Welcome to Anping County Boli Hardware Wiremesh Products Factory, a trusted manufacturer since 1998 with annual export value of US$5-10 million. Our 0.2mm Wire Diameter Sintered Wire Mesh 200 Mesh 304L SS is engineered for efficient gas-solid separation, offering superior strength and uniform pore distribution. This product is the reliable choice for demanding industrial filtration applications.
Key Features & Technical Specifications:
- Precision Filtration: 200 mesh (74 micron) with 0.2mm wire diameter ensures high separation efficiency for fine particles.
- Material Excellence: 304L stainless steel provides excellent corrosion resistance, low carbon content prevents sensitization during welding.
- Sintered Structure: Multi-layer diffusion bonding creates a rigid, high-strength mesh with consistent pore size and anti-clogging properties.
- Gas-Solid Separation: Ideal for fluidized bed systems, pneumatic conveying, catalyst recovery, and dust collection.
- Thermal Stability: Withstands temperatures up to 600°C (optional higher grades available).
- Customizable: Available in various shapes (sheets, discs, cylinders) with thickness from 0.5mm to 10mm.
| Parameter | Value |
| Wire Diameter | 0.2 mm |
| Mesh Count | 200 x 200 mesh |
| Aperture Size | ~74 micron |
| Open Area | ~30% |
| Material Grade | 304L SS |
| Tensile Strength | ≥ 500 MPa |
Advantages for Your Application: The sintered wire mesh eliminates the need for support layers, reduces maintenance frequency, and improves filtration accuracy. Its uniform pore structure minimizes pressure drop while maximizing throughput. Compared to woven mesh alone, the sintered version offers higher mechanical strength and resistance to vibration and thermal shock.
Trusted by Global Markets: Our products are exported to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. With decades of experience, we ensure strict quality control from raw material to finished product. Each batch is tested for mesh count, wire diameter, and filtration efficiency. We offer samples for evaluation and provide technical support for custom designs.
FAQ – Frequently Asked Questions
-
Q: What is the difference between sintered wire mesh and regular woven mesh?
A: Sintered mesh is diffusion-bonded under high temperature and pressure, creating a rigid, monolithic structure with higher strength, better pore uniformity, and resistance to high flow rates and backwashing. -
Q: Can this mesh be used for liquid filtration?
A: Yes, it is suitable for both gas and liquid filtration, but the 200 mesh size is specifically optimized for gas-solid separation. For liquid applications, we recommend alternative mesh sizes. -
Q: What is the maximum operating temperature?
A: Standard 304L sintered mesh can handle up to 600°C in oxidizing atmospheres. For higher temperatures, we can provide 310S or Inconel options. -
Q: Do you cut the mesh to custom sizes?
A: Yes, we offer custom cutting, punching, and welding to meet your specific dimensions. Minimum order quantities apply. -
Q: How do I clean the sintered mesh?
A: It can be cleaned by backwashing, ultrasonic cleaning, or chemical washing. The robust structure withstands repeated cleaning cycles. -
Q: Is the product certified?
A: Our manufacturing process follows ISO 9001 quality management system (optional certification available upon request). We can provide material test certificates if needed. -
Q: What is the lead time for bulk orders?
A: Typical lead time is 15–25 working days depending on quantity and complexity. We operate from our factory in Hengshui, Hebei with efficient logistics through Tianjin, Qingdao, Shanghai ports. -
Q: Can I get a free sample?
A: Yes, we provide sample pieces for testing. Please contact our sales team to arrange shipment (freight collect).
Why Choose Boli Hardware? With over 26 years of manufacturing experience, we have delivered millions of square meters of wire mesh products globally. Our advanced sintering furnaces and precision testing equipment guarantee consistent quality. We offer competitive pricing, professional customer service, and flexible packaging options. Contact us today to discuss your gas-solid separation needs – we are ready to provide a tailored solution.
