From Anping Xinye Metal Wire Mesh Products Co., Ltd – your trusted manufacturer based in Hengshui, Hebei, China – we present our premium Galvanized PVC Stainless Steel Concertina Razor Barbed Wire, available in models BTO-16/18/22/60 and CBT-65. This perimeter security solution combines high-strength materials with a razor-sharp blade design to deliver unmatched deterrence for military zones, correctional facilities, industrial plants, and private estates. Whether you need galvanized, PVC-coated, or stainless steel options, our concertina wire is engineered for long-lasting outdoor performance and quick installation.
Our razor barbed wire is manufactured using advanced automatic winding machines to ensure consistent coil diameter, tight blade spacing, and uniform tension. Each roll undergoes strict quality checks to guarantee that every meter meets your security requirements. With over 15 years of experience in wire mesh products, we provide customized solutions to match your specific perimeter needs.
Key Features & Specifications
- Dual Material Options: Choose from hot-dip galvanized steel (excellent corrosion resistance), stainless steel 304/316 (maximum durability in harsh environments), or PVC-coated wire (available in green, black, or custom colors for aesthetic integration).
- Razor Blade Design: Sharp, tight-edged blades (CBT-65 style) with 65mm spacing between loops, providing a formidable barrier that is difficult to cut or climb.
- Multiple Model Sizes: BTO-16 (16mm blade spacing), BTO-18, BTO-22, BTO-60, and CBT-65 – each designed for different security levels. The smaller the gap, the higher the deterrence.
- Coil Diameter Options: Standard 450mm, 500mm, or 600mm diameter coils; custom diameters available upon request.
- High Tensile Strength: Core wire made from high-carbon steel with tensile strength up to 600-800 N/mm², ensuring the wire resists cutting and deformation.
- Easy Installation: Pre-compressed rolls for convenient transport and quick deployment. Can be mounted on existing fences, walls, or standalone posts.
- Long Service Life: Galvanized coating (≥ 50 g/m²) or PVC thickness (0.3-0.5mm) protects against UV, rain, and temperature extremes, offering 10+ years of outdoor durability.
Technical Specifications (Model Overview)
| Model | Blade Spacing | Coil Diameter | Core Wire Diameter | Common Use |
|---|---|---|---|---|
| BTO-16 | 16mm | 450mm | 2.5mm ±0.05 | High-security prisons, military |
| BTO-18 | 18mm | 500mm | 2.7mm ±0.05 | Industrial zones, airports |
| BTO-22 | 22mm | 500mm | 2.7mm ±0.05 | Perimeter fencing, villas |
| BTO-60 | 60mm | 600mm | 3.0mm ±0.05 | Low-security borders, livestock |
| CBT-65 | 65mm | 600mm | 3.0mm ±0.05 | General perimeter, farm security |
Benefits for Your Security Project:
• Cost-Effective Deterrence – Compare to electric fencing or guard patrols, concertina wire provides a one-time investment with 24/7 physical barrier protection.
• Low Maintenance – Galvanized or PVC coating reduces rust and corrosion, minimizing replacement and repair costs over the years.
• Versatile Mounting – Can be installed on chain-link fences, brick walls, concrete pillars, or standalone support frames. Accessories like clips, brackets, and tension springs are available.
• Customizable – We offer custom lengths, blade colors, wire diameters, and packaging (pallet or carton) to match your logistics and installation requirements.
Our manufacturing facility in Hengshui, Hebei, covers an area of 10,000 square meters and is equipped with 50+ automatic CNC machines. We produce over 500 tons of razor wire monthly, serving clients in more than 30 countries including the United States, Australia, Middle East, and Southeast Asia. Each batch is traceable with a quality control number, and we provide samples for approval before mass production.
Trust & Reliability:
Since 2005, Anping Xinye Metal Wire Mesh Products Co., Ltd has been dedicated to manufacturing security fencing solutions. Our experienced team ensures on-time delivery, consistent quality, and responsive after-sales support. We offer a 12-month warranty against manufacturing defects and free technical consultation for installation. For bulk orders, we provide competitive pricing and flexible payment terms (T/T, L/C, etc.).
Ready to strengthen your perimeter security? Contact us today for a quote, free sample, or technical datasheet. Our concertina razor barbed wire is the reliable choice for demanding environments.
Frequently Asked Questions
Q1: What is the difference between BTO and CBT models?
A: BTO models have tighter blade spacing (16-60mm) and are designed for higher security requirements. CBT-65 has a wider 65mm spacing, suitable for general perimeter fencing where a balance between security and cost is needed.
Q2: Can I get the wire in stainless steel instead of galvanized?
A: Yes, we offer stainless steel 304 or 316 grade for maximum corrosion resistance, ideal for coastal areas or chemical plants. Please specify your requirement when ordering.
Q3: What is the typical length per coil?
A: Standard coil length is 8 meters, 10 meters, or 15 meters. Custom lengths are available upon request.
Q4: Is the PVC coating environmentally friendly?
A: Our PVC material is lead-free and complies with RoHS standards. It is safe for use in residential areas and does not release harmful substances under normal conditions.
Q5: How do you pack the concertina wire for export?
A: We pack each coil in a compressed form with a steel strap, then place into cartons or pallets. For large orders, we use wooden crates to protect during sea freight. Each package is labeled with model, quantity, and batch number.
Q6: Can I install the wire on an existing fence?
A: Absolutely. Our concertina wire can be mounted on top of chain-link fences, brick walls, or concrete barriers using appropriate brackets. We can supply mounting accessories or recommend installation methods.
Q7: What is the minimum order quantity (MOQ)?
A: For standard models, our MOQ is 50 coils. For customized specifications, MOQ may be 100 coils. However, we also accept small trial orders for sample testing.
Q8: How long does delivery take?
A: For stock items, shipping takes 7-10 days after payment. For custom orders, lead time is 15-25 days depending on quantity. We can provide exact delivery schedule upon order confirmation.
