Anping Xinye Metal Wire Mesh Products Co., Ltd, located in the renowned wire mesh industrial base of Hengshui, Hebei, China, takes pride in offering high-quality 80x100mm Galvanized Double Twisted 2x1x1m Hexagonal Gabion Wire Mesh. This product is engineered to meet the rigorous demands of civil engineering, landscaping, and erosion control projects worldwide. Our double-twisted hexagonal mesh combines strength, flexibility, and corrosion resistance, ensuring long-lasting performance in both dry and aquatic environments. Whether you need to construct retaining walls, channel linings, or decorative gabion structures, this mesh provides a reliable and cost-effective solution.
Each panel is manufactured from premium galvanized steel wire, with a typical wire diameter of 2.0mm (customizable per your requirements). The hexagonal opening size of 80x100mm offers optimal balance between containment of fill materials (such as stones or rocks) and structural integrity. The double-twisting technique ensures that the mesh maintains its shape under load, preventing unraveling even when cut. Our standard panel size of 2x1x1m (length x width x height) is pre-assembled with selvedge wires for easy installation; however, we can also supply rolls or custom sizes upon request.
Key Features & Technical Specifications
- Material: Low-carbon steel wire, double-twisted into hexagonal mesh.
- Surface Treatment: Hot-dip galvanized (standard) or electro-galvanized (optional) for superior corrosion resistance.
- Mesh Opening: 80mm x 100mm (nominal).
- Wire Diameter: Typically 2.0mm (range 1.6mm–2.5mm available).
- Panel Dimensions: 2m (length) x 1m (width) x 1m (height) – can be customized.
- Selvedge Wires: Edge wires of larger diameter (e.g., 2.7mm) for enhanced strength and easy connection.
- Packaging: Compressed bundles on pallets for efficient transport.
- Compliance: Meets industry standards for gabion mesh (e.g., ASTM A975, EN 10223-8).
| Parameter | Value |
|---|---|
| Mesh Opening (W x L) | 80mm x 100mm |
| Standard Wire Diameter | 2.0mm (custom: 1.6–2.5mm) |
| Panel Size (L x W x H) | 2m x 1m x 1m |
| Tensile Strength (wire) | 350–550 N/mm² (depending on material) |
| Zinc Coating Mass | > 245 g/m² (hot-dip galvanized) |
| Weight per Panel (approx.) | ~8–10 kg (depending on wire dia.) |
Advantages & Customer Benefits
- Exceptional Durability: Double-twisted hexagonal design prevents unraveling, even when cut, ensuring long service life.
- Corrosion Resistance: Hot-dip galvanizing provides robust protection against rust and environmental degradation, ideal for coastal or high-moisture areas.
- Versatile Applications: Suitable for gabion retaining walls, riverbank protection, slope stabilization, and decorative landscaping.
- Easy Installation: Pre-assembled panels with selvedge wires allow quick connection using spiral binders or tying wire, reducing labor time.
- Customizable: We offer various wire diameters, panel sizes, and coating options to meet your specific project requirements.
- Eco-Friendly: Gabion structures promote vegetation growth and drainage, making them a sustainable choice for erosion control.
Trust & Reliability from Anping Xinye
With years of experience in the wire mesh industry, Anping Xinye Metal Wire Mesh Products Co., Ltd has built a reputation for consistent quality and timely delivery. Our factory in Hengshui, Hebei, is equipped with advanced weaving machines and strict quality control processes. We have supplied millions of square meters of gabion mesh to clients across North America, Europe, Southeast Asia, and the Middle East. Our team of engineers ensures every batch meets the required specifications, and we offer flexible order quantities—from small trial orders to large container loads. Contact us today for a competitive quote and let us support your next infrastructure project.
Frequently Asked Questions (FAQ)
-
What is the difference between hot-dip galvanized and electro-galvanized gabion mesh?
Hot-dip galvanizing provides a thicker zinc coating, offering superior corrosion resistance, especially in harsh environments. Electro-galvanizing is thinner and more economical for indoor or dry applications. We recommend hot-dip for outdoor and marine use. -
Can I get custom panel sizes other than 2x1x1m?
Yes, we can manufacture panels in various lengths, widths, and heights. Please provide your specific dimensions for a quotation. -
How is the mesh packaged for shipping?
Panels are typically compressed into bundles and strapped onto pallets. This reduces volume and protects the mesh during transit. Custom packaging is available upon request. -
What is the typical lead time for an order?
For standard products, our lead time is 15–25 days after receiving the deposit, depending on quantity. Custom orders may require additional time. -
Is the mesh suitable for use in saltwater environments?
Yes, hot-dip galvanized mesh is highly resistant to saltwater corrosion. For extreme conditions, we also offer PVC-coated or stainless steel options. -
How do I connect the panels together?
We provide spiral binders, tie wires, or clips that interlock the selvedge edges. Detailed installation instructions are available. -
Do you provide samples?
Yes, we offer free samples (shipping cost may apply) for quality evaluation. Please contact our sales team to arrange. -
What is the minimum order quantity (MOQ)?
The MOQ for gabion mesh panels is typically 50 pieces, but we can accommodate smaller quantities for trial purposes.
Ready to purchase? Contact Anping Xinye Metal Wire Mesh Products Co., Ltd today for a detailed quote, technical support, or to discuss your custom requirements. We look forward to partnering with you!
