As a leading manufacturer established in 1998, Anping County Boli Hardware Wiremesh Products Factory specializes in the production of high-quality filtration solutions. Our 304 Stainless Steel Wedge Wire Filter (0.3mm Slot, 150mm OD, 6m Length, Continuous Slot Design) is engineered to deliver exceptional performance in demanding filtration applications. With over two decades of experience and annual export volumes exceeding US$5 million, we are proud to offer a product that combines precision, durability, and cost-effectiveness. This filter is designed to meet the rigorous standards of industries ranging from water treatment to petrochemical processing, ensuring reliable operation and long service life.
The wedge wire filter features a robust construction using high-grade 304 stainless steel, which provides excellent corrosion resistance and mechanical strength. The 0.3mm slot width offers fine filtration while maintaining high flow rates, making it ideal for removing suspended solids and particles. The 150mm outer diameter and 6-meter length allow for efficient installation in large-scale systems, reducing the need for multiple elements. The continuous slot design eliminates dead zones and minimizes clogging, ensuring consistent performance over time. Below are key specifications and advantages:
| Parameter | Value |
|---|---|
| Material | 304 Stainless Steel |
| Slot Width | 0.3 mm |
| Outer Diameter | 150 mm |
| Length | 6 m |
| Design | Continuous Slot |
| Slot Shape | V-shaped (Wedge Wire) |
| Maximum Operating Temperature | Up to 400°C (depending on application) |
| Connection Type | Flanged, Threaded, or Welded (customizable) |
Key Features and Benefits
- High Precision Filtration: The 0.3mm slot width provides accurate particle separation, ensuring product quality and process efficiency.
- Exceptional Strength: The wedge wire construction with a V-shaped profile offers high load-bearing capacity, resisting deformation under pressure.
- Anti-Clogging Design: Continuous slot geometry allows smooth flow and self-cleaning capability, reducing maintenance downtime.
- Corrosion Resistance: 304 stainless steel withstands harsh environments, including acidic and alkaline media, extending service life.
- Easy Installation: The 6m length reduces the number of joints, lowering installation costs and potential leak points.
- Versatile Applications: Suitable for liquid filtration, gas filtration, dewatering, and solid-liquid separation across multiple industries.
- Customizable Options: Available in different slot widths, diameters, lengths, and end connections to meet specific requirements.
Technical Advantages in Detail
Our wedge wire filter is manufactured using advanced welding technology, ensuring consistent slot width and uniform distribution. The continuous slot design minimizes pressure drop while maximizing open area, resulting in higher flow rates compared to conventional mesh filters. Additionally, the V-shaped slot profile prevents particles from becoming trapped, enabling easy backwashing and regeneration. This makes the filter ideal for applications such as:
- Water treatment (industrial, municipal, wastewater)
- Oil and gas production (wellhead filtration, pipeline protection)
- Chemical processing (catalyst recovery, slurry filtration)
- Food and beverage (juice clarification, syrup filtration)
- Mining and mineral processing (dewatering, ore washing)
Trusted Quality and Global Reach
With a strong presence in markets across North America, South America, Europe, Asia, Africa, and Oceania, Anping County Boli Hardware Wiremesh Products Factory has built a reputation for reliability and excellence. Our annual export value of US$5 million to US$10 million reflects the trust our global customers place in our products. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery worldwide. Each filter undergoes rigorous quality control checks to guarantee dimensional accuracy and performance. We also offer customization services—contact us for tailored solutions to your specific filtration challenges. Experience the durability and efficiency of our 304 Stainless Steel Wedge Wire Filter; place your order today!
Frequently Asked Questions (FAQ)
- What is the tolerance of the 0.3mm slot width? The slot width is manufactured within ±0.03mm tolerance to ensure consistent filtration performance.
- Can this filter withstand high pressure? Yes, the wedge wire design provides high mechanical strength. The specific pressure rating depends on the end connection and support structure; please consult our technical team for your application.
- How do I clean the filter? It can be cleaned by backwashing, chemical cleaning, or mechanical brushing. The continuous slot design facilitates easy cleaning with minimal clogging.
- What end connections are available? We offer flanged, threaded, and welded connections. Custom connection types are also available upon request.
- Is the material certified? Our 304 stainless steel is sourced from reputable mills. Material certificates are available upon request.
- What is the typical lifespan of this filter? With proper maintenance, the filter can last several years, depending on the operating conditions and media characteristics.
- Can I order different slot widths or lengths? Yes, we offer customization. Slot widths from 0.1mm to 5mm and lengths up to 6m are available. Please provide your requirements.
- Do you provide samples for testing? Yes, we can provide sample pieces for evaluation. Contact our sales team for details.
