Fully Automatic MVR Evaporation and Crystallization System for Lithium Extraction With PLC HMI
Product Spotlights
Fully automatic MVR evaporation and crystallization system for lithium extraction, featuring energy-saving up to 70% via mechanical vapor recompression, PLC HMI touch control, corrosion-resistant materials, and compact skid design. Customizable capacity, low maintenance, and backed by ISO-certified manufacturer with global export experience.
US$ 2890 - 859000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Application:
Other, Lithium extraction
Certification:
ISO9001, Other, SA8000, ISO14000
Control System:
PLC + HMI (touch screen, fully automatic)
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
20 days
Related Products
-
316L Stainless Steel MVR Evaporation and Crystallization System for Lithium Hydroxide ProductionUS$ 2890 - 859000MOQ: 1 Combo -
1 Year Warranty MVR Evaporation and Crystallization System for Lithium Extraction With Technical SupportUS$ 2890 - 859000MOQ: 1 Combo
-
220V MVR Evaporation and Crystallization Unit for Lithium Brine Processing, Automatic OperationUS$ 2890 - 859000MOQ: 1 Combo
-
PLC Controlled MVR Evaporation and Crystallization System for Lithium Extraction, 304SSUS$ 2890 - 859000MOQ: 1 Combo
-
MVR Evaporation and Crystallization System for Battery Grade Lithium Carbonate ProductionUS$ 2890 - 859000MOQ: 1 Combo
Application
Other, Lithium extraction
Certification
ISO9001, Other, SA8000, ISO14000
Control System
PLC + HMI (touch screen, fully automatic)
Evaporation Capacity
Customizable (e.g., 5-50 t/h)
Material of Construction
Stainless steel 316L / Titanium / Duplex (optional)
Power Supply
380V/50Hz/3P (customizable)
Compressor Type
Centrifugal / Roots blower (depending on capacity)
MVR Technology
Mechanical Vapor Recompression, energy-saving up to 70%
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – Your Trusted Partner in Lithium Extraction Solutions
Since 2015, we have been dedicated to providing advanced environmental and industrial equipment, with a focus on MVR evaporation and crystallization technology. Our Fully Automatic MVR Evaporation and Crystallization System for Lithium Extraction is designed to meet the highest standards of efficiency, reliability, and automation. Backed by a 10,000–30,000 m² factory, 201–300 skilled employees, and annual export value exceeding US$10 million, we deliver solutions that optimize lithium recovery while reducing energy consumption and operational costs. This system is the result of years of R&D and field experience, incorporating PLC HMI control for seamless operation in challenging environments.
Key Features & Benefits
Technical Specifications (Typical – Customizable)
Why Choose Qingdao Conqinphi?
Frequently Asked Questions (FAQ)
Since 2015, we have been dedicated to providing advanced environmental and industrial equipment, with a focus on MVR evaporation and crystallization technology. Our Fully Automatic MVR Evaporation and Crystallization System for Lithium Extraction is designed to meet the highest standards of efficiency, reliability, and automation. Backed by a 10,000–30,000 m² factory, 201–300 skilled employees, and annual export value exceeding US$10 million, we deliver solutions that optimize lithium recovery while reducing energy consumption and operational costs. This system is the result of years of R&D and field experience, incorporating PLC HMI control for seamless operation in challenging environments.
Key Features & Benefits
- MVR (Mechanical Vapor Recompression) Technology – Reuses vapor heat to drastically reduce energy consumption (up to 70% less than traditional multi-effect evaporation).
- Fully Automatic PLC HMI Control – Touch-screen interface with intuitive operation; real-time monitoring of temperature, pressure, flow, and concentration; alarm and data logging functions.
- Designed for Lithium Extraction – Handles high-concentration brine, efficiently separates lithium salt crystals, and achieves high recovery rates.
- Corrosion-Resistant Materials – Available in SS316L, titanium, or duplex stainless steel to withstand aggressive chemical environments.
- Compact & Modular Design – Skid-mounted for easy installation, minimal footprint, and quick integration into existing production lines.
- Low Maintenance – High-quality compressor, anti-scaling design, and CIP cleaning option reduce downtime.
- Compliance & Certifications – Manufactured under ISO9001, ISO14000, OHSAS18001, SA8000, and other international standards (full list available upon request).
Technical Specifications (Typical – Customizable)
| Parameter | Value / Range |
| Evaporation Capacity | 5 – 50 t/h (customizable) |
| Operating Temperature | 60 – 120 °C |
| Compressor Type | Centrifugal / Roots blower |
| Power Consumption | Energy saving ≥ 70% compared to traditional evaporation |
| Control System | Siemens / Mitsubishi PLC + HMI (touch screen) |
| Material of Construction | SS316L / Titanium / Duplex (optional) |
| Crystallization Method | Forced circulation / DTB (optional) |
| Certification | ISO9001, ISO14000, OHSAS18001, SA8000, HACCP, etc. |
Why Choose Qingdao Conqinphi?
- Over 8 years of experience in MVR evaporation and crystallization.
- Factory area of 10,000–30,000 m² with advanced processing equipment.
- Annual export value US$10–50 million, serving clients across North America, South America, Europe, Asia, Africa, and Oceania.
- Stringent quality control – all products undergo factory testing before shipment.
- Global after-sales support: on-site installation guidance, commissioning, and training.
Frequently Asked Questions (FAQ)
-
What types of lithium-containing solutions can this system handle?
It is suitable for brine, leach solutions, and mother liquor from lithium carbonate/hydroxide production, with high chloride or sulfate content. -
How energy-efficient is the MVR system compared to multi-effect evaporation?
Typically saves 60–70% of energy, as the compressor recycles vapor heat instead of using fresh steam. -
Can the system be customized for different capacities?
Absolutely. We offer design from 5 t/h to 50 t/h or more, and can adapt to your specific site conditions. -
What is the automation level? Can remote monitoring be added?
Standard PLC HMI provides full automation with touch control. Remote monitoring via SCADA is optional. -
How often does the system require maintenance?
With proper operation, major maintenance intervals are 12–18 months. The system includes CIP cleaning capability to reduce scaling. -
Do you provide installation and commissioning services?
Yes, our engineers can supervise installation and perform commissioning at your site. Training for operators is included. -
What certifications do you hold?
We are certified under ISO9001, ISO14000, OHSAS18001, SA8000, HACCP, and others. Specific certificates are available upon request. -
What is the typical delivery time?
Depending on capacity and customization, lead time ranges from 60 to 120 days after order confirmation.
