Multi 3510 Portable Multi-Parameter Water Quality Analyzer – WTW
Product Overview
The Multi 3510 IDS is a high-quality, portable digital multi-parameter analyzer from WTW. It supports multiple channels and allows flexible combinations of different digital sensors to measure parameters such as pH/ORP, dissolved oxygen, conductivity, turbidity, and more. With wireless probe connectivity, it is ideal for a wide range of field applications.
Key Features:
Wireless connection to IDS sensors – no cables required
Automatic sensor recognition – calibration data and probe settings are stored directly in the sensor
Compatible with multi-parameter probes MPP 910 IDS and MPP 930 IDS
USB interface for convenient data transfer
Rechargeable battery function
Galvanically isolated probes to avoid signal interference
Data storage capacity: up to 10,000 datasets
Technical Specifications
Model |
Multi 3510 IDS |
Multi 3620 IDS |
Multi 3630 IDS |
Display |
LCD graphic display |
Same |
Same |
Parameters |
pH/ORP, DO, O₂ saturation, O₂ partial pressure, conductivity, resistivity, salinity, TDS, turbidity |
Same |
Same |
Measuring range |
Depends on IDS sensor |
Same |
Same |
Data storage |
Manual: 500 / Automatic: 4,500 |
Manual: 500 / Automatic: 10,000 |
Manual: 500 / Automatic: 10,000 |
Channels |
1 |
2 |
3 |
Data logger |
Manual / time-controlled |
Same |
Same |
Interfaces |
Micro USB-B |
Micro USB-B, USB-A (for storage & printer) |
Same as 3620 |
Protection class |
IP 67 |
IP 67 |
IP 67 |
Power supply |
4×1.5V AA or 4×1.2V NiMH (rechargeable) or USB |
4×1.5V AA, 4×1.2V NiMH, mains adapter, or USB |
Same as 3620 |
MPP IDS Multi-Parameter Deep Water Sensors
The MPP IDS series are digital multi-parameter sensors designed for deep water measurements. They can be equipped with up to three probes (pH/ORP, dissolved oxygen, conductivity, turbidity). When connected to the Multi 3630 IDS analyzer, they also provide integrated depth measurement. These sensors are widely used in wastewater, lakes, seawater, drilling water, and landfill leachate testing.
Sensor Model |
MPP 910 IDS |
MPP 930 IDS |
Number of probe slots |
1 |
3 |
Parameters |
pH/ORP, DO, O₂ saturation, O₂ partial pressure, conductivity, resistivity, salinity, TDS, turbidity, depth, temperature |
Same |
Depth range |
0.05 – 100 m (with pressure & density compensation for seawater) |
Same |
Temperature compensation |
Yes |
Yes |
Depth resolution |
0.05 m |
0.05 m |
Depth accuracy |
±0.25 m |
±0.25 m |
Material |
POM, stainless steel |
Same |
For any further technical or ordering information, please contact your local WTW representative.
