1. Product Overview
HDPE (High-Density Polyethylene) Geomembrane is a high-performance impermeable geosynthetic material manufactured from 100% virgin high-density polyethylene resin, supplemented with carbon black, anti-oxidants, UV stabilizers and other special additives. Produced through advanced extrusion and calendering processes, the product features uniform thickness, stable physical and chemical properties, and excellent long-term service performance. It strictly complies with international industry standards including GRI-GM13, ASTM and European EN standards, and is widely recognized as a core anti-seepage and isolation material for modern civil and environmental engineering.
2. Core Features & Advantages
1. Excellent Impermeability
With extremely low hydraulic conductivity (10⁻¹³ cm/s level), the HDPE geomembrane achieves nearly zero water and gas permeability. It effectively blocks the leakage of water, sewage, chemical liquids and harmful gases, providing reliable anti-seepage protection for engineering projects.
2. Superior Chemical & Corrosion Resistance
The material shows strong resistance to acids, alkalis, salts, organic solvents, industrial wastewater and various corrosive soils. It is not easy to be eroded, aged or decomposed in harsh chemical environments, adapting to complex industrial and landfill working conditions.
3. High Mechanical Performance
It boasts high tensile strength, tear resistance and puncture resistance, with elongation at break over 700%. The flexible structure can effectively adapt to foundation settlement, ground deformation and external mechanical impact, avoiding cracking and damage.
4. Ultraviolet & Aging Resistance
Formulated with high-efficiency UV stabilizers and carbon black additives, the product resists ultraviolet radiation and thermal oxidation aging. It maintains stable performance for more than 50 years in outdoor exposed and buried environments.
5. Safe & Environmentally Friendly
Made of non-toxic virgin raw materials, the HDPE geomembrane is harmless to soil, water bodies and ecological environment. It features stable physical properties, no precipitation of harmful substances, and meets environmental protection requirements for water conservancy and ecological restoration projects.
6. Easy Construction & Low Cost
The product is lightweight, flexible, easy to cut, weld and lay. The hot-welded seam has high bonding strength and good integrity. It shortens construction period, reduces engineering comprehensive cost, and supports large-area rapid construction.
3. Technical Specifications
- Raw Material: 100% Virgin HDPE Resin
- Density: 0.940–0.960 g/cm³
- Available Thickness: 0.75mm, 1.0mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm
- Surface Type: Smooth Surface / Textured (Single/Double Rough) Surface
- Tensile Strength (Yield): ≥20 kN/m
- Tensile Strength (Break): ≥40 kN/m
- Elongation at Break: ≥700%
- Tear Strength: ≥10 kN/m
- Puncture Resistance: Excellent anti-puncture performance
- Hydraulic Conductivity: ≤1×10⁻¹³ cm/s
- Carbon Black Content: 2.0%–3.0% (UV resistance grade)
4. Implementation Standards
- International Standard: GRI-GM13 (Global Geomembrane Industry Standard)
- American Standard: ASTM D5199, ASTM D6693, ASTM D4833, ASTM D6392
- European Standard: BS EN 13361, BS EN 13362, BS EN 13492
5. Application Scope
1. Environmental Sanitation Engineering
Municipal solid waste landfills, hazardous waste disposal sites, sewage treatment plants, anaerobic digestion pools, tailings pond anti-seepage and closure projects.
2. Water Conservancy Engineering
Reservoirs, rivers, lakes, artificial ponds, water storage tanks, dam anti-seepage, channel anti-leakage and seepage prevention reinforcement projects.
3. Industrial Engineering
Chemical plants, pharmaceutical factories, electroplating factories, oil depots, industrial sewage pools, hydrocarbon barrier and chemical tank lining anti-seepage projects.
4. Ecological & Landscape Engineering
Artificial lake landscaping, fish and shrimp aquaculture ponds, wetland restoration, golf course lake anti-seepage projects.
5. Traffic & Municipal Engineering
Tunnel anti-seepage, highway and railway foundation isolation, subway underground structure waterproofing and gas barrier projects.
6. Product Advantages & Quality Guarantee
All our HDPE geomembranes adopt pure virgin raw materials without recycled materials. Each batch of products undergoes strict factory testing to ensure consistent thickness, stable indexes and reliable welding performance. The textured geomembrane effectively increases friction coefficient, suitable for slope anti-slip and high-gradient engineering construction. With long service life, zero pollution and strong adaptability, it is the preferred anti-seepage material for global engineering construction.
