As a trusted manufacturer since 1998, Anping County Boli Hardware Wiremesh Products Factory takes pride in offering high-quality rail baseplates that meet the stringent requirements of the railway industry. Our Rail Baseplate DIN 9000-1 Standard Compliant Q235B Steel Hot Dip Galvanized 10mm Thickness is engineered to provide reliable support and stability for rail tracks, ensuring long-term performance even under heavy loads and harsh environmental conditions. With annual export values between US$5 million and US$10 million, we serve global markets including North America, Europe, Asia, and Oceania, demonstrating our commitment to excellence and customer satisfaction.
This baseplate is manufactured from premium Q235B steel, known for its excellent weldability and strength, and then undergoes a hot dip galvanizing process to deliver superior corrosion resistance. The 10mm thickness ensures robust load distribution, reducing rail wear and extending track life. Compliance with DIN 9000-1 guarantees dimensional accuracy and interchangeability, making it an ideal choice for railway maintenance, new construction, and track repair projects.
Below we present the key technical specifications and features of our product, providing you with a clear understanding of its capabilities.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | Q235B Steel (equivalent to ASTM A36) |
| Standard | DIN 9000-1 |
| Thickness | 10 mm (0.394 inches) |
| Surface Finish | Hot Dip Galvanized (average coating thickness ≥ 85 μm) |
| Dimensions (L x W) | Customizable – typically 200 mm x 150 mm (subject to customer requirements) |
| Hole Configuration | 4 holes, 24 mm diameter, spacing according to DIN 9000-1 |
| Weight (approx.) | 2.5 kg per piece (based on typical size) |
| Application | Railway track, crane rail, mining rail, port tracks |
Product Features & Benefits
- High Strength & Durability: Made from Q235B steel, our baseplate exhibits excellent tensile strength (370–500 MPa) and yield strength (≥235 MPa), ensuring reliable performance under dynamic train loads.
- Corrosion Protection: The hot dip galvanized coating provides a robust barrier against rust and corrosion, doubling the service life compared to untreated steel. Ideal for outdoor installations, tunnels, and coastal areas.
- Precision Engineering: Every baseplate is manufactured to tight tolerances (hole positions ±0.5 mm, overall dimensions ±1 mm) to guarantee easy installation and alignment with standard rail fastening systems.
- Standard Compliance: Full compliance with DIN 9000-1 ensures compatibility with European railway infrastructure and acceptance by international railway authorities.
- Customizable Options: We offer flexible dimensions, hole patterns, and additional machining (e.g., chamfering, drilling) to meet specific project requirements. Minimum order quantity negotiable.
- Cost-Effective: Direct factory pricing eliminates middleman costs, and our efficient production capacity (up to 50,000 pieces per month) ensures timely delivery even for large orders.
Quality Assurance & Trust
With over 25 years of manufacturing experience, Anping County Boli Hardware Wiremesh Products Factory has built a reputation for consistent quality and reliable service. We ship from major Chinese ports including Tianjin, Qingdao, Shanghai, and Foshan, offering flexible logistics solutions. Our products have been exported to more than 20 countries across North America, South America, Europe, Southeast Asia, Africa, and Oceania, with annual export sales reaching US$5–10 million. We perform rigorous in-house inspections on every batch, including dimensional checks, coating thickness tests, and material composition analysis, to ensure that each baseplate meets our high standards.
Our dedicated team is ready to support you with technical advice, sample requests, and customized solutions. Whether you need a small trial order or a large-scale supply contract, we are committed to providing you with the best value and service.
Frequently Asked Questions (FAQ)
-
Q: Can you provide baseplates with different thicknesses?
A: Yes, we can customize thicknesses from 8 mm to 20 mm based on your requirements. Please contact our sales team with your specific needs. -
Q: What is the typical lead time for this product?
A: For standard sizes (10 mm thickness, regular dimensions), lead time is 10–15 days after order confirmation. Customized orders may take 20–25 days depending on complexity. -
Q: What is the minimum order quantity (MOQ)?
A: Our MOQ is 500 pieces for standard sizes. For custom sizes, MOQ is 1000 pieces. Smaller trial orders are welcome for evaluation. -
Q: How are the baseplates packaged for export?
A: Baseplates are packed in pallets with steel strapping, wrapped in plastic film, and protected with edge guards. For fragile coatings, we use additional cushioning material. Custom packaging is available upon request. -
Q: Do you have certificates for DIN 9000-1 compliance?
A: We can provide a Declaration of Conformity based on our manufacturing process and quality control. If a third-party certification is required, we can arrange testing at an additional cost. -
Q: Can you supply samples before bulk order?
A: Yes, we offer free samples (shipping cost borne by buyer) for quality evaluation. Sample lead time is 5–7 days. -
Q: What is the maximum size you can produce?
A: Our standard production capacity covers baseplates up to 400 mm x 300 mm. Larger sizes can be discussed for special projects. -
Q: How do you control the quality of hot dip galvanizing?
A: We strictly follow the specifications of the hot dip galvanizing process, including pre-treatment, zinc bath temperature, and immersion time. Coating thickness is measured per ISO 1461 standards, and we also perform adhesion and uniformity tests.
Choose Anping County Boli Hardware Wiremesh Products Factory for your railway baseplate needs. With our proven track record, competitive pricing, and customer-centric approach, we are confident that our DIN 9000-1 compliant baseplate will exceed your expectations. Contact us today for a quotation or technical consultation!
