Help CenterPLC Controlled Automatic Plate Heat Exchanger for Dairy, 15 Bar, 120°C, Flow Regulation
Product Spotlights
Related Products
-
Plate Heat Exchanger for Dairy Whey Cooling, 316L, 20 Bar, Sanitary Design, Easy MaintenanceUS$ 7380 - 85000MOQ: 1 Combo -
Plate Heat Exchanger for Dairy, Mill Test Report Included, 12 Months Warranty, 316LUS$ 7380 - 85000MOQ: 1 Combo
-
High-Pressure Plate Heat Exchanger for Dairy Products, 25 Bar, 160°C, 316L, 80 PlatesUS$ 7380 - 85000MOQ: 1 Combo
-
Plate Heat Exchanger for Dairy Products With 1 Year Warranty, Technical Support, 304 StainlessUS$ 7380 - 85000MOQ: 1 Combo
-
Plate Heat Exchanger for Milk Pasteurization, 304 Stainless, 10 Bar, CIP Cleanable, HygienicUS$ 7380 - 85000MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a leading manufacturer specializing in advanced heat exchange solutions for the food and dairy industry. With over 8 years of engineering experience and a modern factory spanning 10,000–30,000 square meters, we deliver high-performance equipment that meets the strictest hygiene and safety standards. Our PLC Controlled Automatic Plate Heat Exchanger for Dairy is designed to handle demanding processes at 15 Bar and 120°C, with precise flow regulation controlled by an intelligent PLC system. This unit ensures consistent product quality, energy efficiency, and minimal downtime, making it an ideal choice for dairy plants worldwide.
The heat exchanger combines robust construction with smart automation. The PLC control unit monitors and adjusts flow rates in real-time, ensuring optimal heat transfer while maintaining the delicate properties of dairy products. The unit is fully automatic, reducing manual intervention and operator errors. It is built to withstand continuous operation in harsh environments, with all wetted parts made of high-grade stainless steel to resist corrosion and facilitate cleaning-in-place (CIP).
Key Features & Technical Specifications
- PLC Control with HMI Interface: User-friendly touchscreen allows easy parameter setting, real-time monitoring, and data logging. Supports remote access and integration with plant SCADA systems.
- Automatic Flow Regulation: PID-controlled modulating valves ensure precise flow adjustment based on temperature and pressure feedback, maintaining ±0.5°C temperature accuracy.
- High Pressure & Temperature Rating: Designed for 15 Bar operating pressure and 120°C continuous service, suitable for pasteurization, sterilization, and cooling processes.
- Sanitary Design: All product contact surfaces are polished to Ra ≤ 0.8 μm, with no dead ends. Gaskets are made of FDA-approved EPDM or Viton, ensuring compliance with dairy industry standards.
- Energy Efficient: Counter-current flow arrangement maximizes heat recovery, reducing utility costs by up to 30% compared to traditional shell-and-tube exchangers.
- Modular Construction: Plate packs can be easily expanded or reconfigured for future capacity changes. Frame is made of carbon steel with epoxy coating for durability.
| Parameter | Specification |
|---|---|
| Plate Material | SS304 / SS316L (0.5–0.8 mm thickness) |
| Gasket Material | EPDM (FDA) / Viton / NBR |
| Max Design Pressure | 15 Bar (g) |
| Max Design Temperature | 120°C |
| Flow Range | 5 – 200 m³/h (depending on plate count) |
| PLC Controller | Siemens / Allen-Bradley (customizable) |
| Power Supply | 380V / 50Hz (or as specified) |
Benefits for Your Dairy Operation
- Enhanced Product Quality: Precise temperature control prevents protein denaturation and ensures consistent pasteurization, preserving taste and nutritional value.
- Reduced Downtime: Automatic cleaning cycles and self-diagnostics minimize maintenance. The PLC can alert operators before issues arise.
- Lower Operational Costs: Energy recovery and optimized flow reduce steam and cooling water consumption, cutting utility bills by up to 30%.
- Easy Scalability: Modular design allows adding plates without replacing the entire unit, adapting to future production increases.
- Compliance with Regulations: Built to meet HACCP, ISO9001, and other international food safety standards, ensuring smooth audits.
Trust the Experts at Qingdao Conqinphi
Since 2015, our company has grown into a global supplier with an annual export value of US$10–50 million, serving markets across North America, Europe, Asia, and Oceania. Our factory is certified with multiple quality management systems including ISO9001, ISO14000, OHSAS18001, HACCP, TL900, QS9000, SA8000, and many more, reflecting our commitment to excellence. We employ 201–300 skilled workers and engineers who continuously improve our designs. Our heat exchangers have been installed in over 50 countries, delivering reliable performance for dairy processors, breweries, and beverage plants.
We offer comprehensive after-sales support, including on-site commissioning, training, and spare parts availability from our Qingdao port. Customization options are available—contact our team to discuss your specific flow rate, pressure, or temperature requirements. Choose Qingdao Conqinphi for a heat exchanger that combines automation, durability, and dairy-specific engineering.
Frequently Asked Questions
- Q: Can this heat exchanger handle milk pasteurization at 72°C? A: Yes, the unit is designed for 120°C maximum, making it suitable for both pasteurization (72°C) and ultra-high temperature (UHT) processes. The PLC can be programmed with multiple temperature profiles.
- Q: What cleaning procedures are supported? A: The unit is CIP (clean-in-place) compatible. The PLC can control automated CIP cycles using caustic and acid solutions. All wetted materials are corrosion-resistant.
- Q: Is the PLC controller user-friendly for operators? A: Absolutely. The HMI touchscreen provides intuitive menus with real-time graphs. Multi-language support is available. We also provide operator training.
- Q: What is the typical lead time? A: Standard models can be shipped within 30–45 days after order confirmation. Custom configurations may take 50–60 days. We ship from Qingdao port.
- Q: Can the flow regulation handle variable dairy product viscosities? A: Yes, the PID controller adapts to changes in viscosity. The pressure drop across the plates is monitored, and the valve adjusts accordingly to maintain set flow.
- Q: Do you provide installation and commissioning support? A: Yes, we offer on-site installation supervision and commissioning services. Remote support is also available via VPN connection to the PLC.
- Q: What certifications does the equipment carry? A: Our factory is certified with HACCP, ISO9001, ISO14000, OHSAS18001, and many others. Specific certificates like CE or ASME can be provided upon request at additional cost.
- Q: Is there a warranty? A: Yes, we offer a standard 12-month warranty covering defective materials and workmanship. Extended warranties are negotiable.
