Strong and Resilient Double Twisted Wire Mesh for High Stress and Pressure Applications
Product Spotlights
Engineered double twisted wire mesh with high tensile strength (350-550 N/mm²) and flexible hexagonal structure, ideal for retaining walls, slope protection, and heavy civil works. Hot-dip galvanized or PVC coated for long corrosion resistance. Customizable wire diameter, opening, and panel size. Manufactured by Anping Xinye with 15+ years experience, 500-ton monthly capacity, and global export to 30+ countries.
Negotiable
MOQ: 50 Cubic Centimeters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Galvanized Steel Wire / PVC Coated Wire
Wire Diameter:
2.0mm – 4.0mm (customizable)
Mesh Opening:
50mm × 70mm, 60mm × 80mm, 80mm × 100mm (customizable)
Payment & Shipping
Payment Methods:
Port of Shipment:
china
Delivery Detail:
7 days
Related Products
-
Twisted Welded Hexagonal Wire Mesh for Fencing ApplicationsNegotiableMOQ: 50 Cubic Centimeters -
Double Twisted Steel Wire Rope Mesh for Mining Slope StabilizationNegotiableMOQ: 50 Cubic Centimeters
-
80x100mm Galvanized Double Twisted Hexagonal Gabion Mesh 2x1x1mNegotiableMOQ: 50 Cubic Centimeters
-
Galvanized Double Twisted Gabion Mesh for Stream Bank ProtectionNegotiableMOQ: 50 Cubic Centimeters
-
80X100mm Double Twisted Hexagonal Wire Mesh Drape System for Rockfall Protection Slope StabilizationNegotiableMOQ: 50 Cubic Centimeters
Material
Other, Galvanized Steel Wire / PVC Coated Wire
Wire Diameter
2.0mm – 4.0mm (customizable)
Mesh Opening
50mm × 70mm, 60mm × 80mm, 80mm × 100mm (customizable)
Panel Size
2m × 3m, 2m × 4m, 3m × 4m (customizable)
Tensile Strength
350 – 550 N/mm² (depending on wire diameter)
Surface Treatment
Hot-dip galvanized / PVC coated / Electro-galvanized
Shape
Hexagonal opening with double twist
Edge Finish
Selvedge edge / twisted edge / plain edge
Anping Xinye Metal Wire Mesh Products Co., Ltd proudly presents our Strong and Resilient Double Twisted Wire Mesh, engineered specifically for high stress and pressure applications. As a leading manufacturer based in Hengshui, Hebei, China, we combine decades of weaving expertise with advanced production technology to deliver wire mesh that withstands extreme loads, harsh environmental conditions, and long-term wear. Our double twisted wire mesh is the preferred choice for civil engineering, mining, and heavy construction projects where structural integrity is non-negotiable.
This mesh features a unique hexagonal pattern formed by twisting two wires together, creating a flexible yet incredibly strong structure. The double twist design allows the mesh to distribute stress evenly, preventing localized failure even under heavy pressure. Whether used for gabion baskets, retaining walls, slope stabilization, or rockfall protection, our product offers reliable performance that project managers trust.
Key Features & Technical Advantages
- High Tensile Strength: Manufactured from high-quality low-carbon steel wire with tensile strength ranging from 350 to 550 N/mm², ensuring the mesh can handle significant static and dynamic loads.
- Superior Corrosion Resistance: Available with hot-dip galvanized, PVC coated, or electro-galvanized surface treatment. Our hot-dip galvanized coating meets ASTM A641 standards, providing long-lasting protection in aggressive environments.
- Flexibility Without Compromise: The double twist structure allows the mesh to conform to uneven terrain and settle without breaking, making it ideal for ground movement and seismic zones.
- Uniform Openings: Precision manufacturing ensures consistent mesh openings, which is critical for effective soil retention and aggregate containment.
- Easy Installation: Lightweight panels can be cut and shaped on-site; no special tools required. The mesh can be connected using helical binders or lacing wire for seamless assembly.
- Customizable Dimensions: We offer a wide range of wire diameters (2.0mm – 4.0mm), mesh openings (50×70mm, 60×80mm, 80×100mm, etc.), and panel sizes (2×3m, 2×4m, 3×4m, or custom) to meet specific project requirements.
