Professional Hook-strip Composite Shaker Screen 1200x950mm 316L Triple Layer Composite for Drilling
As a leading manufacturer with over 20 years of experience, Anping County Boli Hardware Wiremesh Products Factory (est. 1998) proudly presents our high-performance Hook-strip Composite Shaker Screen. Designed for rigorous drilling operations, this 1200x950mm triple-layer screen combines premium 316L stainless steel with advanced composite technology to deliver exceptional filtration efficiency and durability. Our factory, with an annual export value of US$5–10 million, serves global markets including North America, South America, and the Middle East, ensuring reliable supply and consistent quality.
This shaker screen is engineered to optimize solids control in drilling fluids, reducing downtime and maintenance costs. Its hook-strip design allows quick installation and replacement on most shale shakers, while the triple-layer composite structure ensures superior screening accuracy and long service life. Whether you are drilling in harsh offshore environments or demanding onshore conditions, our screen provides the performance you need.
Key Features & Technical Specifications
- Material: 316L stainless steel – excellent corrosion resistance, suitable for high-temperature and acidic drilling fluids.
- Size: 1200mm x 950mm – standard dimensions compatible with major shaker brands (e.g., Brandt, Derrick, MI-Swaco).
- Layer: Triple-layer composite – bonded with a perforated plate for enhanced rigidity and filtration precision.
- Hook-strip: Pre-formed hook strips on both ends for easy tensioning and secure fit.
- Mesh Count: Available in API 20 to 325 mesh (customizable per request).
- Flow Capacity: Optimized for high throughput while maintaining fine solids separation.
- Durability: Reinforced edges and anti-clogging design reduce screen blinding.
Parameter Table
| Dimension | 1200×950 mm |
| Material | 316L Stainless Steel |
| Layer Structure | Triple-layer composite (mesh + mesh + perforated plate) |
| Hook Strip | Carbon steel or stainless steel (optional) |
| Mesh Range | 20–325 mesh (API) |
| Weight | Approx. 28 kg |
| Package | Plywood case or pallet |
Advantages & Customer Benefits
- Extended Service Life: The 316L stainless steel resists corrosion and abrasion, providing up to 3x longer lifespan compared to standard screens.
- Improved Filtration Efficiency: Triple-layer design delivers precise solids cut points, reducing recirculation of drill solids and improving mud quality.
- Easy Installation: Hook-strip design allows quick screen changes without special tools, minimizing rig downtime.
- Compatibility: Fits most hook-strip type shale shakers, including Brandt, Derrick, and Kem-Tron models.
- Cost-Effective: Lower replacement frequency and reduced maintenance costs translate to significant savings over time.
- Customizable: Mesh count, hook strip material, and edge reinforcement can be tailored to your specific drilling conditions.
Trust & Quality Assurance
With over two decades of manufacturing expertise, Anping County Boli Hardware Wiremesh Products Factory has established a reputation for reliability and precision. Our annual export volume of US$5–10 million to markets across North America, South America, Europe, Africa, and Asia reflects the trust our global clients place in our products. We strictly control each production stage – from raw material sourcing to final inspection – ensuring every screen meets rigorous quality standards. Our experienced team can also provide technical support and after-sales service. Choose Boli for your drilling screen needs and experience superior performance, consistent quality, and competitive pricing. Contact us today for a quote or sample!
Frequently Asked Questions (FAQ)
-
Q: What is the difference between a single-layer and triple-layer composite shaker screen?
A: A triple-layer screen uses two mesh layers bonded to a perforated plate, providing higher screening accuracy and better durability. It is ideal for demanding drilling applications where fine solids control is critical. -
Q: Can I use this screen on my Brandt shaker?
A: Yes, our hook-strip composite screen is designed to fit most standard hook-strip shakers, including Brandt, Derrick, MI-Swaco, and others. Please confirm dimensions – 1200x950mm is a common size. -
Q: What mesh sizes are available?
A: We offer a wide range from 20 mesh to 325 mesh (API). Custom meshes can be produced according to your requirements. Contact our sales team for details. -
Q: Is the hook strip also made of 316L stainless steel?
A: The hook strip is typically made of carbon steel with anti-corrosion coating, but stainless steel hook strips are available upon request for extreme environments. -
Q: How long is the delivery time?
A: For standard screens, delivery is usually 15–20 working days after order confirmation. Custom orders may take longer depending on quantity and specifications. -
Q: Do you provide samples for testing?
A: Yes, we can provide samples. Please contact us to discuss sample fees and shipping arrangements. -
Q: What is the minimum order quantity (MOQ)?
A: For standard sizes, MOQ is typically 10 pieces. For custom orders, MOQ may vary. We welcome small trial orders. -
Q: How do you package the screens to prevent damage during shipping?
A: Each screen is packed in a sturdy plywood case or pallet, with foam or cardboard separators to prevent movement. Our export packaging ensures safe arrival at your site.
* All technical specifications are subject to change without notice. Please confirm with our sales team for the latest information.
