Help CenterAutomatic ZLD Water Treatment System 1000L/H Capacity Touch Screen Operation
Product Spotlights
Related Products
-
Semi-Automatic ZLD Water Treatment System 500L/H With Pre-Filter and UV SterilizationUS$ 3240 - 879000MOQ: 1 Combo -
Compact ZLD Water Treatment System With IP65 Waterproof Enclosure and 2000LPDUS$ 3240 - 879000MOQ: 1 Combo
-
ZLD Water Treatment System With Mill Test Report and Factory Direct ServiceUS$ 3240 - 879000MOQ: 1 Combo
-
Efficient Sludge Dehydrator Machine for MVR / Multi-Effect Sewage Treatment EquipmentUS$ 2140 - 7500MOQ: 1 Combo
-
Vacuum Wastewater Treatment Plant for Sewage TreatmentUS$ 400 - 14300MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015, is a professional manufacturer specialized in water treatment solutions. With a factory spanning 10,000–30,000 square meters and a team of 201–300 employees, we annually export over US$10–50 million to markets across North America, South America, Europe, Asia, Africa, and Oceania. Our Automatic ZLD Water Treatment System with 1000L/H capacity and touch screen operation represents the pinnacle of efficient zero-discharge technology, designed to help industries achieve stringent environmental compliance while maximizing water reuse and minimizing waste.
This system integrates advanced evaporation, crystallization, and solid-liquid separation processes to achieve zero liquid discharge (ZLD). It is ideal for treating high-salinity wastewater from industries such as chemical, pharmaceutical, textile, food processing, and power generation. The intuitive touch screen interface allows operators to monitor and control all parameters in real time, ensuring stable performance and easy maintenance.
Key Features & Technical Advantages
- Zero Liquid Discharge – Recovers up to 95% of water as clean distillate, leaving only dry solids or concentrated brine, eliminating wastewater discharge.
- Touch Screen PLC Control – User-friendly HMI with auto-diagnostics, alarm history, and remote monitoring capability (optional).
- High Efficiency Energy Recovery – Integrated heat exchangers and vapor compression reduce energy consumption by up to 30% compared to conventional ZLD systems.
- Robust Material Construction – Main components are made of stainless steel (SS304/SS316L) or carbon steel with anti-corrosion coating, ensuring long service life.
- Modular Design – Compact footprint, easy to install and expand. Pre-assembled skid-mounted units reduce on-site installation time.
- Multi-Stage Treatment – Includes pretreatment (filtration, softening), reverse osmosis (RO), brine concentrator, and crystallizer, all integrated into a single automated system.
- Low Operating Cost – Automatic cleaning cycles, minimal chemical dosing, and low maintenance requirements.
- Compliance with Environmental Standards – Helps meet local discharge regulations and supports sustainability goals.
Technical Specifications
| Parameter | Specification |
|---|---|
| Treatment Capacity | 1000 L/H (24 m³/day) |
| Feed Water TDS | Up to 50,000 mg/L (customizable) |
| Recovery Rate | ≥95% |
| Power Supply | 380V / 50Hz, 3-phase (optional 220V/60Hz) |
| Installed Power | Approx. 45–60 kW (depending on configuration) |
| Control System | Touch Screen PLC (Siemens / Mitsubishi optional) |
| Main Material | SS304 / SS316L / Carbon Steel |
| Dimensions (L×W×H) | 5.0m × 2.0m × 2.5m (approx., skid-mounted) |
| Operating Temperature | 5–45°C |
| Certifications | ISO9001, ISO14000, OHSAS18001, SA8000, and others |
Customer Benefits
By implementing this ZLD system, industrial users can significantly reduce fresh water intake, eliminate wastewater discharge penalties, and recover valuable by-products. The touch screen operation simplifies training and reduces human error, while the robust construction ensures long-term reliability even in harsh conditions. The modular design allows for easy capacity expansion in the future.
Trust & Credibility
Qingdao Conqinphi Environmental Technology Group is a certified manufacturer with multiple international quality management system certifications, including ISO9001, ISO14000, OHSAS18001, and SA8000. Our factory covers 10,000–30,000 m² with a dedicated R&D team and 200+ skilled workers. With annual export value exceeding US$10 million, we have supplied water treatment solutions to clients in over 50 countries. We are committed to providing customized, reliable, and cost-effective ZLD systems that meet your specific wastewater challenges. Contact us today for a free consultation and quotation.
Frequently Asked Questions
-
Q: What types of wastewater can this system treat?
A: It is suitable for high-salinity industrial wastewater from chemical, pharmaceutical, textile, food processing, and desalination plants. Custom pretreatment may be required for specific contaminants. -
Q: How long does installation take?
A: The skid-mounted system is pre-assembled and tested. On-site installation and commissioning typically take 2–4 weeks, depending on site conditions. -
Q: What is the energy consumption per 1000 liters?
A: Approximately 45–60 kWh, depending on feed water TDS and recovery rate. Our energy recovery features can reduce this by up to 30%. -
Q: Is the system fully automatic?
A: Yes, the touch screen PLC controls all operations including start/stop, cleaning cycles, and alarm management. Remote monitoring is optional. -
Q: What maintenance is required?
A: Regular inspection of pumps, valves, and membranes; automatic cleaning cycles are built-in. We recommend quarterly preventive maintenance. -
Q: Can the system be customized for different capacities?
A: Absolutely. We offer modular designs ranging from 500 L/H to 50,000 L/H. Contact us for a tailored solution. -
Q: What certifications does your company hold?
A: We are certified with ISO9001, ISO14000, OHSAS18001, SA8000, and others. Specific certifications can be provided upon request. -
Q: What is the warranty period?
A: Standard warranty is 12 months from commissioning. Extended warranty and after-sales service contracts are available.
