Hemaokang Steel (Shandong) Co., Ltd. proudly presents our premium Pharmaceutical Aluminum Foil, fully compliant with ASTM B209 and supplied with a comprehensive Mill Test Report. As a reliable manufacturer established in 2025 and backed by an annual export value exceeding US$50 million, we specialize in high-quality aluminum foil tailored for pharmaceutical blister packaging. Our foil offers exceptional barrier properties, ensuring product integrity and extended shelf life. Trusted by clients across North America, Europe, Asia, and beyond, our product meets the stringent requirements of the pharmaceutical industry.
Key Features and Technical Specifications
- Material Composition: High-grade aluminum alloys (8011, 8079) known for excellent ductility and puncture resistance.
- Thickness Range: 0.02 mm – 0.09 mm, customizable to specific packaging needs.
- Width Tolerance: ±1 mm, available from 200 mm to 1200 mm.
- Surface Finish: Matte or bright finish options for optimal printing and sealing.
- Pinhole Rate: Below 10 pinholes per square meter, ensuring superior barrier integrity.
- Elongation: ≥ 3% (for thickness ≥ 0.02 mm), guaranteeing flexibility during forming.
- Tensile Strength: 100–150 N/mm², providing robust mechanical performance.
- Heat Seal Coating: Optional water-based or solvent-based coating for secure blister sealing.
| Parameter | Value | Notes |
|---|---|---|
| Alloy | 8011 / 8079 | Foil grade for pharma |
| Temper | O, H18 | Soft or hard as required |
| Surface Oil Level | ≤ 200 mg/m² | Clean, suitable for coating |
| Mill Test Report | Provided with each shipment | ASTM B209 compliance verified |
Advantages for Customers
- Product Protection: Excellent moisture, light, and oxygen barrier keeps medicines stable and extends shelf life.
- Formability: High elongation allows deep drawing without cracking, ensuring precise blister cavities.
- Printability: Uniform surface accepts high-quality printing and coating for branding and regulatory information.
- Compliance: Full traceability via mill test reports, satisfying pharmaceutical quality audits.
- Customizable: Width, thickness, coating, and packaging options available to match production lines.
- Cost-Effective: Competitive pricing without compromising on quality, backed by large-scale production capacity.
At Hemaokang Steel (Shandong) Co., Ltd., we combine advanced manufacturing with rigorous quality control. Our ISO9001 certified processes ensure consistent product performance. With an annual export value between US$50 million and US$100 million, we have the scale to meet large-volume orders while maintaining punctual delivery. Our team of 51–100 experienced professionals is dedicated to serving global markets, including North America, South America, Europe, Asia, Africa, and Oceania. Every coil of pharmaceutical aluminum foil is accompanied by a detailed mill test report, confirming adherence to ASTM B209 standards. Choose Hemaokang for reliable supply chain partnership and superior product quality. Contact us today for samples, custom specifications, or to place your order. We are committed to helping your pharmaceutical packaging succeed.
FAQ – Frequently Asked Questions
1. What is the difference between ASTM B209 and other aluminum foil standards?
ASTM B209 is a widely recognized standard for aluminum and aluminum-alloy sheet and plate. It specifies mechanical properties, chemical composition, and dimensional tolerances. Our foil is tested to meet these requirements, providing reliable performance for pharmaceutical packaging.
2. Do you provide a mill test report with every shipment?
Yes, each shipment includes a comprehensive mill test report (MTR) that documents the chemical analysis, mechanical properties, and compliance to ASTM B209. This ensures full traceability for your quality assurance.
3. Can I get customized thickness or width?
Absolutely. We offer customizable thickness from 0.02 mm to 0.09 mm and width from 200 mm to 1200 mm. Please specify your requirements, and we will produce accordingly.
4. Is the foil suitable for child-resistant blister packaging?
Yes. Our aluminum foil can be combined with specially designed push-through or peel-off films to meet child-resistant standards. We also offer optional heat-seal coatings tailored for such applications.
5. What coating options are available for heat sealing?
We provide both water-based and solvent-based coatings. The specific coating formulation can be selected based on your sealing equipment and the type of PVC, PVDC, or cold-form blister film used.
6. How do you ensure pinhole-free quality?
We use advanced rolling mills, strict process control, and online pinhole detectors. Our reject threshold is ≤10 pinholes per square meter, which is well below typical industry limits.
7. What is your typical lead time?
For standard specifications, lead time is approximately 15–20 days after order confirmation. Custom orders may require 20–25 days. We can expedite based on stock availability.
8. Do you offer free samples for testing?
Yes, we provide free samples for qualified buyers. Please contact our sales team with your requirements, and we will arrange shipment.
