Welcome to Hemaokang Steel (Shandong) Co., Ltd. – your reliable partner for high-quality galvanized steel products. Our DX51D+Z 0.5mm Thickness Z275 Hot Dipped Galvanized Steel Coil with Regular Spangle is designed to meet the rigorous demands of construction, roofing, and industrial applications. With a zinc coating of 275 g/m², this coil offers exceptional corrosion resistance and durability, ensuring long-lasting performance even in challenging environments. Backed by our ISO9001-certified quality management system, we deliver consistent quality and precision that you can trust.
Key Features & Technical Specifications
- Superior Corrosion Protection: Z275 zinc coating (275 g/m² total both sides) provides excellent resistance against rust and oxidation, ideal for outdoor and humid conditions.
- Optimal Thickness: 0.5mm thickness balances strength and formability, suitable for roll forming, bending, and stamping processes.
- Regular Spangle Finish: Classic spangle pattern offers a uniform appearance and is compatible with further painting or coating if required.
- High Ductility: DX51D+Z grade ensures good elongation and workability, reducing cracking during fabrication.
- Wide Width Range: Available from 600 mm to 1500 mm, customizable to meet your specific project needs.
- Strict Quality Control: Each coil undergoes tensile testing, zinc coating weight check, and surface inspection to ensure compliance with international standards.
| Parameter | Value |
|---|---|
| Material Grade | DX51D+Z (EN 10346) |
| Thickness | 0.5 mm (±0.05 mm tolerance) |
| Zinc Coating Weight | Z275 (275 g/m², triple-spot test) |
| Spangle Type | Regular Spangle |
| Width | 600 - 1500 mm (customizable) |
| Coil Inner Diameter | 508 mm or 610 mm (optional) |
| Coil Weight | 3 - 10 tons per coil |
| Surface Treatment | Passivated / Oiled (optional) |
| Tensile Strength | 270 - 500 MPa (depending on grade) |
| Elongation | ≥ 22% |
Customer Benefits
- Cost-Effective Solution: 0.5mm thickness reduces material weight while maintaining strength, lowering transportation and structural support costs.
- Easy Fabrication: Regular spangle and DX51D+Z composition allow for smooth cutting, punching, and welding, saving time and tool wear.
- Long Service Life: Z275 coating provides up to 20+ years of protection in moderate environments, reducing maintenance frequency.
- Versatile Applications: Suitable for roofing sheets, wall panels, garage doors, HVAC ducts, electrical cabinets, and automotive components.
- Consistent Quality: Every coil is produced in a fully automated production line with continuous annealing and hot-dip galvanizing process, ensuring uniform coating and mechanical properties.
Why Choose Hemaokang Steel?
Founded in 2025, Hemaokang Steel (Shandong) Co., Ltd. has quickly established itself as a trusted supplier in the global steel market. With an annual export value of US$50 million to US$100 million and a dedicated team of 51–100 employees, we serve clients in North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and beyond. Our ISO9001:2015 certification guarantees a robust quality management system from raw material sourcing to final delivery. We maintain strict inventory control and offer flexible packaging options (including waterproof wrapping, edge protection, and steel strapping) to ensure your coils arrive in perfect condition. Whether you need standard sizes or custom specifications, our experienced sales team provides prompt quotes and reliable after-sales support. Contact us today to discuss your project requirements – we are committed to delivering excellence in every coil.
Frequently Asked Questions (FAQ)
Q1: What does DX51D+Z stand for?
A: DX51D+Z is a European standard designation for hot-dip galvanized steel. 'DX' indicates steel for cold forming, '51' denotes a minimum yield strength of 140 MPa, 'D' means hot-dip coating, and '+Z' indicates zinc coating. This grade offers excellent formability and weldability.
Q2: What is the difference between regular spangle and zero spangle?
A: Regular spangle has visible zinc crystals on the surface, giving a classic patterned look. Zero spangle (or minimized spangle) has a more uniform matte appearance. Regular spangle is often preferred for applications where appearance is not critical, or for further painting, as it provides good adhesion.
Q3: Can this coil be used for roofing?
A: Yes, 0.5mm thickness with Z275 coating is commonly used for residential and commercial roofing sheets, especially in areas with moderate corrosion risk. The material can be roll-formed into corrugated or trapezoidal profiles.
Q4: What is the typical lead time for this product?
A: For standard sizes (width 1000-1250mm, coil weight 5-8 tons), lead time is usually 15-20 working days after order confirmation. Custom sizes may require 25-30 working days. We recommend contacting our sales team for current stock availability.
Q5: Do you provide material test certificates?
A: Yes, we provide mill test certificates (MTC) in accordance with EN 10204. Tests include chemical composition, tensile properties, coating weight, and surface condition. Third-party inspection is also available upon request.
Q6: How is the coil packaged for export?
A: Our standard export packaging includes: inner plastic film wrapping, waterproof kraft paper, steel strapping with edge protectors, and optional wooden pallet or steel crate for small coils. We also offer custom packaging as per customer requirements.
Q7: Can you supply other thicknesses, such as 0.3mm or 1.0mm?
A: Yes, we offer a wide range of thicknesses from 0.2mm to 2.5mm in hot-dipped galvanized steel. The Z275 coating is available for thicknesses ≥0.5mm. Please inform our sales team of your specific requirements.
Q8: What payment terms do you accept?
A: We accept T/T (30% deposit, 70% balance before shipment), L/C at sight, and other negotiable terms subject to credit evaluation. For long-term partners, we can discuss open account possibilities.
