Help CenterSteel-framed Drilling Mud Screen 58x30 Inches API 200 Mesh Premium Grade for Fine Solids Control
Product Spotlights
Related Products
-
Steel-framed Mud Shaker Screen 48x30 Inches Hook Strip Flat Panel 304SS for Efficient SeparationNegotiableMOQ: 1 Piece -
Steel-framed Shaker Screen Used in Horizontal Directional Drilling (HDD) Mud Cleaning EquipmentNegotiableMOQ: 1 Piece
-
Steel-framed Mud Shaker Screen 304SS 1.0mm Wire Diameter 20 Mesh for High-Frequency VibratingNegotiableMOQ: 1 Piece
-
Steel-framed Shale Shaker Screen Factory Direct 1-Year Warranty API Standard Compliant for Long Service LifeNegotiableMOQ: 1 Piece
-
Steel-framed Drilling Mud Shaker Screen for Oilfield Solids Control and Mud Recycling SystemsNegotiableMOQ: 1 Piece
Anping County Boli Hardware Wiremesh Products Factory, a trusted manufacturer established in 1998 with annual export value of US$5-10 million, proudly presents our Steel-framed Drilling Mud Screen 58x30 Inches API 200 Mesh Premium Grade. Engineered for demanding drilling operations, this screen provides exceptional fine solids control, effectively separating particles as small as 74 microns. Our premium-grade construction ensures long service life and consistent performance, making it an ideal choice for shaker systems in oil & gas, water well, and geothermal drilling.
Built with a robust steel frame and high-tensile stainless steel wire cloth, this screen is designed to withstand harsh conditions while maintaining high flow capacity. The precise API 200 mesh opening guarantees accurate cut-points, reducing solids loading and protecting downstream equipment. Whether you need to extend mud life or improve drilling efficiency, our screen delivers reliable results.
Key Features & Technical Specifications
- Heavy-duty steel frame: Provides rigidity and prevents warping under high vibration.
- Premium stainless steel mesh: Corrosion-resistant and durable, with API 200 (74 micron) openings.
- High open area: Up to 38% for improved fluid flow and reduced blinding.
- Pre-tensioned design: Ensures uniform tension across the screen for consistent performance.
- Compatible with major shaker brands: Fits most 58x30 inch shaker units (e.g., Brandt, Derrick, SWACO).
- Optional hook strip or flat panel: Available upon request for different mounting systems.
- Customizable: Mesh count, frame material, and dimensions can be tailored to your needs.
| Property | Specification |
| Model | BL-58x30-API200 |
| Mesh Count | 200 x 200 (API 200) |
| Wire Diameter | 0.063 mm (main) / 0.08 mm (support) |
| Cut Point (d50) | 74 microns |
| Flow Capacity | Up to 800 L/min per screen (depending on viscosity) |
| Weight | ~13 kg (steel frame version) |
| Operating Temperature | -40°C to 120°C |
Our premium-grade screen is manufactured using advanced weaving technology and strict quality control. Each screen undergoes vibration testing to ensure uniform tension and dimensional accuracy. The steel frame is treated with anti-corrosion coating, extending service life even in aggressive drilling fluids. Compared to standard screens, our premium version offers 20% longer operational life and superior resistance to blinding, reducing downtime and replacement costs.
Why Choose Our Steel-framed Mud Screen?
- Enhanced solids control: Fine mesh captures even the smallest cuttings, improving mud quality.
- Lower total cost of ownership: Durable construction reduces replacement frequency.
- Easy installation: Pre-tensioned screen fits directly into shaker bed without adjustments.
- Compatible with multiple shaker models: Works with Brandt, Derrick, SWACO, and other common brands.
- Customizable options: Available in different mesh sizes (API 80 to API 400) and frame materials (steel, composite).
With over 25 years of manufacturing experience, Anping County Boli Hardware Wiremesh Products Factory has exported to North America, South America, Europe, Africa, and Oceania, serving clients in the oil & gas, mining, and water well industries. Our annual export value of US$5-10 million reflects the trust placed in our products. We ship from major ports (Tianjin, Qingdao, Shanghai, Foshan) with fast lead times.
Order today and experience the difference of premium-grade solids control. Contact our sales team for a quote or to discuss custom requirements. We offer free samples for qualification, and bulk orders come with competitive pricing and full technical support.
Frequently Asked Questions
-
Q: What is the exact mesh opening of API 200?
A: API 200 mesh has a nominal opening of 74 microns (0.074 mm). It is designed for fine solids control, removing particles larger than 74 microns. -
Q: Can this screen be used on any shaker?
A: It fits most shakers with a 58x30 inch screen bed. However, we recommend checking the mounting system (hook strip, pin, or flat). We can provide adapters or custom frames if needed. -
Q: How long does the screen typically last?
A: Lifetime depends on operational conditions (abrasiveness, vibration, cleaning). Under normal use, our premium screens last 2-4 weeks in continuous drilling. Proper maintenance (e.g., avoiding high-pressure spray) extends life. -
Q: Do you offer other mesh sizes?
A: Yes, we supply API 80, 100, 140, 170, 200, 210, 230, 250, 270, 325, and 400 mesh. Custom sizes are available upon request. -
Q: Is the screen pre-tensioned?
A: Yes, all our screens are pre-tensioned during manufacturing to ensure uniform tension and consistent performance. No additional tensioning is required. -
Q: What is the minimum order quantity?
A: MOQ is 10 pieces for stock sizes. For custom orders, MOQ may be higher. We accept small trial orders for new customers. -
Q: Can you provide certification?
A: We can provide material test reports and dimensional inspection certificates. For API certification, please contact our sales team to discuss options. -
Q: How is the screen packed for export?
A: Each screen is packed individually with cardboard or plywood reinforcement, then bundled on pallets. We ensure safe shipping to prevent damage.
