Hemaokang Steel (Shandong) Co., Ltd. is proud to offer our premium Stainless Steel Pipe 304 1.5 Inch OD 0.065 Wall Thickness 20 ft Long, a product designed for demanding industrial applications where reliability, corrosion resistance, and dimensional accuracy are critical. As a trusted supplier with an annual export value of US$50–100 million and ISO9001 certification, we ensure every pipe meets strict quality standards. Each pipe is supplied with a Mill Test Report for full traceability, giving you confidence in material integrity.
This 304 stainless steel pipe combines excellent formability with outstanding resistance to oxidation and many corrosive media. The 1.5-inch outer diameter and 0.065-inch wall thickness offer a robust balance of strength and weight, while the 20-foot length minimizes joints and reduces installation time. Whether you are building process lines, structural supports, or sanitary systems, this pipe delivers consistent performance.
Key Features & Benefits
- High-Grade 304 Stainless Steel: Excellent corrosion resistance in most environments, including food, chemical, and marine applications.
- Precise Dimensions: 1.5" OD ±0.005" and 0.065" wall thickness for consistent fit and flow characteristics.
- Full 20 ft Length: Reduces welding joints, lowers installation costs, and improves system integrity.
- Mill Test Report Included: Chemical composition and mechanical properties verified per ASTM requirements.
- ISO9001 Certified Production: Quality management system ensures repeatability and batch consistency.
- Customizable Surface Finish: Available annealed & pickled, 2B, or polished finish upon request.
- Seaworthy Packaging: Each pipe is bundled with plastic caps and wrapped to prevent damage during transit.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | 304 Stainless Steel (UNS S30400) |
| Outer Diameter | 1.5 inch (38.1 mm) |
| Wall Thickness | 0.065 inch (1.65 mm) |
| Length | 20 ft (6.1 m) |
| Standard | ASTM A269 / A312 |
| Tensile Strength | ≥ 515 MPa (75 ksi) |
| Yield Strength (0.2% offset) | ≥ 205 MPa (30 ksi) |
| Elongation | ≥ 35% |
| Surface Finish | Annealed & Pickled (standard); 2B, #4, or mirror polish optional |
Why Choose Hemaokang Steel?
We are a young but rapidly growing company based in Liaocheng, Shandong, China, with a strong focus on quality and customer satisfaction. Our team of 51–100 experienced professionals ensures that every order is handled with care. With an annual export value of US$50 million to US$100 million, we serve markets across North America, South America, Europe, Africa, Oceania, and Asia. Our ISO9001 certification reflects our commitment to consistent quality, and we provide a Mill Test Report with every shipment for full material traceability.
We understand that stainless steel pipe is often used in critical applications. Therefore, we offer flexible customization options including cutting to custom lengths, beveling, and different surface finishes. Our packaging is designed for long-distance sea freight, protecting your pipes from moisture and mechanical damage. You can rely on us for prompt delivery and responsive after-sales support.
Frequently Asked Questions
Q1: What is a Mill Test Report (MTR) and why is it important?
A: A Mill Test Report is a quality assurance document that certifies the chemical composition and mechanical properties of the steel. It is essential for traceability in industries like oil & gas, pharmaceutical, and food processing, where material integrity is critical.
Q2: Is this pipe suitable for potable water systems?
A: Yes, 304 stainless steel is widely used for potable water due to its corrosion resistance and non-toxic nature. However, local codes should be checked for specific requirements.
Q3: Can you provide custom lengths or cut-to-size?
A: Absolutely. We can cut the 20 ft pipes to your required lengths, with tolerances as per your specification. Please contact us with your exact requirements.
Q4: What surface finishes are available?
A: Standard finish is annealed & pickled. We also offer 2B (cold rolled, bright), #4 brushed, or mirror polish finishes. Each finish has different applications and aesthetic properties.
Q5: How do you ensure the pipe meets dimensional tolerances?
A: We use calibrated measuring instruments and perform 100% inspection on OD, wall thickness, and length before packing. Our ISO9001 system includes regular process audits.
Q6: What is the minimum order quantity (MOQ)?
A: MOQ for standard sizes is typically 100 pieces (20 ft each). For smaller quantities, please contact us to discuss availability.
Q7: What is the lead time for this product?
A: For stock items, lead time is 7–10 working days. For custom orders, it depends on volume and finish; typically 15–25 days.
Q8: Do you offer samples for quality evaluation?
A: Yes, we can provide small sample pieces (approx. 30 cm) for a nominal fee plus shipping. The cost is refundable with a first order.
Ready to place your order or request a quote? Contact Hemaokang Steel today. With our reliable quality, comprehensive Mill Test Report, and global shipping capabilities, we are your ideal partner for 304 stainless steel pipe solutions.
