As a trusted manufacturer based in Liaocheng, Shandong, China, Hemaokang Steel (Shandong) Co., Ltd. is proud to offer the ASTM A53 Grade A Sch40 Galvanized Steel Pipe 1.5 Inch Nominal 2.0mm Wall Thickness ERW. This product combines the strength of ERW manufacturing with the corrosion resistance of hot-dip galvanizing, making it a reliable choice for various industrial applications. With our ISO9001 certification and annual export value exceeding US$50 million, we ensure consistent quality and timely delivery to global markets.
Our galvanized steel pipe is specifically designed to meet the rigorous demands of fluid transportation, structural support, and underground piping systems. The 1.5-inch nominal size and Schedule 40 wall thickness (2.0mm) provide a balance of strength and flexibility, while the ERW process ensures uniform wall thickness and smooth finish. Below we detail the key features, technical specifications, and benefits of this product.
Key Features & Technical Specifications
- Standard Compliance: Manufactured in accordance with ASTM A53 Grade A, ensuring consistent mechanical properties and dimensional accuracy.
- Galvanized Coating: Hot-dip galvanized inside and out, providing excellent protection against rust and corrosion, extending service life in harsh environments.
- ERW Manufacturing: Electric Resistance Welding process creates a strong, uniform weld seam without filler metal, resulting in high strength and pressure containment.
- Nominal Size & Wall Thickness: 1.5 inch nominal (outside diameter 1.9 inch / 48.3 mm) with 2.0 mm wall thickness (Schedule 40), suitable for medium-pressure applications.
- Versatile Application: Ideal for water supply, gas lines, oil pipelines, structural scaffolding, fence posts, and electrical conduit.
- Customizable Lengths: Available in standard random lengths (20 ft / 6 m) or custom lengths upon request.
- End Finish: Plain ends, beveled ends, or threaded ends as per customer requirement.
| Parameter | Value |
|---|---|
| Standard | ASTM A53 Grade A |
| Schedule | Sch40 |
| Nominal Size | 1.5 inch |
| Outside Diameter | 1.90 inch (48.3 mm) |
| Wall Thickness | 2.0 mm (0.079 inch) |
| Weight per Meter | Approx. 2.28 kg/m |
| Manufacturing Process | ERW (Electric Resistance Welding) |
| Surface Finish | Hot-dip Galvanized (Zinc coating) |
| Coating Weight | ≥ 300 g/m² (ASTM A53 requirement) |
| Tensile Strength (min) | 330 MPa (48,000 psi) |
| Yield Strength (min) | 205 MPa (30,000 psi) |
Advantages & Customer Benefits
- Corrosion Resistance: The hot-dip galvanized coating protects the steel from moisture, chemicals, and environmental elements, reducing maintenance costs and extending pipe life.
- High Strength & Durability: ASTM A53 Grade A material offers reliable tensile and yield strength, suitable for medium-pressure fluid and gas transport.
- Consistent Quality: ERW process ensures a uniform wall thickness and a smooth interior surface, minimizing friction loss and improving flow efficiency.
- Cost-Effective: Compared to seamless pipes, ERW galvanized pipes offer a more economical solution without compromising performance for most applications.
- Easy Installation: Standard dimensions and end finishes allow for quick joining using threaded fittings, welding, or mechanical couplings.
- Versatile Use: Suitable for both above-ground and underground installations, including water supply, gas distribution, fire sprinkler systems, and structural framework.
Our pipe is manufactured under strict quality control procedures in our ISO9001-certified facility. We perform hydrostatic testing, visual inspection, and dimensional checks to ensure every pipe meets ASTM A53 requirements. The galvanized coating is uniform and free of bare spots, ensuring long-term protection.
Trust & Reliability
Hemaokang Steel (Shandong) Co., Ltd. has been serving global customers since 2025, with an annual export value of US$50 million to US$100 million. Our team of 51–100 employees is dedicated to providing high-quality steel products and exceptional customer service. We have established a strong presence in major markets including North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and other regions. Our ISO9001 certification reflects our commitment to quality management and continuous improvement.
We understand that each project has unique requirements. That's why we offer flexible ordering options, including custom lengths, threading, and packaging. Our professional sales team is ready to provide technical support, samples, and competitive pricing. With our large production capacity and efficient logistics, we can handle both small and large orders with short lead times.
Contact us today to discuss your project needs. Choose Hemaokang Steel for reliable, high-quality ASTM A53 Grade A Sch40 Galvanized Steel Pipe that delivers performance and value.
Frequently Asked Questions (FAQ)
-
What is the difference between ASTM A53 Grade A and Grade B?
Grade A has lower tensile and yield strength (min 330 MPa tensile, 205 MPa yield) compared to Grade B (min 415 MPa tensile, 240 MPa yield). Grade A is suitable for lower-pressure applications where ductility is preferred, while Grade B is for higher strength requirements. -
Can this pipe be used for underground water lines?
Yes, the hot-dip galvanized coating provides excellent corrosion resistance for underground installations. However, for aggressive soil conditions, additional wrapping or cathodic protection may be recommended. -
What lengths are available?
Standard lengths are 20 ft (6.0 m) or random lengths between 16–22 ft. Custom lengths are available upon request with a minimum order quantity. -
Is the pipe threaded or plain end?
We offer plain ends, beveled ends, or threaded ends with couplings. Please specify your requirement when ordering. Threaded ends are available for NPT standards. -
How is the galvanized coating applied?
Our pipe is hot-dip galvanized after manufacturing. The pipe is cleaned, fluxed, and dipped in molten zinc, resulting in a metallurgical bond that provides long-lasting protection. -
Do you provide test certificates?
Yes, we supply mill test certificates (MTC) that comply with EN 10204 Type 3.1, including chemical composition, mechanical properties, and hydrostatic test results. -
What is the minimum order quantity (MOQ)?
For standard sizes, MOQ is typically 1 ton (approximately 20 pieces). For custom lengths or special finishes, MOQ may be higher. Contact our sales team for details. -
Can I get a sample before placing a bulk order?
Yes, sample requests are welcome. We can provide a 1-meter sample with freight collect. Please contact us to arrange.
Hemaokang Steel (Shandong) Co., Ltd. – Your reliable partner for galvanized steel pipes. Contact us for a quote or technical consultation.
