Anping Xinye Metal Wire Mesh Products Co., Ltd, located in the heart of Hengshui, Hebei – China's renowned wire mesh manufacturing hub – brings you a premium security solution: the Galvanized PVC Stainless Steel Concertina Razor Barbed Wire in models BTO-22, BTO-60, and CBT-65. This product is engineered to deliver maximum deterrence against intrusion while withstanding harsh outdoor environments. Whether you need a cost-effective galvanized finish, a corrosion-resistant PVC coating, or the superior strength of stainless steel, our concertina razor wire adapts to your specific security requirements. Designed for high-security perimeters such as prisons, military compounds, and industrial facilities, it offers a formidable barrier that is both durable and easy to install.
| Model | Blade Length (mm) | Blade Thickness (mm) | Core Wire Diameter (mm) | Coil Diameter (mm) | Tensile Strength (N/mm²) |
|---|---|---|---|---|---|
| BTO-22 | 22 | 0.5 – 0.6 | 2.5 | 450 – 500 | ≥ 600 |
| BTO-60 | 60 | 0.6 – 0.7 | 3.0 | 500 – 600 | ≥ 600 |
| CBT-65 | 65 | 0.6 – 0.7 | 3.5 | 550 – 650 | ≥ 600 |
Key Features and Benefits
- Triple Material Options: Choose from hot-dip galvanized steel, PVC-coated steel, or stainless steel. The galvanized layer offers excellent rust resistance for general outdoor use; PVC coating adds extra protection against UV and moisture while providing a discreet color; stainless steel delivers maximum corrosion resistance for coastal or chemical environments.
- Variety of Models: BTO-22 (standard security), BTO-60 (medium security), and CBT-65 (high security with longer blades). The blade length and thickness are optimized to match different threat levels, allowing you to select the most cost-effective solution.
- Concertina Design: The spiral coil shape creates a dense, multi-layered barrier that is difficult to cut or climb. Each coil can be stretched to cover a wide area, reducing the number of rolls needed per linear meter.
- Easy Installation: Comes in compressed rolls that can be quickly deployed using clamps, brackets, or clips. No welding or special tools required. Can be mounted on existing walls, fences, or standalone posts.
- Customizable Specifications: Coil diameter, blade length, core wire gauge, and packing method can be tailored to your project requirements. Contact us for custom dimensions or special finishes.
- High Tensile Strength: Core wire made from high-carbon steel with tensile strength ≥ 600 N/mm², ensuring the razor wire retains its shape under tension and impact.
- Long Service Life: Properly coated galvanized or PVC finish can last 8–10 years in normal outdoor conditions. Stainless steel variants offer even longer durability with minimal maintenance.
- Wide Application: Ideal for prisons, military bases, border walls, airports, power plants, industrial estates, farms, and residential security perimeters.
Technical Specifications
| Parameter | Details |
|---|---|
| Material | Galvanized steel (Q195), PVC coated, or Stainless steel (201/304) |
| Blade Shape | Sharp, triangular or square points |
| Surface Treatment | Hot-dip galvanized (≥ 50 µm), PVC coating (0.4–0.6 mm), or plain stainless steel |
| Coil Pitch | 100 mm – 150 mm (standard), customizable |
| Standard Length per Roll | 8 m – 10 m (compressed), can be stretched to 15 m – 20 m |
| Weight per Roll | Approximately 10 – 15 kg (depending on model and material) |
Why Choose Anping Xinye?
With over a decade of experience in wire mesh manufacturing, Anping Xinye Metal Wire Mesh Products Co., Ltd has established a reputation for reliable quality and competitive pricing. Our factory in Hengshui, Hebei is equipped with modern production lines, allowing us to produce concertina razor wire in large volumes while maintaining strict quality control. We serve clients worldwide, from government agencies to private contractors, and we offer flexible shipping options including FOB, CIF, and door-to-door delivery. Our team provides professional technical support, sample requests, and after-sales service. Whether you need a small order for a residential project or a large container for a national security infrastructure, we are ready to meet your needs. Contact us today for a quote or to discuss your specific requirements.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between BTO-22, BTO-60, and CBT-65?
A: BTO-22 has a 22mm blade length and is used for standard security; BTO-60 has 60mm blades for medium security; CBT-65 has 65mm blades and a thicker core wire for high-security applications. The larger the blade, the more deterrent effect. -
Q: Can I get a custom color for the PVC coating?
A: Yes, we offer PVC coating in colors such as green, red, yellow, white, and black. Custom colors are available upon request with a minimum order quantity. -
Q: How long does the galvanized or PVC coating last?
A: Under normal outdoor conditions, hot-dip galvanized coating lasts 8–10 years, and PVC coating can last 5–8 years depending on UV exposure. Stainless steel options have an indefinite lifespan with proper maintenance. -
Q: Is the razor wire easy to install?
A: Yes, the concertina coils are compressed and shipped in rolls. They can be stretched and fixed using simple clips, brackets, or tie wires. No special tools are required. We can provide installation instructions or videos upon request. -
Q: Do you offer samples before ordering?
A: Yes, we provide free samples of small blade pieces or a short coil section for evaluation. The buyer only needs to cover the shipping cost. -
Q: What is the packing method for export?
A: Each coil is compressed and tied with plastic straps, then wrapped in waterproof paper and packed in wooden pallets. For sea freight, we use fumigated wooden crates if required. -
Q: Can I order a mix of models in one container?
A: Absolutely. We can mix different models, materials, and colors in one container to optimize your inventory. Contact us with your quantity breakdown. -
Q: What is the minimum order quantity?
A: Our standard MOQ is 100 rolls per model, but we can accommodate smaller orders for trial purposes. Please inquire for details.
Contact Anping Xinye Metal Wire Mesh Products Co., Ltd
Based in Hengshui, Hebei, China – your trusted partner for high-quality razor barbed wire. We welcome inquiries, samples, and factory visits. Let us help you secure your perimeter with the most reliable concertina wire available.
