304 Stainless Steel Resin-Coated Wire Mesh With 0.5mm Wire Diameter for Filtration
Product Spotlights
304 stainless steel core with durable resin coating for exceptional corrosion and abrasion resistance. Precise 0.5mm wire diameter ensures consistent filtration. Anti-clogging, easy-to-clean surface extends service life. Customizable mesh openings, dimensions, and colors. Trusted manufacturer since 1998 with global export experience.
Negotiable
MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, 304 Stainless Steel
Application:
Other, Filtration
wire diameter:
0.5 mm
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin shanghai qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Epoxy Coated Support Mesh Inside Air Filter Element, 10 Micron Efficiency, 250°C Max Operating Temperature, Aluminum FrameNegotiableMOQ: 1 Square Meter -
Epoxy Resin Support Mesh Inside Air Filter Element for Dust Collection Systems, 5 Micron, 200°C, Compatible With Baghouse FiltersNegotiableMOQ: 1 Square Meter
-
Industrial Air Filter Element With Epoxy Resin Support Mesh, 1.0mm Wire Thickness, 6mm Mesh Size, 300 Pa Pressure DropNegotiableMOQ: 1 Square Meter
-
Epoxy Resin Support Mesh Inside Air Filter Element With 304 Stainless Steel Frame, 5 Micron Filtration, 200°C Heat ResistanceNegotiableMOQ: 1 Square Meter
-
Epoxy Resin Support Mesh Inside Pleated Air Filter Element, 95% Filtration Efficiency, 150°C Continuous Use, Galvanized Steel MeshNegotiableMOQ: 1 Square Meter
Material
Other, 304 Stainless Steel
Application
Other, Filtration
wire diameter
0.5 mm
coating
Resin (Epoxy/Polyester optional)
mesh type
Woven wire mesh
weave type
Plain weave / Twill weave (customizable)
color
Black / Green / Gray (customizable)
width
1m – 2m (customizable)
length
30m – 50m per roll (customizable)
Anping County Boli Hardware Wiremesh Products Factory, a professional manufacturer established in 1998 with an annual export value of US$5–10 million, proudly presents our 304 Stainless Steel Resin-Coated Wire Mesh with a precise 0.5mm wire diameter. Engineered for high-performance filtration, this mesh combines the corrosion resistance of 304 stainless steel with a durable resin coating, offering extended service life even in harsh environments. Whether you need fine particle separation in chemical processing or reliable liquid filtration in food production, our product delivers consistent results.
Key Features & Technical Specifications
- Material: Premium 304 stainless steel wire – excellent resistance to rust, acids, and alkalis.
- Wire Diameter: 0.5 mm (±0.02 mm tolerance) – ensures strength while maintaining precise openings.
- Resin Coating: Uniform epoxy/polyester coating – enhances chemical resistance, reduces friction, and prevents clogging.
- Mesh Opening: Available from 0.5 mm to 5 mm (customizable according to your filtration requirements).
- Mesh Count: Ranges from 4 mesh to 100 mesh (depending on opening size).
- Weave Type: Plain weave or twill weave – optional for different filtration efficiency.
- Roll Dimensions: Standard width 1m × 30m or 1.2m × 50m; other sizes available upon request.
- Color Options: Black, green, gray, or custom color to match your equipment.
| Parameter | Value |
|---|---|
| Wire Diameter | 0.5 mm |
| Coating Thickness | 0.05 – 0.15 mm (on each side) |
| Operating Temperature | -20°C to +120°C (continuous) |
| Tensile Strength | 500 – 800 N/mm² (before coating) |
| Mesh Opening Tolerance | ±5% |
Benefits for Your Filtration Applications
- Enhanced Durability: The resin coating protects the stainless steel wire from abrasion and chemical attack, significantly extending the mesh lifespan compared to uncoated wire mesh.
- Anti-Clogging Surface: The smooth, non-stick coating reduces material buildup, maintaining consistent flow rates and lowering maintenance frequency.
- Precise Filtration: With a 0.5mm wire diameter, we can produce mesh openings as fine as 0.5mm, ideal for removing particles in liquid or gas filtration.
- Corrosion Resistance: 304 stainless steel provides excellent resistance to most organic and inorganic chemicals, making it suitable for aggressive environments.
- Easy to Clean: The resin-coated surface allows quick washing with water or mild solvents, restoring performance without damage.
- Customizable Dimensions: We offer cutting, slitting, and edging services to meet your exact equipment specifications.
- Cost-Effective: Long service life reduces replacement frequency, lowering your total cost of ownership.
Trusted Quality & Global Reach
Since 1998, Anping County Boli Hardware Wiremesh Products Factory has been dedicated to manufacturing high-quality wire mesh products. With an annual export value of US$5–10 million, our products are shipped to major markets including North America, South America, Europe, Southeast Asia, Africa, and Oceania. We ship from ports such as Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery worldwide. Our factory is equipped with advanced weaving and coating lines, and we follow strict quality control procedures to ensure every roll meets your specifications.
We understand that filtration performance is critical to your operations. That’s why we offer free samples for evaluation before bulk orders, and our technical team is available to help you choose the optimal mesh configuration. Contact us today to discuss your filtration requirements and experience the reliability of Boli wire mesh.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum temperature this resin-coated mesh can withstand?
A: The continuous operating temperature is -20°C to +120°C. For short-term exposure, it can handle up to 150°C, but please consult our technical team for your specific application. -
Q: Can you provide different mesh openings for the same 0.5mm wire diameter?
A: Yes. With a 0.5mm wire, we can produce mesh openings ranging from 0.5mm to 5mm. The mesh count varies accordingly. Please specify your required opening size when ordering. -
Q: Is the resin coating food-grade?
A: We offer both standard and food-grade resin coatings. If you need FDA or EU food contact compliance, please inform us in advance, and we can provide the appropriate coating material. -
Q: What is the standard roll size, and can I get custom-cut pieces?
A: Standard rolls are 1m wide × 30m long. We can also cut to specific widths and lengths, or provide sheets with flattened edges or hooks. Custom sizes are available upon request. -
Q: How long does the coating last under normal use?
A: The coating lifespan depends on the operating conditions (temperature, chemicals, abrasion). In typical filtration applications, our resin coating lasts 3–5 years before requiring recoating or replacement. We recommend periodic inspection. -
Q: Do you offer free samples for testing?
A: Yes, we provide free samples (A4 size or 1 square foot) for your evaluation. You only need to pay for shipping. Contact our sales team to request a sample. -
Q: What is the minimum order quantity (MOQ)?
A: Our MOQ for stock items is 10 rolls. For custom specifications, the MOQ may be higher. However, we can accommodate small trial orders for new customers. -
Q: Can you print or mark the mesh with my company logo?
A: We can add custom markings on the edge or on the packaging. Please discuss your requirements with our sales representative.
