As a leading manufacturer from Anping Xinye Metal Wire Mesh Products Co., Ltd in Hengshui, Hebei, China, we specialize in producing high-quality Double Twisted Steel Wire Rope Mesh engineered for mining slope stability and protection. Our mesh combines the strength of steel wire rope with the flexibility of double-twisted construction, delivering reliable performance in demanding geotechnical environments. With over 15 years of experience in wire mesh fabrication, we supply cost-effective solutions that help mining operations reduce landslide risks and maintain safe working conditions.
This product is specifically designed to reinforce slopes, catch falling rocks, and stabilize loose soil surfaces in open-pit mines, quarries, and infrastructure projects. The double-twisted structure ensures even load distribution, while the high-tensile steel wire provides excellent durability against corrosion and mechanical stress. Below we detail the key features, technical specifications, and benefits that make our mesh a preferred choice for mining engineers.
Key Features & Technical Specifications
- Material: High-tensile steel wire (galvanized or PVC-coated) with a minimum tensile strength of 1770 N/mm² (optional).
- Wire Diameter: Available from 2.0 mm to 4.0 mm, customizable based on load requirements.
- Mesh Opening: Standard sizes range from 50 mm × 50 mm up to 200 mm × 200 mm. Other dimensions can be supplied upon request.
- Panel Size: Typical panels are 2 m × 3 m, 3 m × 6 m, or custom dimensions to match site-specific slope geometry.
- Surface Treatment: Hot-dip galvanizing (HDG) or electro-galvanizing for enhanced corrosion resistance in harsh mining environments.
- Construction: Double-twisted rhombic mesh structure, which prevents unraveling even if a single wire breaks.
- Connection: Panels are interconnected using spiral binders or hog rings for continuous coverage.
- Standards: Manufactured in accordance with general international geotechnical mesh standards (e.g., ASTM A975, EN 10223-3 – available upon request).
| Parameter | Standard Range | Notes |
|---|---|---|
| Wire Diameter | 2.0 – 4.0 mm | Thicker wires for higher load capacity |
| Mesh Opening Size | 50×50 – 200×200 mm | Smaller openings for finer debris |
| Tensile Strength (Wire) | ≥ 1770 N/mm² | Optional, can be customized |
| Zinc Coating Weight | ≥ 250 g/m² (HDG) | Ensures long-term corrosion protection |
| Panel Weight (approx.) | 1.5 – 4.5 kg/m² | Depends on wire diameter and opening |
Advantages for Mining Slope Stability
- High Load-Bearing Capacity: The double-twisted steel wire rope construction distributes forces evenly, allowing the mesh to absorb significant impact energy from rockfalls.
- Flexibility & Conformability: The mesh easily conforms to irregular slope surfaces, ensuring full contact and effective soil retention.
- Corrosion Resistance: Hot-dip galvanizing provides a robust protective layer, extending service life in acidic or humid mining environments.
- Easy Installation: Lightweight panels can be handled manually or with light machinery, reducing labor costs and installation time.
- Low Maintenance: Once installed, the mesh requires minimal upkeep; periodic inspections are sufficient to ensure continued performance.
- Environmentally Friendly: The mesh allows vegetation to grow through, promoting natural slope stabilization and erosion control.
- Cost-Effective: Compared to concrete or shotcrete solutions, our mesh offers a more economical alternative with comparable performance.
In addition to slope stability, our double twisted wire rope mesh is widely used for rockfall protection barriers, avalanche prevention, landslide mitigation, and mine pit wall reinforcement. It can be combined with anchors, gabions, or other geotechnical systems to create a comprehensive slope stabilization solution.
Why Choose Anping Xinye?
Anping Xinye Metal Wire Mesh Products Co., Ltd has been serving the global mining and construction industry since 2005. Our factory in Hengshui, Hebei, covers an area of 12,000 square meters and is equipped with advanced automatic wire mesh weaving machines. We produce over 500,000 square meters of double twisted mesh annually, exporting to more than 30 countries including Australia, Chile, South Africa, and Canada.
We maintain strict quality control throughout the manufacturing process – from incoming raw material inspection to final packaging. Each batch is tested for wire tensile strength, zinc coating thickness, and mesh opening accuracy. Our team of 15 quality engineers ensures that every panel meets your project specifications. We also offer customization services for wire diameter, mesh opening, panel size, and coating type to match unique site requirements.
With a commitment to on-time delivery and competitive pricing, we have built long-term partnerships with major mining companies and engineering contractors. Our products are backed by a 12-month warranty against manufacturing defects, and our technical support team is available for installation guidance.
Ready to enhance slope safety at your mine site? Contact us today for a quote or to request a free sample. Our experienced engineers can help you select the right mesh configuration for your specific slope conditions. Let Anping Xinye be your trusted partner in slope protection.
Frequently Asked Questions (FAQ)
-
What is the difference between double twisted wire rope mesh and chain link mesh?
Double twisted wire rope mesh uses a unique rhombic pattern that prevents the mesh from unraveling if a wire breaks, making it much stronger for slope stabilization. Chain link mesh is typically used for fencing and has lower tensile strength. -
Can this mesh be used for steep slopes (over 60 degrees)?
Yes, our mesh is designed for steep slopes. It can be securely anchored to the rock face using bolts or tensioned cables. The flexibility of the mesh allows it to adapt to steep contours. -
What is the typical lifespan of the galvanized mesh in a mining environment?
With hot-dip galvanizing (HDG) of at least 250 g/m², the mesh can last 20–30 years in moderate corrosive conditions. For aggressive acidic environments, we recommend PVC coating or stainless steel options as an upgrade. -
Do you provide installation services or only the material?
We supply the mesh material and can provide detailed installation drawings and guidelines. For large projects, we can recommend qualified local installation contractors upon request. -
What is the minimum order quantity (MOQ)?
Our standard MOQ is 100 square meters per specification. For trial orders, we can accommodate smaller quantities. Please contact our sales team to discuss your needs. -
Can the mesh be cut to custom sizes on site?
Yes, the mesh can be cut with standard bolt cutters or angle grinders. However, we recommend ordering pre-cut panels to avoid waste and ensure proper edge finishing. -
How do you ensure the mesh is securely connected between panels?
Panels are joined using galvanized spiral binders (also called lacing wires) or hog rings. These connections maintain the integrity of the mesh system and are included in the supply. -
Is this product compliant with international standards?
Our mesh is manufactured in accordance with general geotechnical mesh standards such as ASTM A975 and EN 10223-3. Compliance certificates are available upon request for specific projects.
