Anping County Boli Hardware Wiremesh Products Factory, established in 1998, is a professional manufacturer specializing in sintered wire mesh products. With an annual export value of US$5–10 million, we serve global markets including North America, Europe, Asia, and Africa. Our sintered wire mesh for gas filtration in the petrochemical industry is engineered to deliver exceptional performance, reliability, and longevity. The 5 micron filtration rating combined with 316L stainless steel construction ensures superior corrosion resistance and high-temperature stability, making it the ideal choice for demanding gas filtration applications.
This product is produced by sintering multiple layers of woven wire mesh under high temperature and pressure, creating a monolithic porous structure with precise pore size distribution. The 316L grade offers excellent resistance to acidic and alkaline environments commonly encountered in petrochemical processing. Our sintered mesh is designed to remove fine particles down to 5 microns while maintaining high flow rates and low pressure drop, ensuring efficient and cost-effective operation.
Key Features & Technical Specifications
- High Filtration Accuracy: Absolute 5 micron rating ensures removal of fine contaminants such as catalyst fines, dust, and scale from gas streams.
- Excellent Corrosion Resistance: 316L stainless steel provides outstanding resistance to chlorides, sulfides, and other corrosive media.
- High Temperature Stability: Can withstand continuous operating temperatures up to 600°C in air, suitable for hot gas filtration.
- High Mechanical Strength: Sintered multi-layer structure offers high burst strength and resistance to pressure fluctuations.
- Low Pressure Drop: Optimized pore structure minimizes flow resistance, reducing energy consumption.
- Easy Cleaning & Regeneration: Can be backwashed, ultrasonically cleaned, or chemically regenerated for extended service life.
- Customizable Dimensions: Available in sheets, rolls, discs, and custom shapes to fit specific filter housings.
| Parameter | Value |
|---|---|
| Material | 316L Stainless Steel |
| Filtration Rating | 5 Micron (absolute) |
| Thickness | 1.0 – 3.0 mm (customizable) |
| Maximum Operating Temperature | 600°C (in air) |
| Maximum Pressure | Up to 500 bar (depending on design) |
| Porosity | 30% – 40% |
| Available Shapes | Sheet, roll, disc, custom |
Benefits for Your Business
By choosing our sintered wire mesh for gas filtration, petrochemical plants can achieve consistent product quality by removing fine particles that could damage downstream equipment or contaminate final products. The robust construction means reduced maintenance frequency and longer intervals between replacements, lowering overall operational costs. The ability to clean and reuse the mesh multiple times also contributes to sustainability and waste reduction.
Our 5 micron rating is particularly effective in applications such as natural gas processing, hydrogen purification, syngas filtration, and catalyst recovery. The 316L material ensures compatibility with aggressive gases like hydrogen sulfide and chlorine, providing peace of mind in harsh environments.
Trust & Reliability
With over 25 years of experience in wire mesh manufacturing, Anping County Boli Hardware Wiremesh Products Factory has built a reputation for quality and reliability. Our annual export volume of US$5–10 million to markets across North America, Europe, Asia, and Africa demonstrates the trust our customers place in our products. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery worldwide.
We offer customized solutions to meet your specific filtration requirements – whether you need special dimensions, different mesh layers, or integration with existing filter housings. Our technical team is ready to assist with product selection, design, and after-sales support. Contact us today to discuss your gas filtration needs and experience the difference of precision-engineered sintered wire mesh.
Frequently Asked Questions (FAQ)
-
Q: Can this sintered mesh be cut to custom sizes?
A: Yes, we offer custom cutting and shaping to meet your exact dimensions. Please provide your requirements for a quote. -
Q: What is the maximum operating temperature for 316L sintered mesh?
A: In air, it can continuously operate up to 600°C. For reducing or inert atmospheres, the temperature limit may be higher. Consult our technical team for specific conditions. -
Q: How do I clean the sintered mesh after use?
A: Common methods include backwashing with clean gas or liquid, ultrasonic cleaning, or chemical cleaning using appropriate solvents. The mesh is fully regenerable and can be reused many times. -
Q: Is the 5 micron rating absolute or nominal?
A: Our 5 micron rating is absolute, meaning it effectively retains particles larger than 5 microns with high efficiency (>99%). -
Q: Can you provide samples for testing?
A: Yes, we can provide small samples (e.g., 100x100mm sheets) for evaluation. Please contact our sales team to arrange sample shipment. -
Q: What is the typical lead time for custom orders?
A: Lead time depends on quantity and complexity. Standard sizes are usually shipped within 7–15 days. Custom orders may take 15–30 days. -
Q: Do you offer any type of certification?
A: We can provide a material test certificate (MTC) for the 316L stainless steel upon request. Other certifications are available as per customer requirements. -
Q: Is this product suitable for high-pressure gas filtration?
A: Yes, it can be designed to withstand pressures up to 500 bar. The actual pressure rating depends on the thickness and support structure. Please provide your operating pressure for a customized solution.
