Zhongcai High-tech Coloring Zhongcai BrandPhthalocyanine Green G General Type
1. Product Name: Phthalocyanine Green G
2. Chinese Name: Phthalocyanine Green G (Pigment Index Number: Pigment Green PG7)
3. English Name: PHTHALOCYANINEGREEN (C.I.PIGMENT 74260, GREEN 7)
4. Molecular Formula: C32Cl15 - 16N8CuH1 - 0
5. Molecular Weight: 1029 - 1027
6. Physical and Chemical Properties of the Product: Phthalocyanine Green G General Type
1. Product Name: Phthalocyanine Green G
2. Chinese Name: Phthalocyanine Green G (Pigment Index Number: Pigment Green PG7)
3. English Name: PHTHALOCYANINEGREEN (C.I.PIGMENT 74260, GREEN 7)
4. Molecular formula: C32Cl15-16N8CuH1-0
5. Molecular weight: 1029-1027
6. Physical and chemical properties of the product:
This product is a green uniform powder, insoluble in water and common organic solvents, soluble in concentrated sulfuric acid, chlorosulfonic acid, etc. It has high light fastness and weather resistance.
7. Main uses of the product: This product is mainly used for coloring interior and exterior wall coatings, water-based inks, and pigment printing pastes.
8. Product features: This product has bright colors, high coloring strength and color concentration, a yellowish hue, excellent dispersion performance (easy to grind), good fluidity, high light fastness, and very good storage stability. It is very suitable for producing high-concentration color pastes and is suitable for water-based applications.
9. Reaction principle:
This product is mainly produced by introducing dry chlorine gas into a low-melting salt mixture composed of aluminum trichloride and sodium chloride with copper phthalocyanine as the medium, and carrying out a chlorination reaction at 190℃ - 220℃ to obtain crude phthalocyanine green. The crude phthalocyanine green is then treated with o-dichlorobenzene to obtain the target product with excellent performance.
10. Technical indicators
Name |
Phthalocyanine Green G |
||
Index Number |
74260; PG7 |
||
CAS NO. |
1328-53-6 |
||
Tinting Strength |
110±3% |
||
Hue |
Approximate |
||
Batch Number: |
|||
Technical Data | |||
Physical Property Index | |||
Melting temperature |
> 450℃ |
||
pH value |
6--9 |
||
Residue on sieve |
≤2000ppm |
||
Water solubility |
Insoluble |
||
Odor |
None |
||
Appearance |
Bright green powder |
||
Physical properties | |||
Relative density |
1.60-1.80 |
Grade (1 to 5) |
|
Oil absorption |
35-45 |
Petroleum solvent |
5 |
Grade (1 to 5) |
Xylene |
5 |
|
Ethanol |
5 |
Mixed solvent |
5 |
n-Butanol |
5 |
Ethylene glycol monomethyl ether |
5 |
Ethyl acetate |
5 |
D.E.G. |
5 |
Methyl ethyl ketone |
5 |
D.B.P. |
5 |
Nitrocellulose |
5 |
D.O.P. |
5 |
Water |
5 |
Linseed oil |
5 |
Oleic acid |
5 |
||
Paraffin wax |
5 |
||
Fastness index | |||
Lightfastness (1 to 8) |
Heat resistance (1 to 5) |
||
Dark color |
8 |
220℃ for 30 minutes |
5 |
Light color (1:10 TiO2) |
8 |
240℃ for 20 minutes |
5 |
260℃ 10 minutes |
5 |
||
This product is a green and uniform powder, insoluble in water and common organic solvents, but soluble in concentrated sulfuric acid, chlorosulfonic acid, etc. It has high light fastness and weather resistance.
