Anping Xinye Metal Wire Mesh Products Co., Ltd – your trusted manufacturer of high-quality stainless steel wire mesh. Our SUS 201, 304, and 316 embossed woven mesh is engineered to deliver exceptional strength, corrosion resistance, and reliable performance in both protective support and filtration applications. With a unique embossed pattern that enhances rigidity and flow distribution, this mesh is the ideal choice for demanding industrial environments where durability and precision matter.
Manufactured in our facility in Hengshui, Hebei, China, we combine decades of weaving expertise with modern production lines to ensure consistent mesh openings, uniform wire diameter, and a flawless embossed surface. Whether you need a heavy-duty support screen for mining equipment or a fine filter for pharmaceutical processing, our mesh can be customized to your exact specifications.
Key Features & Technical Specifications
- Material Options: Choose from SUS 201 (economical), SUS 304 (standard corrosion resistance), or SUS 316 (superior resistance to chemicals and saltwater).
- Embossed Design: The raised diamond or lenticular pattern increases the mesh's structural rigidity without adding weight, preventing deformation under heavy loads.
- Precision Weaving: Tight tolerance control ensures consistent mesh openings for accurate particle separation and uniform flow.
- Corrosion & Heat Resistance: Suitable for use in temperatures up to 800°C (for 304/316) and harsh chemical environments.
- Versatile Applications: Ideal for protective guards, machine shields, vibrating screens, water filtration, oil filtering, and architectural cladding.
- Customizable Dimensions: Available in rolls, sheets, or cut-to-size panels with custom wire diameter, opening, width, and length.
- Optional Surface Treatments: Bright annealing, PVC coating, or galvanized after weaving (upon request).
| Parameter | Available Range | Standard Tolerance |
|---|---|---|
| Wire Diameter (mm) | 0.3 – 3.0 | ±0.02 mm |
| Mesh Opening (mm) | 0.5 – 20 | ±0.05 mm |
| Mesh Width (m) | 1.0 – 2.0 | ±3 mm |
| Mesh Length (m per roll) | 10 – 30 | ±0.5% |
| Embossed Pattern Height (mm) | 0.5 – 2.5 | ±0.1 mm |
| Open Area (%) | 30% – 75% | Depends on weave |
Advantages for Your Application
- Enhanced Structural Support: The embossed pattern increases the mesh's load-bearing capacity, making it suitable for heavy-duty guarding and support structures in mining, quarrying, and construction.
- Improved Filtration Performance: The raised surface prevents particle blinding and allows for better cake release in filter presses and vibrating screens, reducing downtime.
- Corrosion Resistance: SUS 316 grade offers excellent resistance to chlorides and acidic environments, extending service life in marine, chemical, and wastewater applications.
- Cost-Effective Solutions: SUS 201 provides a budget-friendly option with good mechanical properties for less aggressive environments.
- Easy Installation: Flexible yet strong, the mesh can be cut, bent, or welded with standard tools, reducing fabrication time.
- Consistent Quality: Every roll undergoes strict dimensional inspection and visual check before shipment, ensuring you receive a defect-free product.
Why Choose Anping Xinye?
Located in the renowned wire mesh capital of China – Hengshui, Hebei – Anping Xinye Metal Wire Mesh Products Co., Ltd has been dedicated to the production of woven wire mesh for over 15 years. Our factory is equipped with advanced automatic looms, embossing machines, and annealing furnaces, enabling us to produce high-quality mesh with tight tolerances. We export to more than 30 countries across Europe, America, Southeast Asia, and the Middle East, serving industries such as oil & gas, food processing, pharmaceuticals, and construction.
We pride ourselves on our strict quality control system and responsive customer service. Each order is carefully managed from raw material selection to final packaging, ensuring that the mesh meets your specific requirements. We offer free samples for evaluation, and our technical team is always available to assist with mesh selection, weave pattern recommendations, and installation guidance.
Whether you need a small trial roll or a bulk container shipment, we can deliver on time and at competitive prices. Contact us today to discuss your protective support and filtering mesh needs – we are ready to provide you with a reliable solution.
Frequently Asked Questions
-
What is the difference between SUS 304 and SUS 316 for this mesh?
Both are austenitic stainless steels. SUS 316 contains molybdenum, which provides superior resistance to chlorides and acids, making it ideal for marine or chemical environments. SUS 304 is suitable for general industrial use with good corrosion resistance. -
Can the embossed mesh be used for liquid filtration?
Yes, the embossed pattern helps distribute flow evenly and reduces clogging, making it effective for pre-filtration, polishing, or cake support in filter presses. -
Is the mesh available in cut-to-size sheets?
Yes, we can cut the mesh to your specified dimensions. We also offer custom shapes, edging, and welding for panels. -
What is the embossed pattern – diamond or lenticular?
We offer both diamond and lenticular (ripple) patterns. The standard is diamond, but we can produce lenticular per your request. -
How do I choose the correct wire diameter and mesh opening?
It depends on the required strength and filtration size. For protective support, larger wire diameter (e.g., 1.5–3.0 mm) is recommended. For filtering, select an opening smaller than the particles you need to retain. Our technical team can advise based on your application. -
Can the mesh be welded or bent after delivery?
Yes, stainless steel mesh is easy to weld, cut, and bend using standard fabrication methods. We recommend using 304/316 filler rods for welding to maintain corrosion resistance. -
Do you provide samples? How long is the lead time?
Yes, free samples (A4 size) are available. Typical lead time for production orders is 15–25 working days, depending on quantity and customization. -
What packaging do you use for export?
Each roll is wrapped with plastic film, then packed in woven bags or wooden crates to prevent damage during transit. Custom packaging is also available.
