Hengshui City Yike Composite Materials Co., Ltd., established in 2009, is proud to present our Atmospheric Pressure 8000L Fertilizer Storage Tank with Overflow Protection and Vent Filter. This tank is engineered to safely store liquid fertilizers and agricultural chemicals, providing reliable performance under demanding conditions. With our extensive experience in composite materials manufacturing, we deliver a product that combines durability, safety, and cost-effectiveness. Whether you are a large farm, a cooperative, or a chemical distributor, this tank is designed to meet your bulk storage needs while minimizing environmental risks and product loss.
The 8000-liter capacity makes it ideal for medium to large-scale operations, offering ample space for fertilizers, herbicides, or other liquid agrochemicals. Its atmospheric pressure design ensures safe operation without the need for complex pressure controls, while the integrated overflow protection system prevents accidental spills and overfilling. The vent filter effectively blocks dust, insects, and contaminants, keeping the stored liquid pure and reducing evaporation losses. All these features come together in a robust composite shell that resists corrosion, UV radiation, and harsh weather.
Key Features & Benefits
- Corrosion-Resistant Composite Material: The tank is made from high-quality FRP (Fiberglass Reinforced Plastic), which is lightweight yet extremely strong. It will not rust, rot, or degrade when exposed to acidic or alkaline fertilizers, ensuring a long service life.
- Overflow Protection System: A built-in overflow pipe and float valve (or equivalent mechanism) automatically stops the filling process when the tank reaches its maximum capacity, preventing dangerous spills and environmental contamination.
- Vent Filter: The top-mounted vent filter uses a replaceable activated carbon or mesh element to purify incoming air. This keeps the tank contents free from airborne particles and reduces odors, making it suitable for operation near populated areas.
- Large 8000L Capacity: Effectively stores up to 8000 liters of liquid, reducing the frequency of refills and increasing operational efficiency for farms and industrial facilities.
- Atmospheric Pressure Design: No need for pressure vessels or complex safety valves; the tank operates at ambient pressure, simplifying installation and maintenance.
- UV Stabilized Outer Layer: The outer gel coat is treated with UV inhibitors, preventing fading and cracking under direct sunlight, ensuring the tank remains visually appealing and structurally sound for years.
- Customizable Color & Fittings: Available in standard colors (green, white, blue) and can be equipped with additional nozzles, sight glasses, or level indicators upon request.
Technical Specifications
| Parameter | Value |
| Nominal Capacity | 8000 Liters (8 m³) |
| Working Pressure | Atmospheric (0 bar / 0 psi) |
| Design Temperature | -20°C to +60°C |
| Material | FRP Composite (Fiberglass + Polyester / Vinyl Ester Resin) |
| Overflow Protection | Integrated overflow pipe & float valve (or equivalent) |
| Vent Filter Type | Activated carbon / mesh filter (replaceable) |
| Inlet/Outlet Connections | 2" or 3" BSP/NPT (customizable) |
| Dimensions (Approx.) | Diameter 2000 mm, Height 3000 mm (varies by design) |
| Weight (Empty) | Approx. 250 kg |
| Color Options | Green, White, Blue (custom colors available upon request) |
Why Choose This Tank for Your Fertilizer Storage?
Liquid fertilizers are often corrosive and require specialized storage solutions. Traditional steel tanks can rust, while plastic tanks may degrade under UV light and become brittle over time. Our FRP composite tank offers the best of both worlds: the strength of steel and the corrosion resistance of plastic. The overflow protection feature is critical for environmental compliance – it prevents accidental releases that could lead to soil and water contamination, saving you from costly fines and cleanup. The vent filter also reduces the release of volatile compounds, making your operation more eco-friendly.
Furthermore, the 8000L capacity strikes an excellent balance between storage volume and footprint. You can place it on a concrete pad or a compact stand, and it requires minimal maintenance. The tank is supplied with clear installation guidelines, and our technical support team is available to assist you. Whether you store urea solutions, ammonium nitrate, or liquid potassium, this tank is up to the task.
Frequently Asked Questions (FAQ)
-
Q: What types of fertilizers can be stored in this tank?
A: This tank is suitable for most liquid fertilizers, including urea-ammonium nitrate (UAN), ammonium polyphosphate, potassium chloride solutions, and other non-oxidizing, non-flammable agricultural chemicals. Always check compatibility with the specific chemical; we can provide a chemical resistance chart upon request. -
Q: How does the overflow protection work?
A: The tank is equipped with an overflow pipe that connects to a float valve inside the tank. When the liquid level reaches a preset maximum, the float valve closes the inlet, stopping further filling. Alternatively, a simple overflow pipe can direct excess liquid to a safe drainage area. This prevents overfilling and spills. -
Q: Is the vent filter replaceable?
A: Yes, the vent filter is designed to be easily replaced. We recommend inspecting it every 6 months and replacing the filter element (activated carbon or mesh) as needed, depending on the operating environment and the type of stored liquid. -
Q: Can this tank be used for drinking water or food-grade liquids?
A: No, this tank is designed specifically for agricultural and industrial chemical storage. The materials used are not certified for potable water or food contact. For food-grade applications, please contact us for special options. -
Q: What is the expected lifespan of the tank?
A: With proper installation and regular maintenance, an FRP composite tank can last 15–20 years or more. The UV-stabilized outer layer and corrosion-resistant inner surface contribute to its long service life. -
Q: What ports do you ship from?
A: We ship from Tianjin port, Shanghai Port, or Tianjin port of China, depending on the destination and order volume. Our logistics team will arrange the most cost-effective shipping method for your location. -
Q: Do you offer customization of the tank, such as different inlet/outlet sizes or additional fittings?
A: Absolutely. We can customize the tank with various inlet/outlet sizes (e.g., 2", 3", or 4" BSP/NPT), additional sight glasses, level indicators, manholes, or ladders. Please provide your requirements when placing an order. -
Q: Is there a warranty?
A: Yes, we offer a standard 12-month warranty against manufacturing defects. Extended warranty options are available upon request. Our after-sales team is also available for remote technical support.
Trust in our experience and global reach. Since 2009, Hengshui City Yike Composite Materials Co., Ltd. has been a reliable manufacturer of composite storage tanks. With an annual export value of US$1.5 Million – US$2.5 Million, we have successfully delivered products to markets across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. Our location in Hengshui, Hebei, China, gives us access to a well-developed supply chain, ensuring competitive pricing and timely delivery. We are committed to quality control and customer satisfaction. When you choose our Atmospheric Pressure 8000L Fertilizer Storage Tank with Overflow Protection and Vent Filter, you are investing in a durable, safe, and efficient solution that will serve your storage needs for years to come. Contact us today for a quote or to discuss your specific requirements.
