Help CenterSintered Wire Mesh With Quality Guarantee, 304 SS, 10 Micron, 0.8mm Thickness, Free Technical Support
Product Spotlights
Related Products
-
Sintered Wire Mesh Roll 1m x 30m, 304 Stainless Steel, 20 Micron, for Gas and Oil FiltrationNegotiableMOQ: 1 Piece -
304 Stainless Steel Sintered Wire Mesh, 5 Micron Pore Size, 0.5mm Thickness for Industrial FiltrationNegotiableMOQ: 1 Piece
-
0.2mm Wire Diameter Sintered Wire Mesh 200 Mesh 304L SS for Gas Solid SeparationNegotiableMOQ: 1 Piece
-
Sintered Wire Mesh 304 Stainless Steel 0.5mm Thickness 1.2m Width Standard CompliantNegotiableMOQ: 1 Piece
-
Precision Sintered Wire Mesh 100x100 Mesh 0.1mm Wire 304L With Mill Test ReportNegotiableMOQ: 1 Piece
Welcome to Anping County Boli Hardware Wiremesh Products Factory, a trusted manufacturer with over 20 years of experience in the wire mesh industry. Our Sintered Wire Mesh with Quality Guarantee, 304 SS, 10 Micron, 0.8mm Thickness is designed for demanding filtration applications where precision and durability are paramount. This product combines the strength of 304 stainless steel with advanced sintering technology, delivering consistent pore size and high mechanical strength. Backed by our free technical support, you can rely on our expertise to optimize your filtration process.
Our sintered wire mesh is manufactured using a multi-layer sintering process that bonds stainless steel wires at high temperatures, creating a rigid, porous structure with excellent filtration characteristics. The 10 micron rating ensures effective removal of fine particles, while the 0.8mm thickness provides robust structural integrity for high-pressure and high-temperature environments. Below are the key features and technical specifications:
- Material: 304 Stainless Steel – excellent corrosion resistance, suitable for acidic and alkaline environments.
- Pore Size: 10 Micron (nominal) – consistent and uniform distribution for precise filtration.
- Thickness: 0.8mm – balances strength and flow rate, ideal for both liquid and gas filtration.
- Sintered Structure: Multi-layer diffusion bonding eliminates loose fibers, reducing media migration.
- High Temperature Resistance: Can withstand temperatures up to 450°C (842°F) in oxidizing atmospheres.
- High Mechanical Strength: Withstands differential pressures up to 20 bar (depending on support structure).
- Easy Cleaning: Backwashable and reusable, lowering long-term operational costs.
- Custom Sizes: Available in rolls, sheets, or cut-to-size pieces per your requirements.
- Free Technical Support: Our engineers provide application guidance and troubleshooting.
| Parameter | Value |
| Material Grade | 304 Stainless Steel (also available in 316L, 310S upon request) |
| Nominal Pore Size | 10 Micron (range: 5–100 micron) |
| Thickness | 0.8mm (0.031 inch) |
| Maximum Operating Temperature | 450°C (842°F) in air |
| Maximum Differential Pressure | Up to 20 bar (with proper support) |
| Filtration Efficiency | >99% for particles ≥10 micron |
| Standard Sheet Size | 1000mm × 1000mm (custom sizes available) |
| Surface Finish | Sintered, smooth, no loose fibers |
This sintered wire mesh is widely used in industries such as petrochemical, pharmaceutical, food and beverage, water treatment, gas filtration, and electronics. Its robust construction ensures long service life even under cyclic thermal and mechanical stress. The 10 micron rating makes it particularly suitable for fine filtration of fluids and gases where product purity is critical. For example, in the chemical industry, it can be used as a catalyst support or filter element to prevent catalyst fines from contaminating downstream processes. In the food industry, it meets hygiene standards for filtering edible oils, juices, and dairy products.
Our factory, established in 1998, has accumulated extensive experience in sintering technology. We use advanced vacuum sintering furnaces to ensure uniform bonding and consistent pore distribution. Each batch is tested for pore size, thickness, and burst strength before shipment. Our quality guarantee means that if any defect is found within the first year of use, we will replace the product at no extra cost. Additionally, our free technical support team is available to assist you with selection, installation, and maintenance.
Below are the benefits you can expect from choosing our sintered wire mesh:
- Consistent Filtration Performance: Uniform pore size ensures repeatable results.
- Reduced Downtime: Reusable and easy to clean, extending replacement intervals.
- High Flow Capacity: Optimized porosity minimizes pressure drop while maintaining efficiency.
- Versatile Application: Suitable for both liquid and gaseous media.
- Cost-Effective: Long service life lowers total cost of ownership.
- Reliable Supply: We have a production capacity of 10,000 square meters per month, ensuring timely delivery.
Our company has an annual export value of US$5 million to US$10 million and serves markets across North America, South America, Europe, Asia, Africa, Oceania, and the Middle East. We have shipped from ports including Tianjin, Qingdao, Shanghai, and Foshan, demonstrating our global logistics capability. With over 20 years of manufacturing experience, we have built a reputation for quality and reliability. Our products are used by leading filtration system manufacturers and end-users worldwide.
We invite you to experience the difference of working with a dedicated manufacturer. Contact us today for a quote or to discuss your specific filtration requirements. Our free technical support team is ready to help you achieve optimal performance from your sintered wire mesh.
Frequently Asked Questions
-
Q: What is the difference between sintered wire mesh and woven wire mesh?
A: Sintered wire mesh is made by bonding multiple layers of wire mesh under heat and pressure, creating a rigid, porous structure. Woven wire mesh is a single layer that may have loose fibers. Sintered mesh offers higher strength, better pore uniformity, and is less prone to media migration. -
Q: Can this 10 micron mesh handle high-viscosity fluids?
A: Yes, but the pressure drop will increase. We recommend using a support screen or housing to maintain differential pressure within limits. Our technical support can help you design the system. -
Q: Is the 304 stainless steel suitable for food contact?
A: 304 stainless steel is generally considered safe for food contact. However, specific regulations may vary by country. We can provide material certificates upon request. -
Q: How do I clean the sintered mesh?
A: Backwashing with clean fluid or using ultrasonic cleaning is effective. Avoid using harsh chemicals that may damage the material. Detailed cleaning instructions are included with your order. -
Q: What is the typical lead time?
A: For standard sizes, lead time is 10–15 working days. Custom sizes may require 20–25 working days. We can expedite orders for urgent projects. -
Q: Do you offer samples for testing?
A: Yes, we can provide free samples of dimensions 100mm × 100mm. You only need to pay for shipping. Contact us for sample requests. -
Q: Can I get a custom thickness or pore size?
A: Absolutely. We manufacture sintered mesh with pore sizes from 5 to 100 micron and thicknesses from 0.5mm to 2mm. Customization is available upon request. -
Q: What warranty do you provide?
A: We offer a one-year quality guarantee against manufacturing defects. If any issue arises, we will replace or refund the product.
Choose Anping County Boli Hardware Wiremesh Products Factory for your sintered wire mesh needs. Our combination of 20+ years of experience, global logistics, and free technical support ensures you get the best value for your investment. Request a quote today!
