As a leading manufacturer at Hemaokang Steel (Shandong) Co., Ltd., we are proud to introduce our 200mm Width Printed Medicinal Aluminum Foil with VC Coating, specifically engineered for high-performance pharmaceutical blister packaging. With our ISO9001-certified production facility established in 2025 and an annual export value exceeding US$50 million, we deliver reliable, customizable aluminum foil solutions that meet the stringent demands of the global healthcare industry. This product combines superior barrier protection with vibrant, precise printing, ensuring your medications stay safe, stable, and clearly identifiable.
Our aluminum foil is produced using premium-grade raw materials and advanced coating technology. The VC (vinyl coating) layer provides excellent adhesion to blister films, enhances heat-seal strength, and maintains chemical inertness, making it ideal for sensitive pharmaceutical formulations. The precise 200mm width is optimized for standard blister packaging machinery, while the printed surface allows for high-quality branding, dosage information, and tamper-evident features. Below, we detail the key technical specifications and benefits that set this product apart.
Key Features & Technical Specifications
- Material: High-purity aluminum alloy (8011/8021 options) with controlled thickness tolerance.
- Coating: VC (vinyl coating) – certified for pharmaceutical contact, non-toxic, and odorless.
- Width: 200 mm (+/- 0.3 mm tolerance) – compatible with most blister packaging machines.
- Printing: Multi-color gravure or flexographic printing, up to 8 colors, with precise registration.
- Barrier Properties: Excellent moisture barrier (WVTR
- Heat Seal Strength: > 8 N/15mm (with PVC/PVDC/PE films) – customizable based on customer requirements.
- Surface Finish: Available in matte, glossy, or brushed finish to suit branding preferences.
- Certification: ISO9001:2015 quality management system; compliant with FDA and EU pharmacopoeia regulations (on request).
| Parameter | Typical Value | Remarks |
|---|---|---|
| Thickness | 0.020 – 0.045 mm | Customizable |
| Tensile Strength | ≥ 80 N/mm² | MD direction |
| Elongation | ≥ 3% | MD direction |
| Heat Seal Temperature | 160 – 200 °C | Adjustable |
| Printing Resolution | Up to 175 LPI | High clarity |
Our 200mm Printed Medicinal Aluminum Foil with VC Coating offers several advantages for pharmaceutical manufacturers:
- Enhanced Product Protection: The VC coating creates a robust barrier against moisture, oxygen, and light, extending the shelf life of hygroscopic and light-sensitive drugs.
- Superior Print Quality: High-resolution gravure printing ensures sharp text, logos, and barcodes – essential for patient safety and brand recognition.
- Excellent Machinability: Consistent thickness and precise width reduce downtime on blister packaging lines, increasing overall efficiency.
- Regulatory Compliance: Materials are selected to meet USP, EP, and Chinese pharmacopoeia requirements; documentation available upon request.
- Customization Options: We offer custom colors, print designs, thickness, and coating formulations to match your specific blister film and product requirements.
- Eco-Friendly Production: Our manufacturing process minimizes waste and uses solvent-free inks upon request, supporting your sustainability goals.
Trusted by clients across North America, South America, Europe, and Asia, Hemaokang Steel ensures consistent quality and on-time delivery. Our ISO9001-certified facility in Liaocheng, Shandong, operates with 51–100 skilled employees, and our export volume of US$50–100 million per year demonstrates our reliability in the global market. We are committed to providing the best value for your pharmaceutical packaging needs.
Frequently Asked Questions (FAQ)
-
Q: What is the minimum order quantity for this foil?
A: Our standard MOQ is 500 kg per specification, but we can accommodate smaller trial orders for qualified customers. Please contact our sales team for details. -
Q: Can you provide samples for testing?
A: Yes, we offer free samples (A4 size sheets or small rolls) for evaluation. You only need to cover shipping costs. We can also provide a certificate of analysis. -
Q: Is the VC coating safe for pharmaceutical use?
A: Absolutely. The vinyl coating is FDA-compliant for indirect food contact and has been tested for cytotoxicity and migration. We can provide relevant compliance documents. -
Q: How long does it take to produce custom-printed foil?
A: For standard designs, lead time is 15–20 working days after approval of artwork. Complex multi-color designs may require 25–30 days. -
Q: What types of blister films are compatible with this foil?
A: The foil is designed to heat-seal with PVC, PVDC, PVC/PVDC, and PE films. We can adjust the coating formulation to achieve optimal seal strength with your specific film. -
Q: Do you offer technical support for packaging line optimization?
A: Yes, our engineers can provide guidance on sealing parameters, machine settings, and troubleshooting. We also offer on-site support for large orders. -
Q: What is the shelf life of this aluminum foil?
A: When stored in a dry, cool environment (≤25°C, RH ≤65%), the foil retains its properties for at least 24 months from the date of manufacture. -
Q: Can you provide certificates like ISO or test reports?
A: Yes, we are ISO9001:2015 certified and can provide material certificates, MSDS, and RoHS/REACH compliance reports upon request.
With Hemaokang Steel, you are choosing a partner dedicated to quality, innovation, and global service. Our 200mm Printed Medicinal Aluminum Foil with VC Coating is the ideal solution for your pharmaceutical blister packaging requirements. Contact us today to discuss your specific needs and request a quotation!
