Help Center45 Manganese Steel Embossed Crimped Woven Screen Wire Mesh for Quarry Operations
Product Spotlights
Related Products
-
Customized Flat Wire Embossed Metal Mesh for Decorative and Architectural ProjectsNegotiableMOQ: 50 Cubic Centimeters -
Embossed Aluminum Expanded Metal Mesh 8x10mm Opening Powder Coated for Decorative UseNegotiableMOQ: 50 Cubic Centimeters
-
3D Embossed Carved Copper Screen Floral Landscape Room Divider for Chinese Villa DecorativeNegotiableMOQ: 50 Cubic Centimeters
-
3mm Thick Decorative Aluminum Facade Screen for Building Exterior CladdingNegotiableMOQ: 50 Cubic Centimeters
-
Architectural Laser Cut Aluminum Rectangular Pattern Wall Panel Customizable Indoor Outdoor Privacy ScreenNegotiableMOQ: 50 Cubic Centimeters
Anping Xinye Metal Wire Mesh Products Co., Ltd, based in Hengshui, Hebei, China, is proud to present our 45 Manganese Steel Embossed Crimped Woven Screen Wire Mesh – a premium solution designed specifically for rugged quarry operations. This high-strength screen mesh offers exceptional wear resistance and long service life, reducing downtime and operational costs. Our advanced embossing and crimping process ensures precise aperture sizing and consistent material flow, making it the ideal choice for vibrating screens in stone crushing plants.
The 45 manganese steel alloy provides superior hardness and toughness, capable of withstanding heavy impact and abrasive materials. The embossed surface enhances material separation efficiency by preventing pegging and blinding. Whether you are screening granite, limestone, basalt, or gravel, this mesh delivers reliable performance under the harshest conditions.
Key Features & Benefits
- High Wear Resistance: 45 manganese steel offers excellent abrasion resistance, extending mesh life 2–3 times compared to regular steel.
- Embossed Surface: Reduces material sticking and clogging, improving screening efficiency by up to 15%.
- Precision Crimped Weave: Ensures uniform mesh openings for accurate particle sizing.
- Heavy-Duty Construction: Suitable for high-tonnage and high-vibration quarry operations.
- Customizable Specifications: Mesh opening, wire diameter, panel size, and edge type can be tailored to your equipment.
- Easy Installation: Available with hooked, flat, or bolt edges for quick mounting on vibrating screens.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | 45 Manganese Steel (Hardness: 45–55 HRC) |
| Wire Diameter | 2.0 mm – 12.0 mm (customizable) |
| Mesh Opening | 1 mm – 100 mm (square or slotted) |
| Panel Size | Up to 2.5 m x 6 m (custom dimensions available) |
| Open Area | 30% – 65% (depending on opening) |
| Edge Type | Hooked, Flat, Bolt, or Rubber clamp (optional) |
| Surface Finish | Embossed (standard), plain or galvanized available |
Our 45 Manganese Steel Embossed Crimped Woven Screen Mesh is manufactured using advanced automated looms and strict quality control processes. Each panel is tested for dimensional accuracy and tensile strength. The result is a consistent, reliable product that meets the demanding requirements of quarry operators worldwide.
Why Choose Anping Xinye?
- Over 20 years of experience in wire mesh manufacturing.
- Located in the “Wire Mesh Capital” Hengshui, Hebei, with access to raw materials and skilled labor.
- Export to 30+ countries including Australia, South Africa, Chile, and Indonesia.
- Flexible MOQ – we accept small trial orders as well as large container shipments.
- On-time delivery and responsive customer service.
We understand that every quarry operation is unique. Our team works closely with clients to provide customized solutions – from mesh opening size to edge preparation. Whether you need a standard 1m x 2m panel or a custom 2.2m x 5.5m screen, we can produce it efficiently.
Frequently Asked Questions
-
What is the difference between embossed and plain woven screen mesh?
Embossed mesh has a raised pattern on the surface that reduces material sticking and improves screening efficiency. It is especially beneficial for wet or sticky materials. -
Can this mesh be used for both dry and wet screening?
Yes, the 45 manganese steel is corrosion-resistant for typical quarry environments, and the embossed surface helps prevent blinding in wet conditions. -
What edge types are available?
We offer hooked, flat, bolt, and rubber clamp edges. Hooked edges are most common for vibrating screens; we can also add tensioning hooks upon request. -
How long is the lead time for custom orders?
For standard sizes, lead time is 7–10 working days. Custom specifications may require 15–20 working days, depending on complexity. -
Do you provide samples?
Yes, we can provide small samples (e.g., 300mm x 300mm) for quality evaluation. Please contact us for sample availability and shipping cost. -
What is the typical lifespan of this mesh in granite quarrying?
With proper use, the mesh can last 3–6 months for primary screening and 6–12 months for secondary screening, depending on feed material and tonnage. -
Can I get a certificate of material composition?
Yes, we can provide a mill test certificate for the 45 manganese steel material upon request.
At Anping Xinye Metal Wire Mesh Products Co., Ltd, we are committed to delivering high-quality, durable screening solutions for the global quarry industry. Our 45 Manganese Steel Embossed Crimped Woven Screen Wire Mesh combines advanced metallurgy with precision manufacturing to maximize your productivity and profitability. Contact us today for a quotation or technical consultation – we are ready to support your operation with reliable products and expert service.
