At Changzhou Hongxinyutai Precision Mold Co., Ltd., we specialize in delivering high-performance injection molds tailored for precision dosing applications. Our High Cavity Injection Mold for Dosing Scoop with a 1x32 layout is engineered to maximize production efficiency while maintaining exceptional dimensional accuracy. Built with premium H13 and S136 steel and manufactured to LKM standard, this mold offers durability, longevity, and consistent output. Whether you need a robust solution for high-volume dosing scoop manufacturing or a reliable tool for your injection molding line, this mold is designed to meet your demanding requirements.
This mold features a 220V heating system that ensures uniform temperature distribution, reducing cycle times and improving part quality. The 1x32 cavity layout allows for simultaneous production of 32 dosing scoops per cycle, significantly boosting throughput. With our factory’s advanced CNC machining and EDM capabilities, every mold component is precision-machined to tight tolerances. We have been serving global markets since 2017, and our team of 51-100 skilled professionals is dedicated to providing molds that exceed industry standards.
Key Features & Technical Specifications
- High Cavity Count: 1x32 layout enables mass production of dosing scoops with minimal waste and high repeatability.
- Premium Steel Selection: H13 for hot work applications and S136 for corrosion resistance and mirror finish; both materials offer excellent wear resistance.
- LKM Standard Compliance: Fully compatible with leading mold base systems, ensuring easy installation and maintenance.
- 220V Heating System: Integrated heater bands with precise temperature control for consistent melt flow and reduced cycle time.
- Precision Cooling Channels: Conformal cooling design accelerates part cooling and minimizes warpage, leading to higher quality scoops.
- Hot Runner System (Optional): Available with hot runner gating for improved material flow and reduced scrap.
- Customizable Features: Gate type, venting, and surface finish can be tailored to your specific resin and production needs.
| Parameter | Specification |
|---|---|
| Cavity Layout | 1 row x 32 cavities |
| Steel Grade | H13 (core) / S136 (cavity) |
| Mold Base Standard | LKM (standard sizes available) |
| Heating Voltage | 220V AC, 50/60Hz |
| Maximum Cycle Time | Approx. 8-12 seconds (depending on material) |
| Cooling System | Conformal cooling channels (water/oil) |
| Ejection System | Ejector pins + stripper plate (optional) |
| Operating Temperature | 180°C – 300°C (mold surface) |
Advantages & Customer Benefits
- Higher Productivity: 32 cavities per cycle dramatically increase output, reducing per-part cost and improving ROI.
- Extended Mold Life: H13 and S136 steel provide excellent toughness and corrosion resistance, minimizing downtime for repairs.
- Uniform Part Quality: Advanced heating and cooling control ensures each dosing scoop has consistent weight, dimensions, and surface finish.
- Easy Integration: LKM standard mold base allows quick installation on most injection molding machines with minimal modification.
- Reduced Energy Consumption: Efficient heating elements and optimized cooling reduce overall energy usage per part.
- Flexible Material Compatibility: Suitable for common thermoplastics such as PP, PE, ABS, PS, and nylon.
Our dosing scoop mold has been rigorously tested in our own production facility to ensure reliability under high-volume conditions. We offer comprehensive technical support, including mold design review, installation guidance, and troubleshooting. All molds are manufactured in our 1,000-3,000 square meter factory in Changzhou, China, equipped with state-of-the-art machinery and skilled technicians.
Trust & Company Credentials
Since 2017, Changzhou Hongxinyutai Precision Mold Co., Ltd. has been a trusted partner for injection mold solutions worldwide. Our factory covers an area of 1,000-3,000 square meters and employs 51-100 experienced professionals. We hold TS16969 certification, reflecting our commitment to quality management systems in the automotive and precision molding sectors. Our products are shipped from major ports including Jiangsu, Shanghai, and Shenzhen to markets across North America, South America, Europe, Asia, Africa, and Oceania.
We have delivered hundreds of dosing scoop molds to satisfied customers in the pharmaceutical, food, and cosmetic industries. Our team provides responsive after-sales service, including mold maintenance advice and spare parts availability. With a strong focus on precision engineering and customer satisfaction, we invite you to experience the reliability and performance of our High Cavity Injection Mold for Dosing Scoop. Contact us today for a quotation or technical consultation.
FAQ
-
What is the typical lead time for this mold?
Lead time is generally 25-35 working days, depending on customization requirements and current workload. We can provide a precise schedule upon order confirmation. -
Do you offer mold trial and sample testing?
Yes, we offer mold trial at our facility and can ship trial samples for your approval before mass production. Additional charges may apply. -
Can the mold be modified for different dosing scoop sizes?
Yes, the cavity dimensions can be customized to accommodate specific scoop volumes (e.g., 1ml, 5ml, 10ml). Please provide your sample or drawing. -
What materials are recommended for dosing scoops using this mold?
Common materials include polypropylene (PP), polyethylene (PE), and ABS. The mold design works well with most injection-grade thermoplastics. -
Is the heating system compatible with all injection molding machines?
The 220V heating system is standard for many machines, but we can also supply molds with 380V or other voltage upon request. -
How long does the mold last before requiring maintenance?
With proper maintenance (cleaning, lubrication, and inspection), the mold can produce over 2 million shots. H13 and S136 steel ensure long service life. -
Do you provide warranty?
Yes, we offer a standard 12-month warranty against manufacturing defects. Warranty covers mold steel, heater bands, and core components. -
Can you ship the mold to different countries?
Absolutely. We ship to all major global destinations via sea or air freight. Ports include Jiangsu, Shanghai, and Shenzhen.
