Anping Xinye Metal Wire Mesh Products Co., Ltd, based in Hengshui, Hebei, China, is proud to offer our Complete Galvanized Guardrail Set with Posts and Bolts — a comprehensive safety solution designed for roads, highways, parking lots, and industrial perimeters. This guardrail set delivers exceptional durability, easy installation, and long-lasting corrosion resistance, thanks to the high-grade hot-dip galvanized finish. Engineered for maximum impact resistance, each component is precision-manufactured to meet international safety standards, providing reliable protection for vehicles and pedestrians alike.
Our galvanized guardrail set is a complete system that includes everything needed for a secure installation: W-beam rails, sturdy posts, and all necessary bolts, nuts, and washers. The hot-dip galvanization process ensures a uniform zinc coating that protects against rust, even in harsh outdoor environments. Whether you are securing a new highway project or upgrading an existing barrier, this set offers a cost-effective and low-maintenance answer to traffic safety.
Key Features & Technical Specifications
- Complete Set: Includes rails, posts, bolts, nuts, and washers — no additional parts needed.
- Hot-Dip Galvanized: Zinc coating thickness of 85–150 μm per ASTM A123, offering superior corrosion resistance.
- W-Beam Design: Corrugated profile absorbs and redirects impact energy, reducing vehicle damage.
- High-Strength Steel: Q235 or Q345 steel grade, with tensile strength ≥ 370 MPa.
- Easy Installation: Pre-drilled bolt holes and simple post-anchoring system (anchor bolts or concrete base).
- Customizable Dimensions: Rail length, post height, and spacing can be tailored to your project requirements.
- Low Maintenance: Galvanized surface requires no painting; occasional cleaning is sufficient.
- Wide Application: Suitable for highways, bridges, parking lots, factories, warehouses, and residential areas.
| Parameter | Standard Specification | Customization |
|---|---|---|
| Rail Length | 4.0 m (13.1 ft) | 2.0 – 6.0 m available |
| Rail Width | 310 mm (12.2 in) | Fixed – W-beam profile |
| Rail Thickness | 2.5 mm – 3.0 mm | 2.0 – 4.0 mm optional |
| Post Height | 900 mm (35.4 in) | 600 – 1200 mm |
| Post Section | C-shape: 100×50×3.0 mm | I-beam or tube available |
| Bolt Size | M16 × 45 mm | M12 – M20 optional |
| Zinc Coating | 85 – 150 μm | Up to 200 μm available |
| Post Spacing | 2.0 m (6.6 ft) | 1.0 – 2.5 m adjustable |
Each guardrail set is manufactured under strict quality control at our facility in Hengshui, Hebei. The galvanization process ensures a uniform, thick coating that adheres to ASTM A123 standards, providing long-term protection against corrosion, UV radiation, and mechanical wear. The bolt-and-post connection system is designed for quick assembly by two workers, reducing labor costs and installation time by up to 30% compared to traditional welded barriers.
Why Choose Our Complete Galvanized Guardrail Set?
- Time-Saving: All components pre-cut, pre-drilled, and packaged together — no on-site fabrication needed.
- Cost-Effective: Bulk packaging and direct factory pricing reduce overall project costs.
- Versatile: Compatible with both concrete foundations and direct ground anchoring.
- Safety Compliance: Meets international road safety standards (e.g., EN 1317, MASH TL-3 equivalent — available upon request).
- Eco-Friendly: Galvanized steel is 100% recyclable; no harmful coatings or paints.
Anping Xinye Metal Wire Mesh Products Co., Ltd. has been a trusted manufacturer of metal safety products for over 20 years. Located in the famous wire mesh industry hub of Anping, Hebei, we leverage advanced production lines and a skilled workforce to deliver consistent quality. Our Complete Galvanized Guardrail Set has been exported to more than 50 countries, including the USA, Canada, Australia, and Southeast Asia, with positive feedback from contractors and government agencies. We offer flexible shipping options (FOB, CIF, EXW) and can provide sample sets for testing before bulk orders.
Don't compromise on safety — choose a guardrail set that combines strength, durability, and ease of installation. Contact us today for a quotation or technical consultation. Our team is ready to assist with custom dimensions, special packaging, or any questions you may have. With Anping Xinye, you get more than just a product — you get a reliable partner for your infrastructure projects.
Frequently Asked Questions (FAQ)
Q: What is the minimum order quantity (MOQ) for this guardrail set?
A: Our standard MOQ is 1 set (which includes 10 rails, 20 posts, and corresponding bolts). However, we can accommodate smaller sample orders for testing purposes.
Q: Can I customize the length of the rails or the height of the posts?
A: Yes, we offer full customization. Rail lengths can be adjusted from 2m to 6m, and post heights from 600mm to 1200mm. Please provide your drawings or requirements.
Q: How is the guardrail installed? Do I need special tools?
A: Installation is straightforward using standard tools (wrenches, socket set, and a level). The posts are anchored into the ground using concrete or ground screws. Each set comes with an installation guide.
Q: Is the guardrail suitable for high-speed highway applications?
A: Absolutely. Our guardrail set meets the requirements of TL-3 containment level (equivalent to MASH) when installed per specifications. It is designed to redirect vehicles safely at speeds up to 100 km/h.
Q: What is the lifespan of the galvanized coating?
A: In a typical outdoor environment, the hot-dip galvanized coating can last 20–30 years before requiring maintenance. Salt spray environments may reduce this to 15–20 years; periodic rinsing can extend its life.
Q: Do you provide certificates or test reports for the materials?
A: Yes, we can provide mill test certificates for the steel, galvanizing thickness reports, and load test data upon request. These documents are available for each batch.
Q: Can I get a sample before bulk order?
A: Yes, we offer sample sets (e.g., one rail + two posts + bolts) at a reasonable price. The sample cost can be deducted from your first bulk order.
Q: What is the packing method for export?
A: Rails are bundled and strapped together; posts are packed in wooden crates to prevent damage; bolts and small parts are sealed in plastic bags inside cartons. All packages are marked with product details and handling instructions.
