Henan San Kuang Machinery Technology Co., Ltd. brings you a high-quality Replacement Transmission Gear Shaft for Packaging Machinery, engineered to restore and enhance the performance of your packaging lines. With over 10 years of manufacturing experience and a factory spanning 10,000-30,000 square meters, we specialize in producing precision transmission components that meet rigorous industrial standards. Our gear shafts are designed as direct replacements for worn or damaged parts, ensuring minimal downtime and maximum operational efficiency. Trust in our expertise to deliver durability, precision, and reliability for your packaging machinery needs.
Key Features & Technical Specifications
- Superior Material Selection: Manufactured from high-grade alloy steel or carbon steel, with optional heat treatment for enhanced hardness and wear resistance (58-62 HRC).
- Precision Machining: CNC turned and ground to tolerances of ±0.01mm, ensuring smooth transmission and perfect fit with existing gears and bearings.
- Versatile Compatibility: Suitable for a wide range of packaging machinery including horizontal/vertical form-fill-seal machines, cartoners, case packers, and labeling equipment.
- Surface Treatment Options: Black oxide, phosphating, or custom coatings available to improve corrosion resistance and reduce friction.
- Customizable Dimensions: We can produce shafts according to your original drawings or samples, with lengths, diameters, keyway, and spline configurations tailored to your application.
- Rigorous Quality Control: Each shaft undergoes dimensional inspection, hardness testing, and surface finish checks to ensure consistent quality.
| Parameter | Specification |
|---|---|
| Material Grade | 40Cr, 45# steel, 20CrMnTi, or equivalent |
| Hardness | 58-62 HRC (after heat treatment, optional) |
| Diameter Tolerance | h6 – h7 |
| Surface Roughness | Ra ≤ 0.8 μm |
| Keyway Tolerance | JS9 (or as per drawing) |
| Max Length | Up to 2000 mm (customizable) |
Advantages for Your Packaging Line
- Reduced Downtime: Direct replacement design eliminates the need for modifications, allowing quick installation and fast return to production.
- Extended Service Life: High-quality materials and heat treatment greatly improve wear resistance, reducing the frequency of replacements.
- Cost-Effective: Competitive pricing without compromising on quality, helping you maintain budget control for spare parts.
- Technical Support: Our engineering team can assist in shaft selection, customization, and troubleshooting to ensure optimal performance.
About Henan San Kuang Machinery Technology Co., Ltd. – Established in 2014, we are a professional manufacturer with an annual export value of US$2.5 Million – US$5 Million. Our factory employs 51-100 skilled workers and holds multiple certifications including ISO9001, ISO14000, OHSAS18001, SA8000, and others. We serve markets across North America, South America, Europe, Asia, Africa, and Oceania. Our products are shipped from major ports including Shanghai, Lianyungang, Qingdao, and Tianjin, ensuring timely delivery worldwide. With a strong commitment to quality and customer satisfaction, we are your trusted partner for packaging machinery spare parts.
Don't let a worn gear shaft compromise your production efficiency. Choose Henan San Kuang's replacement transmission gear shaft for reliable performance and long service life. Contact us today for a quote or to discuss your specific requirements. We look forward to supporting your packaging operations with our high-quality components.
Frequently Asked Questions
Q1: What materials are used for the gear shaft?
A: We use high-strength alloy steel (e.g., 40Cr, 20CrMnTi) or carbon steel (45#) according to customer requirements. Heat treatment is available to achieve hardness up to 62 HRC.
Q2: Can you produce shafts according to my sample or drawing?
A: Yes, we can manufacture based on your original sample or technical drawing. Please provide dimensions, tolerances, and any special requirements.
Q3: How long is the lead time for a custom order?
A: Typical lead time is 15-25 working days after confirmation, depending on the complexity and quantity. Urgent orders can be discussed.
Q4: What is the minimum order quantity (MOQ)?
A: MOQ is usually 1 piece for standard sizes, but for custom dimensions we may require a small batch. Contact us for details.
Q5: Do you offer surface treatment options?
A: Yes, we offer black oxide, phosphating, nickel plating, and other coatings. Please specify your preference.
Q6: How do you ensure the quality of the shafts?
A: We have a strict quality control system including raw material inspection, in-process checks, and final dimensional & hardness testing. Certificates of analysis are available upon request.
Q7: Is the shaft compatible with my specific packaging machine model?
A: We can design shafts to fit most common packaging machinery brands. Provide your machine model or original part number for compatibility verification.
Q8: Do you provide international shipping?
A: Yes, we ship worldwide via sea, air, or express. Our main ports are Shanghai, Qingdao, Lianyungang, and Tianjin.
