Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a professional manufacturer with over 10 years of experience in the field of evaporation systems. Our Falling Film Evaporation System is constructed from high-quality 316L stainless steel, designed to operate at 0.1 MPa with a capacity of 300 L/h. This system features an advanced CIP (Clean-in-Place) cleaning design, ensuring efficient operation and easy maintenance. It is widely used in the food, pharmaceutical, and chemical industries for concentrating heat-sensitive liquids, offering excellent heat transfer efficiency and product quality preservation.
Our falling film evaporator is engineered to meet the highest standards of reliability and performance. With a compact footprint and modular construction, it can be easily integrated into existing production lines. The 316L stainless steel material provides superior corrosion resistance and longevity, making it ideal for demanding environments. The system is fully customizable to meet specific process requirements, including temperature control, vacuum options, and automation levels.
Key Features & Advantages
- 316L Stainless Steel Construction: Ensures excellent corrosion resistance, hygiene, and durability, suitable for food and pharmaceutical applications.
- High Evaporation Capacity: 300 L/h, ideal for medium-scale production.
- Low Operating Pressure (0.1 MPa): Allows gentle evaporation at low temperatures, preserving sensitive product qualities.
- CIP Cleaning Design: Integrated cleaning system reduces downtime and labor costs, ensuring consistent product quality.
- Efficient Heat Transfer: Thin film formation maximizes heat transfer area and reduces fouling.
- Customizable Options: Available with various heating media (steam, hot water), vacuum systems, and control interfaces.
- Compact & Modular: Space-saving design with easy installation and maintenance.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | 316L Stainless Steel (SS304 optional) |
| Evaporation Capacity | 300 L/h (customizable up to 1000 L/h) |
| Working Pressure | 0.1 MPa (vacuum available) |
| Design Temperature | Up to 150°C (depending on media) |
| Heating Media | Steam, hot water, or thermal oil |
| Cleaning Method | CIP (Clean-in-Place) with spray balls |
| Control System | PLC with HMI touch screen (optional) |
| Power Supply | 380V/50Hz or customized |
Detailed Benefits for Your Business
Enhanced Product Quality: The falling film principle ensures gentle evaporation with minimal thermal degradation. This is critical for heat-sensitive products like fruit juices, dairy concentrates, and pharmaceutical extracts. The 316L stainless steel surface prevents contamination and maintains purity.
Operational Efficiency: With a capacity of 300 L/h, this system is optimized for medium-scale continuous processing. The integrated CIP system allows automatic cleaning without disassembly, reducing labor costs and downtime. The design also minimizes energy consumption through efficient heat recovery.
Compliance & Safety: Our system is built to meet international standards. The 316L stainless steel is FDA-compliant for food contact. The low-pressure operation enhances safety. Additionally, our company holds multiple certifications including ISO9001, HACCP, and OHSAS18001, ensuring rigorous quality management throughout production.
Trust & Reliability
As a leading manufacturer with a 10,000-30,000 m² factory and over 200 employees, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been delivering high-quality evaporation systems since 2015. Our annual export value exceeds US$10 million, serving markets across North America, Europe, Southeast Asia, and more. We offer comprehensive after-sales support, including installation guidance, training, and spare parts supply. Choose our Falling Film Evaporation System for reliable performance and long-term value.
Contact us today for a customized solution tailored to your specific requirements. Our team of engineers is ready to assist you with technical details and quotations.
Frequently Asked Questions
-
Q: What is the main advantage of a falling film evaporator over other types?
A: Falling film evaporators provide high heat transfer coefficients with short residence time, making them ideal for heat-sensitive liquids. They also reduce fouling and are easy to clean. -
Q: Can this system handle viscous liquids?
A: Yes, but viscosity above 1000 cP may require modifications. We recommend a feasibility test. Our team can advise on the best configuration. -
Q: What is the typical delivery time?
A: Standard delivery is 30-45 days after order confirmation, depending on customization requirements. -
Q: Do you provide installation and commissioning support?
A: Yes, we offer on-site installation guidance and commissioning services. Remote technical support is also available. -
Q: Can the system be integrated with existing CIP systems?
A: Absolutely. Our CIP design is compatible with most standard cleaning protocols. We can also provide a standalone CIP unit. -
Q: What materials are used for the gaskets and seals?
A: Standard gaskets are EPDM or silicone (FDA-grade). Other materials like PTFE are available upon request. -
Q: Is the system suitable for pharmaceutical applications?
A: Yes, the 316L stainless steel construction and CIP cleaning meet GMP requirements. Additional surface finish options (Ra ≤ 0.8 μm) are available. -
Q: What is the warranty period?
A: We offer a standard 12-month warranty covering manufacturing defects. Extended warranty plans are negotiable.
