Anping Xinye Metal Wire Mesh Products Co., Ltd proudly presents our Double Twisted Hexagonal Steel Wire Mesh for River Control with Rock Fill. As a leading manufacturer based in Hengshui, Hebei, China, we specialize in producing high-quality wire mesh solutions that combine durability, flexibility, and environmental friendliness. This mesh is specifically designed to work with rock fill for river control, slope protection, and erosion prevention. Its double-twisted hexagonal structure ensures superior strength and stability, even under high water flow conditions. Whether you are working on a large-scale river regulation project or a small landscape restoration, our product offers a cost-effective and long-lasting solution.
Key Features and Technical Specifications
- Double Twisted Hexagonal Design: The hexagonal openings are formed by twisting two wires together, creating a strong, flexible mesh that can conform to irregular surfaces and withstand heavy loads.
- Corrosion Resistance: Available in hot-dip galvanized, PVC coated, or Galfan coated options to resist rust and chemical attack in aquatic environments.
- High Tensile Strength: Made from high-quality low-carbon steel wire with tensile strength up to 350–550 N/mm², ensuring long service life.
- Rock Fill Compatibility: Designed to contain and retain rocks, stones, or gravel, forming a stable, permeable structure that dissipates water energy and reduces erosion.
- Customizable Dimensions: Mesh opening sizes, wire diameters, and panel sizes can be tailored to meet project requirements.
- Easy Installation: The mesh is supplied in pre-assembled panels or rolls, ready for on-site assembly and filling with local rock materials.
Technical Parameters (Typical)
| Parameter | Value |
|---|---|
| Wire Diameter | 2.0 mm – 4.0 mm (customizable) |
| Mesh Opening (A x B) | 60 x 80 mm, 80 x 100 mm, 100 x 120 mm |
| Panel Size (L x W x H) | 2 m x 1 m x 1 m, 3 m x 1 m x 1 m (customizable) |
| Tensile Strength | 350–550 N/mm² |
| Coating Thickness | Galvanized: ≥ 245 g/m²; PVC: 0.4–0.6 mm |
| Corrosion Resistance | Excellent in fresh water, brackish water, and soil |
Benefits for Your Project
- Effective River Control: The mesh-rock fill system reduces water velocity, prevents scouring, and stabilizes riverbanks.
- Environmentally Friendly: The flexible structure allows vegetation growth, promoting ecological restoration and natural integration.
- Cost-Efficient: Uses locally available rock materials, reducing transportation and material costs compared to concrete structures.
- Low Maintenance: The durable coatings ensure long-term performance with minimal upkeep.
- Versatile Applications: Suitable for river training, weirs, check dams, culvert outlets, and roadside slopes.
Why Choose Anping Xinye Metal Wire Mesh Products Co., Ltd?
With years of experience in the wire mesh industry, we have supplied thousands of tons of double twisted hexagonal mesh to clients worldwide. Our factory in Hengshui, Hebei, is equipped with advanced weaving and coating lines, ensuring consistent quality and timely delivery. We adhere to strict quality control procedures, from raw material inspection to final packaging. Our technical team is available to provide design support and customized solutions for your specific river control project. We are committed to providing reliable products that meet international standards, ensuring your project’s success.
Frequently Asked Questions (FAQ)
Q1: What is the difference between double twisted hexagonal mesh and standard welded mesh?
A1: Double twisted hexagonal mesh is made by twisting two wires together at each intersection, creating a flexible, interconnected structure that can deform without breaking. This makes it ideal for rock fill applications where the mesh must conform to ground movement, whereas welded mesh is rigid and may crack under stress.
Q2: How do I choose the right mesh opening size for my river control project?
A2: The mesh opening size depends on the size of the rock fill you plan to use. Typically, the opening should be smaller than the smallest rock to prevent loss. For example, 60x80 mm is suitable for small rocks (50–100 mm), while 100x120 mm works with larger rocks (80–150 mm). Our technical team can help you select the optimal size.
Q3: Can the mesh be used in saltwater environments?
A3: Yes, we offer PVC-coated and Galfan-coated options that provide enhanced corrosion resistance in saltwater or brackish water. However, for long-term immersion in seawater, we recommend a thicker PVC coating (0.5 mm or more) and stainless steel wire upon request.
Q4: What kind of rock fill material is recommended?
A4: Durable, angular rocks such as granite, basalt, or limestone with a specific gravity of 2.4–2.7 t/m³ are ideal. The rock size should be 1.5 to 2 times the mesh opening dimension to ensure interlocking and stability.
Q5: Is the mesh supplied in rolls or panels?
A5: We supply both rolls and pre-assembled panels depending on your installation preference. Rolls are convenient for large areas, while panels are easier for precise placement. Standard panel dimensions are 2x1x1 m, but custom sizes are available.
Q6: How long does the galvanized coating last?
A6: Hot-dip galvanized coating can last 20–30 years in normal soil conditions and 15–20 years in freshwater environments. The actual lifespan depends on the pH level, water flow, and presence of corrosive elements. For enhanced durability, PVC coating is recommended.
Q7: Do you provide installation instructions or technical support?
A7: Yes, we provide detailed installation guidelines and can offer on-site technical support for large orders. Our team can also assist with design calculations for gabion structures.
Q8: What is the minimum order quantity (MOQ)?
A8: Our MOQ for double twisted hexagonal mesh is typically 100 square meters, but we can accommodate smaller quantities for sample or trial orders. Please contact us with your specific requirements.
Conclusion
Anping Xinye Metal Wire Mesh Products Co., Ltd. has been dedicated to manufacturing high-quality wire mesh since 1998, with a production capacity of 500 tons per month. Our double twisted hexagonal steel wire mesh has been successfully used in river control projects across Asia, Africa, and South America, earning trust from civil engineers and contractors. We welcome you to request a quote or sample to experience the quality firsthand. Contact us today to discuss your river control needs and let us provide a tailored solution that ensures long-term stability and cost savings.
