Anping Xinye Metal Wire Mesh Products Co., Ltd is proud to introduce our Heavy Duty Galvanized Welded Mesh with a 3.0mm wire diameter and 100x100mm mesh opening. Manufactured in our Hebei, China facility, this panel is engineered for demanding applications requiring superior strength and long-lasting corrosion resistance. The resistance welding process ensures each intersection is securely fused, providing a robust structure that outperforms traditional woven mesh. Whether for industrial fencing, concrete reinforcement, or heavy-duty animal enclosures, this mesh delivers reliable performance and easy installation.
Our product features a precise 2m x 3m panel size, ideal for large-scale projects. The galvanized coating protects against rust and environmental degradation, extending service life even in harsh conditions. Below are key technical specifications:
| Parameter | Value |
|---|---|
| Wire Diameter | 3.0 mm |
| Mesh Opening (Center to Center) | 100 mm x 100 mm |
| Panel Dimensions | 2 m x 3 m (custom sizes available upon request) |
| Material | Low carbon steel, galvanized |
| Welding Process | Resistance welding (automatic) |
| Surface Coating | Hot-dip galvanized (minimum 250 g/m²) |
Key Features & Benefits:
- Exceptional Strength: The 3.0mm thick wire combined with resistance welding creates a rigid panel that withstands heavy impact and pressure, ideal for security fencing or reinforcement.
- Corrosion Resistance: Hot-dip galvanizing provides a thick, uniform zinc coating that protects against rust, moisture, and chemicals, ensuring decades of service in outdoor or industrial environments.
- Large Panel Size: 2m x 3m panels reduce the number of joints needed, speeding up installation and improving structural integrity. Custom dimensions are available to match your project requirements.
- Versatile Applications: Suitable for uses such as highway barriers, sports field fencing, animal enclosures, concrete slab reinforcement, and heavy machinery guards.
- Cost-Effective: Minimal maintenance required due to galvanized coating, saving long-term replacement and labor costs.
- Easy Handling: Panels are rigid yet manageable for two workers to install. Pre-cut and ready for use.
Frequently Asked Questions (FAQ):
-
Q: What type of galvanizing is used?
A: Our panels are hot-dip galvanized, offering superior corrosion protection compared to electro-galvanized mesh. The zinc coating thickness meets industry standards for heavy-duty applications. -
Q: Can the panel size be customized?
A: Yes, we offer custom lengths and widths. Contact us with your specific dimensions and quantity requirements. -
Q: Is this mesh suitable for concrete reinforcement?
A: Absolutely. The 100x100mm mesh opening and 3.0mm wire provide excellent load distribution for concrete slabs, foundations, and driveways. -
Q: How strong is the weld joint?
A: Resistance welding creates a fusion bond that is typically stronger than the wire itself. Each joint is tested for consistent quality. -
Q: What is the typical lead time for standard panels?
A: Standard 2m x 3m panels are usually in stock. For large orders, lead time is 7-15 days depending on volume. -
Q: Packaging and shipping details?
A: Panels are bundled with steel straps and wrapped in protective material to prevent damage during transit. We ship via sea or air freight as per your preference. -
Q: Does this mesh require painting or additional coating?
A: No, the galvanized finish is ready to use. If you require a colored coating, we can offer powder-coating as an optional service.
Why Choose Anping Xinye?
With over a decade of experience in manufacturing wire mesh products, Anping Xinye Metal Wire Mesh Products Co., Ltd has built a reputation for reliability and quality. Our factory in Hengshui, Hebei utilizes advanced automatic welding machines and strict quality control procedures. We export to more than 20 countries, serving industries such as construction, agriculture, mining, and security. Every batch of mesh undergoes tensile and weld-strength testing to ensure compliance with international standards. Our dedicated customer support team provides technical guidance and after-sales service. Contact us today for a quote or to discuss your custom requirements – we are ready to partner with you for your next project.
