Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply thumbnail-2

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply thumbnail-3

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply thumbnail-4

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply thumbnail-5

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply photo-1

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply photo-2

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply photo-3

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply photo-4

Heavy-duty Hydraulic Metal Slitting Line, One-Stop Thin Coil Uncoil-Slit-Rewind Production Line Full Set Supply photo-5

Product Spotlights

.Dual-sided heavy scrap coiler for thick edge trims, stable winding without scrap jumping
.Extra thick integrated base frame with stress relief annealing, zero deformation under long heavy load
.High-pressure constant tension hydraulic station, maintain stable tension for rigid thick steel strips
.Large-diameter buffer transition rollers to avoid surface scratch and indentation on thick plates
.Overload automatic protection system for heavy cutting, auto stop to protect cutters and mai

US$ 80000 ≥1 Set

Key Specifications

Get Latest Price

Certification:

CE, ISO 9001:2000

Warranty:

1 Year

After-sales Service:

12 mouths

Contact Supplier Request Quote Chat Now

Jinan Zeye Machine Tool Manufacturing Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao port

Delivery Detail:

100 days

Product Details
Company Profile
Contact Us

Certification CE, ISO 9001:2000

Warranty 1 Year

After-sales Service 12 mouths

Automation Automatic

Condition New

Thickness 0.2-25mm

Transport Package Seaway package

Specification 16mmx2000mm

Trademark ZEYE

Origin Shandong ,China

Jinan Zeye Machine Tool Co.,Ltd

Cell & Whatsapp no.:+86 13583106699

E-mail: 2485229105@qq.com

Website:

Product Description

Model	ZSL-6	ZSL-8	ZSL-12	ZSL-16	ZSL-20/25
Material thickness	1.5-6.0mm	2.0-8.0 mm	3.0-12 mm	4.0-16.0 mm	6.0-20/25 mm
Material width	300-1600 mm	300-1800 mm	300-2000 mm	300-2000 mm	300-2200 mm
Slitting quantity	30	25	25	20	20
Width accuracy	±0.10 mm	±0.10 mm	±0.20 mm	±0.20 mm	±0.20 mm
Cutting burr
Winding split level floor
Line speed	120 m/min	100 m/min	80 m/min	60 m/min	60 m/min
Coil weight	20,30 t	20,30 t	20,35 t	20,35 t	20,35 t

Model	ZSL-1	ZSL-2	ZSL-3	ZSL-4
Material thickness	0.15-1.0mm	0.2-2.0 mm	0.3-3.0 mm	0.5-4.0 mm
Material width	300-1250 mm	300-1600 mm	300-1800 mm	300-2000 mm
Slitting quantity	35	35	35	25
Width accuracy	±0.05 mm	±0.05 mm	±0.10 mm	±0.10 mm
Cutting burr
Winding split level floor
Line speed	200 m/min	200 m/min	180 m/min	150 m/min
Coil weight	10,15 t	10,15,20 t	15,20,25 t	20,25,30 t

Slitting line ZSL series
Slitting line is mainly used for metail coil shear recoiling process from decoiling,feeding, head shear, loop, slitting to recoiling.

Its function is to shear wide metal coil longitudinlly into narrow coils, many kinds of material are availble to shear, such as,
cold rolled plate, electrolytic galvanized plate, hot dip galvanized plate, color-coated plate, stainless steel plate, aluminum plate, cooper plate etc.
Main Units
1.Entry coil car,
2.Uncoiler,
3.Feeding device,
4. Hydraulic head shear,
5.Looper,
6.Slitter machine,
7.Scrap winder,
8.Looper,
9.Tension device,
10.Hydraulic shear,
11.Recoiler
12.Exit coil car.

Slitting Line Layout

Main Technical Parameters

Our advantages
1.Automatically detect the material parameter , one key to load coil, automatically centering adjustment.
2.Our parts of equipment are produced by Japan MAZAK, Spain CORREA cnc etc. the world class the most advanced processing equipments. Which can ensure to produce out high precision parts.
3. Every part has been finished it's own complete technology process, such as forge, rough machined, heat treatment, cooling, burring, tempering, finish turning , milling, drill, thread tapping, match pin, surface quenching,coat the anti-rust oil, fine grinding, test ,entry warehouse, which ensure every part meets it's the best performance.

4.Strictly inspection every section during production and assembly process, to ensure every part to be used is qualified.

Part of our customers
Due to enjoy the high reputation of our shearing products, we have supply our cutting lines to POSCO, BAOSTELL, MA STEEL,ANSTEEL, DELONG STEE, SHAN STEEL,SINOTRUCK, CRRC, CHERY, CHANGFENG MOTOR, HRA ,OBON,SIEMENS, MCC, BOSCH, SANDEN etc. famous companies.