Technical Specifications
| Parameter | Standard Range | Notes |
|---|---|---|
| Wire Diameter (mm) | 2.0 / 2.2 / 2.7 / 3.0 / 3.4 / 4.0 | Custom diameters available upon request |
| Mesh Opening (mm) | 50×70, 60×80, 80×100, 100×120 | Other sizes can be produced to order |
| Tensile Strength (N/mm²) | 350 – 550 | Depends on wire diameter and steel grade |
| Zinc Coating (g/m²) | ≥ 245 (hot-dip) | Meets ASTM A641 / BS EN 10244-2 |
| Panel Width (m) | 2.0 / 2.5 / 3.0 | Custom widths up to 4.0m available |
| Panel Length (m) | 3.0 / 4.0 / 5.0 / 6.0 | Custom lengths accepted |
Why Choose Our Double Twisted Wire Mesh?
- Proven Performance in High-Stress Environments: Our mesh is used in heavy-duty retaining walls, bridge abutments, and coastal protection projects where continuous pressure and dynamic loads are present.
- Cost-Effective Solution: Compared to concrete or rigid structures, our wire mesh offers lower material and installation costs while providing equivalent or superior structural reinforcement.
- Environmentally Friendly: The open structure allows vegetation growth, promoting slope greening and ecosystem integration. Ideal for “green” civil engineering solutions.
- Global Compliance: Our manufacturing process adheres to international quality standards. We can produce mesh that meets ASTM, BS, or EN specifications as per customer requirements.
- Rigorous Quality Control: Every batch of wire is tested for tensile strength, elongation, and coating thickness. Final products undergo visual inspection and dimensional checks before packing.
At Anping Xinye, we have been serving the global market for over 15 years, supplying wire mesh to more than 30 countries. Our factory covers 10,000 square meters and is equipped with automated double-twist weaving machines, galvanizing lines, and PVC coating lines. We maintain a monthly production capacity of 500 tons, ensuring timely delivery for both small and large-scale orders. Our team of engineers provides technical support to help you select the right mesh specification for your project.
We are committed to building long-term partnerships based on quality, reliability, and mutual success. Whether you need a standard gabion mesh or a custom-engineered solution for high-pressure applications, we are ready to assist. Contact us today for a quote or to discuss your specific requirements. Let us help you build stronger, safer, and more durable structures with our double twisted wire mesh.
Frequently Asked Questions
-
Q: What makes double twisted wire mesh stronger than regular welded wire mesh?
A: The double twist design interlocks wires in a hexagonal pattern, allowing the mesh to flex under load without breaking. This distributes stress more evenly and prevents rupture at welded joints, providing superior resilience in high-pressure applications. -
Q: Can your mesh be used for retaining walls over 5 meters high?
A: Yes, our double twisted wire mesh is suitable for tall retaining walls when combined with proper internal reinforcement (e.g., using thicker wire, smaller openings, or layered construction). We can provide engineering recommendations based on your wall height and soil conditions. -
Q: What surface treatment is best for coastal or acidic soil environments?
A: For highly corrosive environments, we recommend hot-dip galvanized zinc coating with a minimum of 245 g/m², or PVC coating for additional chemical resistance. Custom zinc-aluminum alloy coatings are also available upon request. -
Q: How long does the mesh last before needing replacement?
A: The service life depends on the coating, environment, and load conditions. In typical applications, hot-dip galvanized mesh lasts 50–70 years, while PVC-coated mesh can exceed 80 years under normal conditions. -
Q: Can you supply mesh in rolls instead of panels?
A: Yes, we offer both rolled and panel forms. Rolls are convenient for long, continuous installations such as slope protection, while panels are easier for gabion basket assembly. Please specify your preference. -
Q: Do you provide installation instructions or technical drawings?
A: Absolutely. We provide detailed installation guidelines, connection details, and product data sheets. Our technical team can also assist with custom design calculations for your project. -
Q: What is the minimum order quantity (MOQ) for custom sizes?
A: For standard sizes, MOQ is 100 square meters. For custom wire diameters, openings, or coatings, MOQ is 500 square meters. Small trial orders are welcome for evaluation purposes. -
Q: How do you ensure the mesh is flat and free from defects?
A: Our automated weaving machines produce uniform mesh with consistent tension. After weaving, each panel is manually inspected for loose twists, wire breaks, and coating defects. Only products that pass our quality check are packaged for shipment.
