for screening aggregates, sand, gravel, ores, coal, recycled materials, and chemical powders.
- Cost-Effective Solution: Combines durability with affordable pricing, delivering excellent value for bulk buyers.
Our manufacturing process strictly controls quality from raw material sourcing to weaving and edge finishing. Each roll is inspected for uniformity, tensile strength, and dimensional accuracy before shipment. The hook-banded composite construction ensures that the screen mesh remains taut under high-frequency vibration, maximizing throughput and minimizing product loss.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
- Over 25 years of specialized manufacturing experience (since 1998).
- Annual export value of US$5–10 million, serving clients in North America, South America, Europe, Asia, Africa, and Oceania.
- Convenient shipping from multiple ports: Tianjin, Qingdao, Shanghai, and Foshan, ensuring fast and cost-effective logistics.
- Dedicated customer support team to assist with customization, sampling, and after-sales inquiries.
- Flexible MOQ and packaging options to accommodate both large projects and trial orders.
We understand that every screening application has unique demands. Our team can provide technical guidance on selecting the optimal mesh count, wire diameter, and edge type for your vibrating screen equipment. Whether you need a standard 20-mesh roll or a custom configuration, we are ready to deliver.
Frequently Asked Questions
Q1: What is the difference between hook-banded and plain edged screen mesh?
A: Hook-banded mesh has a metal hook strip attached to the edges, which allows easy tensioning and fast installation on vibrating screens. Plain-edged mesh requires additional clamping or welding, which can be more time-consuming. Hook-banded is preferred for high-frequency applications where quick screen changes are needed.
Q2: Can I get a custom mesh count or roll size?
A: Yes, we offer customization. You can specify different mesh counts (e.g., 10, 30, 40 mesh), wire diameters, and roll dimensions. Please contact our sales team with your requirements, and we will provide a tailored solution.
Q3: Is this screen mesh suitable for wet screening?
A: Yes, the 304 stainless steel material offers excellent corrosion resistance, making it ideal for wet screening applications such as dewatering, washing, and slurry separation. However, for highly acidic or alkaline conditions, we recommend 316 stainless steel.
Q4: How is the screen mesh packaged for export?
A: Each roll is wound on a sturdy core, wrapped with protective material (e.g., plastic film and woven bag), and secured with straps. The package is marked with product details and handling instructions to ensure safe transit.
Q5: What is the typical lead time for this product?
A: For standard 20-mesh 1.5m x 30m rolls, we usually ship within 7-15 days after order confirmation. Custom orders may take 15-25 days depending on the complexity. We can expedite urgent orders based on stock availability.
Q6: Can you provide a sample before bulk order?
A: Yes, we offer samples (e.g., 0.5m x 0.5m piece) for quality evaluation. The sample cost is reasonable, and we can deduct it from the bulk order if you decide to purchase.
Q7: What is the maximum operating temperature for this screen mesh?
A: 304 stainless steel can typically withstand continuous temperatures up to 870°C (1600°F) in oxidizing conditions, but for vibrating screen applications, the operating temperature is usually much lower. Please consult with us if your process involves high temperature.
Q8: Do you offer technical support for screen selection?
A: Absolutely. Our experienced engineers can help you choose the right mesh count, wire diameter, and edge type based on your material characteristics, feed size, and desired throughput. Just provide your application details, and we will recommend the most suitable solution.
With over two decades of expertise, a strong export track record, and a reliable supply chain, Anping County Boli Hardware Wiremesh Products Factory is your trusted partner for high-performance vibrating screen meshes. Our 20-mesh hook-banded composite screen mesh in 304 stainless steel is ready to enhance your screening operations. Contact us today for a quote or to discuss your specific requirements. We look forward to serving you from our base in Hengshui, Hebei, China.
