Help CenterSlewing Drive Used in Packaging Machine With Dynamic Load 50 kN and Low Backlash 0.1 mm
Product Spotlights
Related Products
-
Slewing Drive 20 Ton Load Capacity IP65 Waterproof Custom Gearbox for Construction MachineryNegotiableMOQ: 1 Piece -
Slewing Bearing 0.2-2 Rpm Variable Speed With 5-arcmin Precision Single Row Ball DesignNegotiableMOQ: 1 Piece
-
Custom Slewing Bearing Gear Applied to Robot Joint Rotation Speed up to 10 Rpm With Grease LubricationNegotiableMOQ: 1 Piece
-
Slewing Bearing Gear 2-Year Warranty Mill Test Report Included Factory Direct Technical SupportNegotiableMOQ: 1 Piece
-
Custom Slewing Bearing 304 Stainless Steel Raceway for Outdoor Environment Resistant to CorrosionNegotiableMOQ: 1 Piece
Henan San Kuang Machinery Technology Co., Ltd., established in 2014, is a professional manufacturer of precision slewing drives and rotary table bearings. With a factory size of 10,000–30,000 square meters and an annual export value of US$2.5–5 million, we serve clients across North America, Europe, Southeast Asia, and beyond. Our Slewing Drive Used in Packaging Machine with Dynamic Load 50 kN and Low Backlash 0.1 mm is designed to deliver exceptional positioning accuracy and durability for high-speed packaging applications. This product combines robust construction with advanced gear technology to ensure reliable performance under demanding operating conditions.
The slewing drive features a compact, flange-mount design that integrates seamlessly into packaging machinery such as rotary fillers, labeling machines, and case packers. With a dynamic load capacity of 50 kN and a backlash as low as 0.1 mm, it provides precise angular positioning and smooth rotation, minimizing product waste and downtime. The unit is manufactured using high-grade alloy steel components and precision-ground gears, ensuring long service life even in continuous operation.
Key Technical Specifications
| Parameter | Value |
| Dynamic Load Rating | 50 kN |
| Backlash | ≤ 0.1 mm |
| Gear Ratio | Available upon request (e.g., 10:1, 20:1, 50:1) |
| Output Torque | Up to 5,000 Nm (depending on ratio) |
| Holding Torque | ≥ 1.5 × Dynamic Torque |
| Operating Temperature | -20°C to +80°C |
| Protection Rating | IP65 (optional) |
| Material | Alloy steel (gear), cast iron (housing) |
Features & Benefits
- Ultra-Low Backlash: Precision-ground worm gear and hardened steel components achieve ≤0.1 mm backlash, ensuring repeatable positioning and reduced product defect rates in packaging lines.
- High Dynamic Load Capacity: The 50 kN dynamic load rating allows the drive to handle heavy packaging loads without deformation or fatigue, extending machine life.
- Compact Flange Design: Space-saving mounting footprint fits into tight packaging machine layouts, simplifying integration and reducing overall machine size.
- Smooth & Quiet Operation: Optimized gear meshing and sealed lubrication minimize noise and vibration, creating a better working environment.
- Customizable Gear Ratios: Multiple standard ratios available, with special ratios customizable to match specific speed and torque requirements.
- Durable Construction: Alloy steel gears with induction-hardened teeth and cast iron housing provide excellent wear resistance and thermal stability.
- Low Maintenance: Pre-filled with long-life grease and equipped with double-lip seals, reducing the need for frequent lubrication and inspection.
- Versatile Application: Suitable for rotary indexing tables, turntables, and other packaging machine mechanisms requiring precise angular control.
Trusted Manufacturing Partner
Henan San Kuang Machinery Technology Co., Ltd. operates a modern facility spanning 10,000–30,000 square meters and employs 51–100 skilled professionals. We hold multiple management system certifications including ISO9001, ISO14000, OHSAS18001 and others, reflecting our commitment to quality, environment, and safety. Our products are exported to over 50 countries worldwide, with an annual export value exceeding US$2.5 million.
We offer comprehensive after-sales support, including 12-month warranty against manufacturing defects, technical documentation, and prompt replacement parts. Our engineering team can assist with custom designs to meet unique packaging line requirements. To learn more about how our slewing drive can improve your packaging machine performance, contact us today for a quote or technical consultation.
Frequently Asked Questions (FAQ)
-
Q: What is the typical lead time for this slewing drive?
A: Standard models can be shipped within 15–20 working days after order confirmation. Customized versions may require 25–35 working days depending on complexity. -
Q: Can the backlash be further reduced below 0.1 mm?
A: Yes, we offer a precision-grade option with backlash ≤0.05 mm, available upon request with additional cost and longer lead time. -
Q: Is this slewing drive compatible with servo motors?
A: Absolutely. The input flange and shaft can be customized to mount directly to most servo motor models. Please provide motor specifications for proper matching. -
Q: What lubricant is recommended for harsh environments?
A: Our standard grease is suitable for -20°C to +80°C. For high-temperature or washdown environments, we can provide food-grade grease or synthetic oil options. -
Q: Do you provide mounting drawings and 3D models?
A: Yes, we provide 2D CAD drawings and 3D STEP files upon request to facilitate integration into your packaging machine design. -
Q: What is the maximum radial load the drive can withstand?
A: The maximum radial load depends on bearing configuration. In standard design, it supports up to 30 kN radial load. Custom designs can increase this capacity. -
Q: How do I determine the correct gear ratio for my application?
A: Our engineers can calculate based on your required output torque, speed, and motor parameters. Please share your application details for a recommendation. -
Q: Is the product covered by warranty?
A: Yes, we offer a 12-month warranty from the date of shipment against manufacturing defects in materials and workmanship.
