Anping Xinye Metal Wire Mesh Products Co., Ltd, based in Hengshui, Hebei, China, is a trusted manufacturer of road safety solutions. Our Q235 Steel Two Three Wave Road Safety Guardrail is engineered to provide reliable protection for highways, combining robust material with advanced wave design. With years of experience in metal fabrication, we deliver guardrails that meet international safety standards while offering cost-effective performance. This product is widely used in highway projects, rural roads, and parking facilities to absorb impact and redirect vehicles safely.
The guardrail features a unique two-wave and three-wave profile, which enhances structural rigidity without compromising flexibility. Made from premium Q235 steel, it offers excellent tensile strength and durability. The surface is hot-dip galvanized to resist corrosion, ensuring a long service life even in harsh environments. Each panel is manufactured with precision to ensure seamless installation and consistent performance.
Key Features & Technical Specifications
- Material: Q235 steel – high strength, good weldability.
- Wave design: Two-wave and three-wave options for different impact levels.
- Surface treatment: Hot-dip galvanized (≥85μm) or powder coated (optional).
- Standard length: 4000mm per panel (custom sizes available).
- Thickness range: 2.5mm, 3.0mm, 3.5mm, 4.0mm.
- Height: 850mm from ground (standard).
- Installation: Compatible with standard post spacings (1.5m – 2.0m).
- Application: Highways, expressways, dangerous curves, bridges.
| Parameter | Value |
|---|---|
| Material | Q235 Steel |
| Wave Type | Two-wave / Three-wave |
| Panel Length | 4000mm (customizable) |
| Thickness | 2.5mm – 4.0mm |
| Height | 850mm |
| Surface | Hot-dip galvanized / Powder coated |
| Standard | AASHTO M180 / RAL-RG 620 (upon request) |
Benefits for your project:
- Enhanced vehicle containment – the wave design effectively absorbs and redirects impact forces.
- Long service life – galvanized coating prevents rust, reducing maintenance costs.
- Quick installation – pre-drilled holes and standardized dimensions simplify assembly.
- Versatile application – suitable for both straight sections and curved roadways.
- Cost-effective – high-strength Q235 steel offers excellent value for large-scale projects.
Our guardrails undergo rigorous quality control at every production stage. With a dedicated R&D team, we continuously improve product performance. Anping Xinye Metal Wire Mesh Products Co., Ltd has supplied guardrails to numerous highway projects across China and overseas. Our location in Hengshui, Hebei – a well-known industrial base for metal products – ensures competitive pricing and reliable supply chain. We offer flexible customization options, including special lengths, colors, and packaging. Contact us today for a quote or technical consultation. Let us help you make your roads safer.
Frequently Asked Questions (FAQ)
A: Two-wave guardrails are lighter and suitable for lower speed roads, while three-wave guardrails have higher impact resistance and are used on highways and high-speed areas.
A: Yes, we can produce panels in custom lengths based on your project requirements. Standard length is 4000mm.
A: Hot-dip galvanized with a minimum thickness of 85μm is recommended for corrosive environments. We also offer epoxy coating as an option.
A: The guardrail panels are sold separately. We can supply matching posts (C-section or I-beam) upon request.
A: Typically MOQ is 100 meters, but we can discuss smaller quantities for sample orders.
A: Under normal conditions, hot-dip galvanizing can provide 20-30 years of maintenance-free service life, depending on the environment.
A: Yes, we provide detailed installation drawings and technical support. On-site training is available upon request.
A: We can supply products meeting AASHTO M180 or RAL-RG 620 standards. Certificates are available upon request.
