>Product Introduction
Manufactured from Grade 2 titanium, these tubes provide stable mechanical strength, excellent corrosion resistance, and long-term durability in chloride-rich and chemically aggressive environments. Gr2 is widely used in seawater desalination systems, heat-exchanger units, marine structures, and chemical processing equipment where resistance to pitting, crevice corrosion, and erosion by high-velocity fluids is required. Its high ductility and weldability also make Gr2 suitable for complex piping layouts and on-site fabrication in chemical plants, offshore facilities, and seawater cooling loops.
▶️ Product Parameters | ||
Property |
Gr2 Titanium Tube |
4130 Chromoly Steel |
Density |
4.51 g/cm³ |
7.85 g/cm³ |
Yield Strength |
≥275 MPa |
~850 MPa |
Elongation |
20% |
18% |
Wall Tolerance |
±0.03 mm |
±0.05 mm |
>>>Product Features & Application
■ Optimized for Endurance Frames
Engineered with a balance of stiffness and compliance, our tubes are ideal for gravel, touring, and endurance road bikes.
■ Fatigue Resistance Under Proven Conditions
Maintains stability under repeated dynamic loading, with over 1 million cycles tested under controlled axial conditions.
■ Lightweight with Structural Integrity
Reduces frame weight by up to 140g per 55cm down tube compared to 6061 aluminum, while retaining strength.
■ Excellent Weldability
Supports TIG welding with recommended argon purity ≥99.99% and preheat guidelines for >1.5mm wall thickness.
■ Verified Use in Competitive Frames
Applied by several European builders for gravel and road frame models used in multi-stage races.
✅ Secure Packing：
All titanium materials are packed in wooden cases with waterproof lining and foam protection to prevent damage during transit.
✅ Easy Handling：
Rods, plates, and wires are palletized for convenient loading and unloading.
✅ Flexible for Small Orders：
Air express is available for small quantity orders (7–15 days worldwide).
✅ Reliable for Bulk Orders：
For large shipments, we provide sea freight with full export documents.
✅ Full Tracking Provided：
All shipments come with tracking numbers to ensure delivery status is visible at every step.
After-Sales Service
■ Each batch includes traceable production and basic dimensional inspection data.
■ Accept customization for CNC slotting, swaged end, hydroforming compatibility and more.
■ Technical support responds within 24 hours; bilingual engineers available.
■ Surface finish options include sand-blasted, polished, and satin matte titanium gray.
■ Optional fatigue, corrosion, or weldability guidance available per application needs.
